TTTTTA2051A2051A2051A2051A2051
2004 TOYOTA SIENNA KIT
SI 10/04 - TA2051 (3000003)
If you have any further questions call: TECH HELP 1-800-621-3695x3
For Factory Wiring Codes go to: www.scosche-cars.com or call.
Thank you for purchasing the Scosche TA2051 Kit. This kit was manufactured with the highest of quality
standards.
NOTES:
•See your vehicle's instructions for any special tools your installation might require.
•Read all instructions accompanying your car stereo/cassette player for proper wiring and mounting instructions.
LIABILITY DISCLAIMER
This instruction booklet is based on carefully documented data and research of automobile dash
disassembly, wire harness/codes and information pertaining to installation of this kit in the listed vehicles.
Manufacturer cannot be held responsible for discrepancies/inconsistencies that may occur due to the
automobile manufacturing changes or options, or damage that may occur in the automobile during the
installation of components while using this booklet.
© 2004 SCOSCHE INDUSTRIES, INC.
WIRE CODES
2004 TOYOTA SIENNA
RADIO REMOVAL AND IN-DASH INSTALLATION
1. Carefully unsnap and remove trim panels from left and right of radio. Unplug and remove.
2. Carefully pry up on trim panel at top of radio. Unsnap and remove.
3. Remove (4) bolts securing factory radio. Unplug and remove.
INTRODUCTION / PRELIMINARY
VEHICLE DISASSEMBLY
5509
MOUNTING
PANEL
DIN
MOUNT
RADIO
5510 RIGHT
MOUNTING
BRACKET
5510 LEFT
MOUNTING
BRACKET
A. ATTACHING MOUNTING BRACKETS (FRONT):
Align the (2) "L" wedges with location openings on the kit
panel. Pressure fit, push into locations unit in place.
B. ATTACHING MOUNTING BRACKETS (BACK):
Align mounting hole of mounting bracket with hole locator
on pocket slide bracket on hole locator on pocket.
MOUNTING BRACKETS ASSEMBLY
TTTTTA2051A2051A2051A2051A2051
2004 TOYOTA SIENNA KIT
SI 10/04 - TA2051 (3000003)
If you have any further questions call: TECH HELP 1-800-621-3695x3
For Factory Wiring Codes go to: www.scosche-cars.com or call.
Thank you for purchasing the Scosche TA2051 Kit. This kit was manufactured with the highest of quality
standards.
NOTES:
•See your vehicle's instructions for any special tools your installation might require.
•Read all instructions accompanying your car stereo/cassette player for proper wiring and mounting instructions.
LIABILITY DISCLAIMER
This instruction booklet is based on carefully documented data and research of automobile dash
disassembly, wire harness/codes and information pertaining to installation of this kit in the listed vehicles.
Manufacturer cannot be held responsible for discrepancies/inconsistencies that may occur due to the
automobile manufacturing changes or options, or damage that may occur in the automobile during the
installation of components while using this booklet.
© 2004 SCOSCHE INDUSTRIES, INC.
WIRE CODES
2004 TOYOTA SIENNA
RADIO REMOVAL AND IN-DASH INSTALLATION
1. Carefully unsnap and remove trim panels from left and right of radio. Unplug and remove.
2. Carefully pry up on trim panel at top of radio. Unsnap and remove.
3. Remove (4) bolts securing factory radio. Unplug and remove.
INTRODUCTION / PRELIMINARY
VEHICLE DISASSEMBLY
5509
MOUNTING
PANEL
DIN
MOUNT
RADIO
5510 RIGHT
MOUNTING
BRACKET
5510 LEFT
MOUNTING
BRACKET
A. ATTACHING MOUNTING BRACKETS (FRONT):
Align the (2) "L" wedges with location openings on the kit
panel. Pressure fit, push into locations unit in place.
B. ATTACHING MOUNTING BRACKETS (BACK):
Align mounting hole of mounting bracket with hole locator
on pocket slide bracket on hole locator on pocket.
MOUNTING BRACKETS ASSEMBLY
