ROLLS RM64 FOUR ZONE MIXER
The new ROLLS RM64 Four Zone Mixer combines t wo paging microphones
with up to four line level source inputs. Each input is switch selected to output
to any combination of four zone outputs. The outputs are all balanced XLR
connectors, and a 1/4" Remote Volume jack provides each zone with the
means for external volume control. The Microphone inputs feature automatic
ducking for easy paging.
The RM64 is the ideal solution for banquet rooms, offices, restaurant/night
clubs, etc.
FEATURES
Two Mic Inputs with Trim controls
Four RCA source inputs
Four Balanced XLR Zone Outputs
Automatic paging
Remote Volume for each output
SPECIFICATIONS
Input Impedance: 10K 9 balanced
50K 9 unbalanced RCA
Output Impedance: 50 9 Balanced XLR
Max Input Level: Mic: +10 dB
Source: +22 dB
Phantom Power: +12 Volts DC
Input Connectors: XLR and RCA
Outputs: 4 ea. XLR
Max Gain: 60 dB mic
30 dB line
S/N Ratio: >75 dB
THD < .3%
IMD (SMPTE) < .3%
CMRR 90 dB
Frequency Response: 20Hz to 20kHz +/- 0 dB
Power 120 VAC 50-60 Hz, 15 W
Weight: 7 lbs (3KG)
Size: 19" x 1.75" x 6.5" (48cm x 4.5cm x 17cm)
ROLLS Coporation
5968 South 350 West, Salt Lake City, UT, 84107
(801) 263-9053 FAX (801) 263-9068
rollsrfx@rolls.com • www.rolls.com
WARNING:
DO NOT EXPOSE THIS EQUIPMENT
TO RAIN OR MOISTURE
NO USER SERVICABLE PARTS INSIDE.
120 VAC
50/60Hz 15VA
MODEL RM64
MADE IN USA
SERIAL NUMBER
64-
RISQUE DE CHOC - NE PAS ENLEVER
C US
REMOTE
VOLUME
REMOTE
VOLUME
REMOTE
VOLUME
REMOTE
VOLUME
REMOTE
VOLUME
OUTPUT
3
OUTPUT
2
OUTPUT
1
OUTPUT
4
ZONE FOUR ZONE THREE ZONE ONEZONE TWO SOURCE INPUTS MIC TWO MIC ONE
4321
INPUT
2
INPUT
1
TRIM TRIM
1 2 3 4 5 6
ZONE
DUCK
ASSIGN
1 2 3 4
PHANTOM
POWER
1 2
LEVEL LEVEL
12345678 1234567812345678
LEVELLEVELLEVELLEVEL
pwr
ZONE
SELECT
1 2 3 4 1 2 3 4
ZONE
SELECT
1 2 3 4 1 2 3 4
ZONE
SELECT
1 2 3 4 1 2 3 4
LEVEL LEVEL LEVEL LEVEL
FOUR
ZONE
MIXER
RM64
