Sida 1/20
BSTV
1
INSTRUCTION MANUAL
We’ll Make It Stress-Free
If you have any questions along the way, just give us a call.
1-800-359-5520. We’re ready to help!
2
Before getting started, let’s make sure this mount is perfect for you!
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE
1
Does your TV weigh more than 60 lbs. (27.2 kg) including accessories?
No
—
Perfect!
Yes
—
This mount is NOT compatible. Visit sanus.com or call 1-800-359-5520 (UK: 0800-056-2853) to fi nd a compatible mount.
2 Do you have
the tools needed?
3 Ready to begin?
Please read through these instructions completely to be sure you’re comfortable with this easy install process. Also check your TV owner’s manual to
see if there are any special requirements for mounting your TV.
If you do not understand these instructions or have doubts about the safety of the installation, assembly or use of this product, contact Customer
Service at 1-800-359-5520.
CAUTION: Avoid potential personal injuries and property damage! Manufacturer is not responsible for damage or injury caused by incorrect
assembly or use.
WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to
make sure the combined weight of the BSTV1 and the display does not exceed 60 lbs (27.2 kg). Use with heavier televisions may result in instability
causing tip over resulting in death or serious injury!
WARNING: Use this mounting system only for its intended use as described in these instructions. Do not use attachments not recommended by
the manufacturer.
WARNING: Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed
on the furnishing may encourage a child to climb on the furnishing and as a result the furnishing may tip over onto the child.
WARNING: Relocating audio and/or video equipment to furniture not specifi cally designed to support audio and/or video equipment may result
in death or serious injury due to the furnishing collapsing or overturning onto a child.
NOTE: The BSTV1 can support screen sizes up to a maximum of 60" diagonal.
NOTE: The BSTV1 has no user serviceable parts.
60 lbs.
(27.2 kg)
Level Screwdriver
3
200mm
7.87 in.
100mm
3.94 in.
400mm
15.75 in.
75mm
2.95 in.
300mm
11.81 in.
600mm
23.62 in.
400mm
15.75 in.
300mm
11.81 in.
100
3.94 in.
200mm
7.87 in.
3deg ROLL
20deg 20deg
243.9mm
9.60 in.
5deg
UPTILT
519.7mm
20.46 in.
200mm
7.87 in.
HEIGHT
ADJUST
735.9mm
28.97 in.
685.8mm
27.00 in.
417.8mm
16.45 in.
TV INTERFACE
BASE PLATE
FULLY ASSEMBLED MOUNT
TOP VIEW - EXTENDED
TOP VIEW - RETRACTED
SIDE VIEW - EXTENDED
FRONT VIEW - HEIGHT ADJUST
3-D
Dimensions
