Safco 5272 Bruksanvisning
Läs nedan 📖 manual på svenska för Safco 5272 (2 sidor) i kategorin Byrå. Denna guide var användbar för 3 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare
Sida 1/2
2
1
Attach Leg Support (no
holes in flange) and Side
Frame Support (with
holes in flange) to Front
Right Leg using 4 Pan
Head Screws and 4
Washers (ensuring
Washers are snug
against the head of the
screws).
Attach Leg Support (no
holes in flange) and Side
Frame Support (with
holes in flange) from
Step 1 to Back Right Leg
using 4 Pan Head Screws
and 4 Washers
(ensuring Washers are
snug against the head of
the screws).
Attach Leg Support (no
holes in flange) and Side
Frame Support (with
holes in flange) to Front
Left Leg using 4 Pan
Head Screws and 4
Washers (ensuring
Washers are snug
against the head of the
screws).
Attach Leg Support (no
holes in flange) and Side
Frame Support (with
holes in flange) from
Step 3 to Back Left Leg
using 4 Pan Head Screws
and 4 Washers
(ensuring Washers are
snug against the head of
the screws).
3
4
Work/Learn Desk # 5272/5273
Simple Collection™ Assembly Instructions
safcoproducts.com
For questions or concerns, please call 1-888-971-6225
available Monday-Friday 7:30 AM to 5:00 PM CST
(English-speaking operators)
Product Warranty is available at:
Hardware Included:
Wood Screw Pan Head Screw Leveler
Q444
QTY:4
Lock Washer
915000089
QTY:24
905000507
QTY:24
X5108
QTY:10
900000383
99000356, Page 1 of 2, Rev C, Rev Date 03-MAR-2021
Back Frame
Support
Front Frame
Support
Back Left Leg
Front Right Leg
Front Left Leg
Back Right Leg
Side Frame
Support (2)
Leg Support (2)
Side Frame
Support
Side Frame
Support
5272 Work Desk Shown
Leg Support
Leg Support
Front Right Leg
Back Right Leg
Side Frame
Support
Leg Support
Front Left Leg
Side Frame
Support
Leg Support
Back Left Leg
6
5
Attach Back Frame
Support to Right and
Left Leg
Sub-Assemblies from
Steps 2 and 4 using 4
Pan Head Screws and 4
Washers (ensuring
Washers are snug
against the head of the
screws).
Attach Front Frame
Support to Right and
Left Leg
Sub-Assemblies from
Steps 2 and 4 using 4
Pan Head Screws and 4
Washers (ensuring
Washers are snug
against the head of the
screws).
Attach Assembly from
Step 6 to the Desk Top
using 10 Wood Screws
into the 10 pilot holes in
the Desk Top. Screw 1
Leveler into each of the
4 Legs until tight
Turn Desk over and
ensure proper leveling by
adjusting the Levelers.
7
8
Work/Learn Desk # 5272/5273
Simple Collection™ Assembly Instructions
For questions or concerns, please call 1-888-971-6225
available Monday-Friday 7:30 AM to 5:00 PM CST
(English-speaking operators)
safcoproducts.com
Product Warranty is available at:
99000356, Page 2 of 2, Rev C, Rev Date 03-MAR-2021
5273 Learn
Desk Shown
Optional Power
Strip Cable Ties
Left Leg
Sub-Assembly
Left Leg
Sub-Assembly
Back Frame
Support
Front Frame
Support
Right Leg
Sub-Assembly
Right Leg
Sub-Assembly
Cable Pass-Through
Cable Management
Desk Top
Levelers (4)
Produktspecifikationer
| Varumärke: | Safco |
| Kategori: | Byrå |
| Modell: | 5272 |
