© 2003 SCOSCHE INDUSTRIES, INC. SI 10/03 - NN1499 (3000003)
If you have any further questions, call our toll free technical help line at: 1-800-621-3695x3
NN1499
IN-DASH INSTALLATION KIT FOR
2003-UP NISSAN PATHFINDER LE
2003-UP INFINITI QX4
LIABILITY DISCLAIMER
This instruction booklet is based on carefully documented data and research of automobile dash
disassembly, wire harness/codes and information pertaining to installation of this kit (NN1499).
Scosche Industries, Inc. can not be held responsible for discrepancies/inconsistencies that may
occur due to the automobile manufacturing changes or options, or damage that may occur in the
automobile during the installation of components while using this booklet.
For Factory Wiring Codes go to: www.scosche-cars.com
FACTORY WIRING CODES
Thank you for purchasing the Scosche NN1499 Kit. This kit was manufactured with the highest of quality
standards.
CAUTION:
Disconnect your vehicle's negative battery terminal before the installation to help prevent electrical
damage. We recommend the use of a volt/ohm meter over a test light to check wiring. A test light or
grounded wire probe can cause damage to the vehicle's computer and/or diagnostic systems. Avoid all
factory air bag wiring - air bags can accidentally deploy causing serious injury or death.
NOTES:
•See your vehicle's instructions for any special tools your installation might require.
•Read all instructions accompanying your car stereo/cassette player for proper wiring and mounting
instructions.
INTRODUCTION / PRELIMINARY
A. ATTACHING THE REAR
BRACKET:
Align the two (2) screw emboss
locations to the matching locations
on pocket. When aligned, slide the
bracket together. Screw the two (2)
supplied screws to screw emboss
locations
B. ATTACHING THE POCKET:
Align the pocket to the snaps of kit
panel. Snap the pocket into place
on the back of kit panel.
RADIO REMOVAL
Note: The factory radio provision is for a Double DIN sized radio.
1. Using panel removal tool pop out vent panel, disconnect and remove. Remove two (2) Philips head
screws from behind.
2. Using panel removal tool pop out radio bezel, disconnect and remove.
3. Remove four (4) Philips head screws from radio bracket, disconnect and remove radio.
5481
MOUNTING KIT PANEL
5125 POCKET
5324
REAR MOUNTING
SUPPORT BRACKET
POCKET ASSEMBLY
STEREO INSTALLATION
MOUNTING THE RADIO
CAUTION:
REAR SUPPORTING THE
RADIO ADDS TO THE
INSTALLATIONS
STRUCTURAL INTEGRITY.
5482
TRIM RING
5125 POCKET
5481
MOUNTING PANEL
5324
REAR MOUNTING
SUPPORT
5481
MOUNTING
KIT PANEL
5324
REAR MOUNTING
SUPPORT
BRACKET
DIN
MOUNT
RADIO
RADIO’S
MOUNTING
SLEEVE
BEND
TABS
OUTWARD
5482
TRIM RING
