INTRODUCTION / PRELIMINARY
IN-DASH INSTALLATION KIT FOR
2006-UP KIA SEDONA
If you have any further questions call: TECH HELP 1-800-621-3695x3
©2006 SCOSCHE INDUSTRIES, INC. KA2072 5/06 (3000003)
KA2072
LIABILITY DISCLAIMER
This instruction booklet is based on carefully documented data and research of automobile dash disassembly, wire harness/codes
and information pertaining to installation of this kit in the listed vehicles. Manufacturer cannot be held responsible for discrepancies/
inconsistencies that may occur due to the automobile manufacturing changes or options, or damage that may occur in the
automobile during the installation of components while using this booklet.
Thank you for purchasing the Scosche KA2072 Kit. This Kit was manufactured with the highest of quality
standards.
CAUTION: DISCONNECT YOUR VEHICLE'S NEGATIVE BATTERY TERMINAL BEFORE THE
INSTALLATION TO HELP PREVENT ELECTRICAL DAMAGE. WE RECOMMEND THE USE OF A
VOLT/OHM METER OVER A TEST LIGHT TO CHECK WIRING. A TEST LIGHT OR GROUNDED WIRE
PROBE CAN CAUSE DAMAGE TO THE VEHICLE'S COMPUTER AND/OR DIAGNOSTIC SYSTEMS.
AVOID ALL FACTORY AIR BAG WIRING - AIR BAGS CAN ACCIDENTALLY DEPLOY CAUSING
SERIOUS INJURY OR DEATH.
NOTES:
• See your vehicle's instructions for any special tools your installation might require.
• Read all instructions accompanying your car stereo/cassette player for proper wiring and mounting
instructions.
2006-Up Kia Sedona
RADIO REMOVAL:
1. Using a panel removal tool, extract the bezel surrounding the shifter.
2. Using a panel removal tool, unsnap the dash bezel surrounding the radio.
3. Extract (1) Phillips head screw securing EACH air vent panel.
4. Using apanel removal tool, unsnap and remove air vent panels.
5. Extract (4) Phillips head screws securing factory A/C control panel.
6. Extract (4) Phillips head screws securing radio to dash.
VEHICLE DISASSEMBLY
KA2072
ASSEMBLED
MOUNTING
PANEL
FACTORY WIRING CODES
CAR STEREO CONNECTORS
PROVIDE EASY CONNECTION OF YOUR CAR
STEREO TO FACTORY WIRING HARNESS.
HY07B
2006-Up Hyundai Accent and Azera;
2005-Up Kia Sportage
6084
TRIM
RING
MOUNTING THE RADIO
2
6084
TRIM
RING
DIN MOUNT
RADIO
RADIO’S
MOUNTING
SLEEVE
VARIOUS REAR
SUPPORTS
BEND TABS
OUTWARD
KA2072
ASSEMBLED
MOUNTING
PANEL
DIN MOUNT
1. Slide DIN sleeve into kit from front.
2. Bend tabs to secure DIN sleeve to panel.
3. Slide radio into DIN sleeve until snaps into place.
DIN MOUNT
NOTE:
REAR SUPPORT AVAILABLE
SEPARATELY. REAR
SUPPORTING THE RADIO
ADDS TO THE INSTALLATION’S
STRUCTURAL INTEGRITY.
