MULTI-PLATFORM STEREO REPLACEMENT
WITH STEERING WHEEL CONTROL INTERFACE
FOR CHRYSLER, GM, FORD & TOYOTA JBL
©2011 SCOSCHE INDUSTRIES, INC. SI - S3-1 (3000553) 6/11
S3CR02 2005-10 Select Chrysler S3-1 harness
S3CR04 2007-UP Select Chrysler S3-1 harness
S3FD23 2005-UP Select Ford, Linc, Merc S3-1 harness
S3GMCL2 2003-UP Select GM Class II S3-1 harness
S3GM11C 2004-UP Select GM LAN11 24Pin S3-1 harness
S3GM11L 2006-UP Select GM LAN11 14/16Pin S3-1 harness
S3GMLAN 2006-UP Select GM LAN29 14/16 Pin S3-1 harness
S3TA03 2004-UP Select Toyota JBL S3-1 harness
STEERING WHEEL CONTROLS
The cutting edge interface from Scosche allows you to replace your S3-1
factory OEM stereo while retaining all necessary safety & warning features as
well as retaining your original steering wheels controls (if vehicle is equipped).
NO Steering wheel programming is required! The Interface has S3-1
built-in protocols for popular aftermarket stereos including:
ALPINE CLARION JVC
KENWOOD PIONEER SONY
S3-1 INSTALLATION HARNESSES*
A vehicle-specific harness is required for installing the interface (*sold separately).S3-1
Verify your vehicle’s compatability by checking the list included with vehicle-specific
harness.
If you have any questions or need
Technical Assistance with the installation, or the most
current applications, please call
1-800-621-3695x3
TECH SUPPORT:
Chrysler Not required No
Ford Not required No
GM LAN Std. Bose only
GM Class II Std. Bose only
Toyota Not required Not required JBL Sys only No
3.5MM STEERING
WHEEL OUTPUT
(Alpine, Clarion,
JVC, Pioneer, Sony)
Make
PRELIMINARY
2
COMPONENT OVERVIEW
S3-1 Functionality by vehicle platForm:
ACC/R.A.P.
Power
Steering
Wheel
Controls
Warning
Chimes
Premium
Sound
Activation
Fade F/R
beFore beGinninG: READ THIS INSTRUCTION MANUAL
!
Disconnect the negative battery terminal to avoid short circuits. Read ALL
vehicle manufacturer’s warnings regarding airbags and electrical systems.
We recommend ONLY a volt/ohm meter when checking/testing vehicle
wiring. A test light (grounded probe type) can damage a vehicle’s computer
and/or electronics systems.
STEERING WHEEL
CONTROL MODULE
S3-1 INTERFACE
MODULE
BLUE STEERING
WHEEL OUTPUT
(Kenwood)
3
3.5MM STEERING WHEEL
OUTPUT CABLE
(Alpine, Clarion, JVC,
Pioneer, Sony)
BLUE STEERING WHEEL
OUTPUT WIRE (Kenwood)
INSTALLATION OVERVIEW
S3-1 VEHICLE-SPECIFIC
WIRE HARNESS
(sold separately for
Chrysler, Ford,
GM, Toyota)
TO VEHICLE
S3-1 MAIN
MODULE
STEERING
WHEEL
MODULE
AFTERMARKET
STEREO
