© 2007 SCOSCHE INDUSTRIES, INC. SI 04/07 - TA2077B (3000003)
If you have any further questions, call our toll free technical help line at: 1-800-621-3695x3
TA2077B
IN-DASH DIN RADIO INSTALLATION KIT FOR
2007 TOYOTA YARIS
(STANDARD RADIOS 3-DR, 4-DR)
LIABILITY DISCLAIMER
This instruction booklet is based on carefully documented data and research of automobile dash disassembly, wire harness/
codes and information pertaining to installation of this kit (TA2077B) in 2007 Toyota Yaris Vehicles. Scosche Industries, Inc. can
not be held responsible for discrepancies/inconsistencies that may occur due to the automobile manufacturing changes or
options, or damage that may occur in the automobile during the installation of components while using this booklet.
INTRODUCTION / PRELIMINARY
2
For Factory Wiring Codes go to: www.scosche-cars.com
FACTORY WIRING CODES
CAR STEREO CONNECTORS
PROVIDE EASY CONNECTION OF YOUR CAR
STEREO TO FACTORY WIRING HARNESS.
TA02
1987-UP Toyota
VEHICLE DISASSEMBLY
2007 TOYOTA YARIS (3-DR & 4-DR)
Radio Removal
1. Using a panel removal tool, remove the trim panel below the HVAC controls.
2. Using a panel removal tool, remove the trim panels on each side of the radio and HVAC controls.
3. Using a panel removal tool, remove the instrument clusters trim bezel.
4. Using a panel removal tool, remove the trim bezel surrounding the radio. Disconnect and remove.
5. Extract (4) 5/15" bolts securing the radio to the dash. Disconnect and remove.
This premium installation kit is for 2007 Toyota Yaris vehicles. Included are all the parts you need to
mount your car stereo/cassette or CD player into your vehicle's dash. Refer to the individual
instruction in this manual to remove your vehicle's factory radio and assemble the kit.
CAUTION:
DISCONNECT YOUR VEHICLE'S NEGATIVE BATTERY TERMINAL BEFORE THE INSTALLATION TO HELP
PREVENT ELECTRICAL DAMAGE. WE RECOMMEND THE USE OF A VOLT/OHN METER OVER A TEST LIGHT
TO CHECK WIRING. A TEST LIGHT OR GROUNDED WIRE PROBE CAN CAUSE DAMAGE TO THE VEHICLE'S
COMPUTER AND/OR DIAGNOSTIC SYSTEMS. AVOID ALL FACTORY AIRBAG WIRING - AIRBAGS CAN
ACCIDENTALLY DEPLOY CAUSING SERIOUS INJURY OR DEATH.
NOTES:
• See your vehicle's instructions for any special tools your installation might require.
• Read all instructions accompanying your car stereo/cassette player for proper wiring and mounting
instructions.
6159
MOUNTING
PANEL
6161L
MOUNTING
BRACKET
6160
TRIM
RING
6161R
MOUNTING
BRACKET
MOUNTING THE RADIO
DIN-ISO MOUNT
1. For Toyota Yaris 3-Door vehicle, use 6299L/R mounting brackets. For Toyota Yaris 4-Door vehicle,
use 6161R/L mounting brackets. The TA2077B is not for premium factory radios, only standard
radios.
2. Align right side ISO mounting bracket (6161R or 6299R) and left side ISO mounting bracket (6161L
or 6299L) with kit panel (6159). Place mounting brackets with matching locating wedges on kit panel
(two locating holes on each side).
3. Align ISO DIN radio. Use hardware supplied with radio to bolt the 6159 mounting brackets.
RADIO
TA2077
ASSEMBLED
PANEL
6160
TRIM
RING
6299R
MOUNTING
BRACKET
6299L
MOUNTING
BRACKET
6299R
MOUNTING
BRACKET
6299L
MOUNTING
BRACKET
