Sida 1/14

AC 22S

ACTIVE CROSSOVER

CH 1

MASTER

POWERDELAY DELAYLEVEL LEVEL LEVEL LEVEL LEVEL LEVELFREQUENCY FREQUENCY

LOW

MUTE

LOW / HIGH HIGH CH 2

MASTER

STEREO

LOW LOW / HIGH

MUTE

HIGH

AC 22S

ACTIVE

CROSSOVER

MASTER LOW LOW / MID

MONO

MID MID / HIGH HIGH

MONO SUB

INACTIVE

1 00

INACTIVE

1 00

100

1 00

MAXMIN

3.0k

70 3.6k

120

250

180

300

700

1.5k

2.0k

1.0k

500

400

3.0k

70 3.6k

120

250

180

300

700

1.5k

2.0k

1.0k

500

400

INACTIVE: MONO SUB

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

To reduce the risk of electrical shock, do not open the unit. No user

serviceable parts inside. Refer servicing to qualied service personnel.

e symbols shown below are internationally accepted symbols

that warn of potential hazards with electrical products.

is symbol indicates that a dangerous voltage

constituting a risk of electric shock is present

within this unit.

is symbol indicates that there are important

operating and maintenance instructions in the

literature accompanying this unit.

WARNING

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A

grounding-type plug has two blades and a third grounding prong. e wide blade or third prong is provided for your safety. If the provided plug

does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord and plug from being walked on or pinched particularly at plugs, convenience receptacles, and the point where it exits from

the apparatus.

11. Only use attachments and accessories specied by Rane.

12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution

when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply

cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

15. e plug on the power cord is the AC mains disconnect device and must remain readily operable. To completely disconnect this apparatus from

the AC mains, disconnect the power supply cord plug from the AC receptacle.

16. is apparatus shall be connected to a mains socket outlet with a protective earthing connection.

17. When permanently connected, an all-pole mains switch with a contact separation of at least 3 mm in each pole shall be incorporated in the

electrical installation of the building.

18. If rackmounting, provide adequate ventilation. Equipment may be located above or below this apparatus, but some equipment (like large power

ampliers) may cause an unacceptable amount of hum or may generate too much heat and degrade the performance of this apparatus.

19. is apparatus may be installed in an industry standard equipment rack. Use screws through all mounting holes to provide the best support.

WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture. Apparatus shall not be exposed to dripping

or splashing and no objects lled with liquids, such as vases, shall be placed on the apparatus.

NOTE: is equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

ese limits are designed to provide reasonable protection against harmful interference in a residential installation. is equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Changes or modications not expressly approved by Rane Corporation could void the user's authority to operate the equipment.

is Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

WARNING: is product may contain chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm.

Manual-1

AC 22S

ACTIVE CROSSOVER

OPERATORS MANUAL

CH 1

MASTER

POWERDELAY DELAYLEVEL LEVEL LEVEL LEVEL LEVEL LEVELFREQUENCY FREQUENCY

LOW

MUTE

LOW / HIGH HIGH CH 2

MASTER

STEREO

LOW LOW / HIGH

MUTE

HIGH

AC 22S

ACTIVE

CROSSOVER

MASTER LOW LOW / MID

MONO

MID MID / HIGH HIGH

MONO SUB

INACTIVE

100

INACTIVE

100

MAXMIN

3.0k

70 3.6k

120

250

180

300

700

1.5k

2.0k

1.0k

500

400

3.0k

70 3.6k

120

250

180

300

700

1.5k

2.0k

1.0k

500

400

INACTIVE: MONO SUB

WEAR PARTS: is product contains no wear parts.

QUICK START

e AC 22S can be either a Stereo 2-Way or Mono 3-Way cross-

over. To keep operation simple, remember this:

Labels the controls refer to the above 2-Way Stereo mode.

Labels the controls refer to the below 3-Way Mono mode.

e fact that the AC 22S is a multiple function unit means

the outputs are switched around depending on the SYSTEM

MODE SUBWOOFER and switches on the back of the unit.

To operate the AC 22S in Stereo 2-Way mode, be sure that

the Mode switch is set for STEREO 2-WAY. Follow the labels

above the controls and jacks.

When operated in the Mono 3-Way mode, the switch should

be set in the MONO 3-WAY position. Follow the labels below

the controls and jacks. In Mono 3-Way mode the Channel 1 High

Output is unusable. is output is the high-pass-only portion of

the midrange lter. e Channel 1 High Level and the Channel 2

Master Level are also defeated on the front panel.

In agreement with IEC and AES/ANSI standards, AC 22S

wiring convention is pin 2 Positive, pin 3 Negative (return),

pin 1 chassis ground. See the “Sound System Interconnection”

RaneNote included with this manual for more information on

cabling and grounding requirements.
