EFX AUDIO IS A DIVISION OF SCOSCHE INDUSTRIES, INC. ©2009 500c1/1000c1 02.09
500c1/1000c1
1-CHANNEL (MONO) AMPLIFIERS
INSTALLATION MANUAL
EFX AMPLIFIER FEATURES
500c1 SPECIFICATIONS
BEFORE YOU BEGIN:
Read all instructions and Cautions.
Disconnect Negative terminal of Vehicle battery.
Digital Multi-Meter
EFX Amplifier Wiring Kit, EFX REVOPAK4 is
recommended for these amplifiers.
Wire Strippers and Cutters
Drill and Drill Bits
Electrical Tape
Tools & Supplies
Installation procedures:
Plan your installation completely before beginning.
Be sure you have all materials needed to complete your installation.
Please call us with any questions before you start at:
Location/Mounting Amplifier
500c1
- 18dB Adjustable Full/Low Pass
- Electronic Crossover (40Hz~400Hz)
- 2-Ohm Load Capability
1000c1
- 18dB Adjustable Low Pass
- Electronic Crossover (40Hz~200Hz)
- 1-Ohm Load Capability
- Strapable
Power Output: 350 Watts RMS x 1 Channel at 4 Ohms and 1% THD+N
Signal to Noise Ratio: >80 dBA (reference:1 Watt into 4 Ohms)
Additional Power Output: 500 Watts RMS x 1 Channels at 2 Ohms at 1% THD+N
Frequency Response: 20Hz -20kHz (-3dB)
Maximum Input Signal: 6V (Low Level) / 10V (High Level
Minimum Input Signal: 200mV (Low Level) / 420mV (High Level)
1000c1 SPECIFICATIONS
Power Output: 350 Watts RMS x 1 Channel at 4 Ohms and 1% THD+N
Signal to Noise Ratio: >80 dBA (reference:1 Watt into 4 Ohms)
Additional Power Output: 500 Watts RMS x 1 Channels at 2 Ohms at 1% THD+N
1000 Watts RMS x 1 Channels at 1 Ohms at 1% THD+N
Frequency Response: 20Hz -200Hz (-3dB)
Maximum Input Signal: 6V (Low Level) / 10V (High Level)
Minimum Input Signal: 200mV (Low Level) / 420mV (High Level)
- 0-12dB Variable 45Hz Bass Boost
- RCA Line Level Output Loop-Thru
- Line Level & Speaker Level Inputs
- Soft Start Turn-on/off
- 5-Way Protection (Thermal, Short Circuit,
Impedance, Voltage, Reverse Polarity)
- MOSFET Power Switching Transistors
- Brushed Aluminum Heatsink and Top Plate
- Sturdy Aluminum Side Panels
- Illuminated Logo Badge
IMPORTANT/ PRELIMINARY
Select a safe/dry location to mount your Amplifier. Double check location and placement of
your amplifier before making any connections or drilling any holes. Never mount your Amplifier
in the engine compartment, or cover it with carpet or any other fabric materials that will cause
the Amplifier not to get the proper ventilation. Avoid drilling through electrical wires, fuel lines,
or other obstructions that may be around your mounting area. If you have any questions or
concerns, please contact our tech support team at 1-800-621-3695 Ext. 3
IMPORTANT/ PRELIMINARY
ROUTING CABLES AND WIRES
Determine the safest place to run wires through firewall. If it is necessary to drill holes be sure
area is free of any obstructions on either side. Always use a grommet to protect wire.
Be sure to route all wires and cables away from parts that may move or become hot. Excessive
heat will damage the amplifier and wiring. Route power wires away from signal (RCA) cables. If
power wires and signal cables need to intersect cross at a 90% angle. Route RCA cables away
from wires that may carry high current.
WARNING: MAKE SURE YOU CHECK TWICE. DRILLING THROUGH ANY ELECTRICAL
WIRES, FUEL LINES OR ANY OTHER VEHICLE SYSTEMS MAY CAUSE INJURY OR
DEATH.
AMPLIFIER STATUS INDICATOR
LED STATUS INDICATOR
ON
PROT
ON
PROT
POWER: GREEN The LED will illuminate in while amplifier is on.
POWER PROTECT: RED The LED will illuminate in to indicate the Amp is in "Protect Mode",
This may be due to an overload or circuit problem (See page 7-8 for trouble shooting tips).
- 2 -
MONO HI GH PO WER CLA SS-D AM PL IFIER
ON
PROT
GND
POWER
B REM PHASE HI INPUT
GND
L R
REMOTE
MASTER/SLAVE
SLAVE MASTER
LEVEL
MAXMIN
BASS
12dB0dB
LOW PASS
200Hz40Hz0 180
IN
OUT
L
R
L
R
LOW
INPUT
LINE
OUTPUT
SPEAKER
AMPLIFIER ADJUSTMENTS
Level:
The Level Adjust Control (Gain) matches the output of your Car Stereo to the
inputs on the Amplifier.
1. Turn Stereo on and adjust the volume to about 3/4’s of the stereo’s
maximum volume.
2. Carefully turn the Level control up (by turning it clockwise from the "Min"
position) on the Amp until the sound is just above your normal listening
volume or near distortion. (Distortion is when the sound/ music becomes
garbled, breaks up, or unclear).
4. If there is excessive HUM or HISS between songs, the levels are set TOO
HIGH and should be turned down, (reverse towards "Min").
Low Level Inputs:
Low Level (RCA) inputs. Using the Low Level output from your car stereo is
recommended (if available). If no Low Level Outputs are available from
your car stereo, please see the HIGH LEVEL INPUT on page 6.
Low Level Outputs:
The Line Level Output is to be used as an easy solution to link multiple
amplifiers together without the use of RCA Y-cables or running extra RCA
cables from the front of the vehicle to the rear amplifier location.
Bass Boost:
Adjustable Bass Boost (0~ +12dB @ 45Hz)
Use Caution while adjusting Bass Boost. Using to high of a setting may
cause distortion or damage Speakers.
MIN MAX
0dB 12dB
- 3 -
PHASE
REMOTE
MASTER/SLAVE
0 180
IN
OUT
L
R
L
R
LOW PASS
200Hz40HzFULL
GND
L R
HI INPUT
Use the High Level input harness if you are connecting your amplifier to a
Factory Stereo or a Stereo that does not have any available Low-Level (RCA)
outputs. Connect Left and Right Speaker outputs from the vehicle to the Left
and Right High Level input wires.
High Input Harness:
Low Pass Filter:
Remote Level Control:
Master/ Slave In and Outputs:
Phase Level:
Plug the cable into the REM connector on the amplifier and into the controller.
This will allow you to adjust the level of your amplifier while in low filter mode
from the crossover frequency and below.
Use the Low Pass filter when you want to Filter out high frequencies.
Set the switch to Low Pass and adjust the level to the desired frequency.
The Master and Slave settings on the 1000c1 allow you to “Strap” or
compound (2) amplifiers to a drive a Single voice coil based on your specific
needs and power requirements. The default setting is for Master. If you
choose to Slave a second amp, please see page 6.
Adjusts the relative phase of the output in a range of 0 to - 180 degrees.
