User Manual

PT-HDBT- 2- 70 TX

User Manual

HDBaseT Transmitter 4K (60Hz 4:2:0) with IR and RS232

Model PT-HDBT- 2-70 TX

Designed in Germany

User Manual

PT-HDBT- 2- 70 TX

Preface

Read this user manual carefully before using this product. Pictures shown in this

manual are for reference only. Diﬀerent model layouts and speciﬁcations are subject

to the physical product.

This manual is for operation instructions only, not for any maintenance usage.

In the constant eﬀort to improve our product, we reserve the right to make changes in

functions or parameters without prior notice or obligation.

Trademarks

Product model and logo are trademarks. Any other trademarks mentioned in this

manual are acknowledged as the properties of the trademark owner. No part of this

publication may be copied or reproduced without the prior written consent.

FCC Statement

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful

interference to radio communications. It has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful interference in

a commercial installation.

Operation of this equipment in a residential area is likely to cause interference, in

which case the user at their own expense will be required to take whatever measures

may be necessary to correct the interference.

Any changes or modiﬁcations not expressly approved by the manufacture would void

the user’s authority to operate the equipment.

User Manual

PT-HDBT- 2- 70 TX

REACH | 1907/2006/EU

ROHS | 2011/65/EU

PureLink hereby declares that this product complies with PureTools -HDBT-702-PT TX

Directives 1907/2006/EU und 2011/65/EU.

EMC / LVD (Electro Magnetic Compatibility / Low Voltage Directive)

PureLink GmbH hereby declares that this product PureTools -HDBT-702- PT TX

complies with Directives 2014/30/EU and 2014/35/EU. The full text of the EU

Declaration of Conformity is available at the following Internet address:

http://www.purelink.de/ce/4251364706763_CE.pdf
