AIR 2
ALTERNATE
INFLATOR
REGULATOR
U.S. PATENT 4.227.521
& WORLDWIDE PATENTS
®
Air2_2009_pagine.qxd:Air2_2005_pagine.qxd 2-12-2009 8:55 Pagina 1
AIR 2
Alternate Inflator Regulator
21 08X 000
IMPORTANT NOTICE: certified diving instruction
should be obtained before using this item
Patented by SCUBAPRO, the AIR 2 is an absolute innovation
in backup regulator design.
It is a combined quick disconnect, inflation/deflation device
for precise buoyancy control plus a reliable demand regulator
for backup emergency breathing. A quick disconnect low
pressure hose is supplied that will connect to most standard
first stage regulators.
WARNING (see figure)
Install the quick disconnect hose into the auxiliary low
pressure outlet of the first stage regulator. Be careful on
most regulators, the high pressure and low pressure outlets
have the same thread and are plugged with a similar plug.
On the contrary on all SCUBAPRO regulators these outlets
are clearly different.
DESIGN PHILOSOPHY
A complete diving gear should consist of a primary regulator,
an emergency regulator and a buoyancy device. SCUBAPRO
AIR 2 provides both function of breathing and buoyancy
control. Housed in one compact, lightweight package, AIR 2
incorporates a push button inflator/deflator that can be used
with one hand for automatic or oral inflation.
LOCATION
Fumbling and/or hunting for the backup regulator during an
emergency wastes precious seconds. The location of the
AIR 2 is always the same. It is engineered for lefthand use
and is positioned at the end of the buoyancy compensator
hose. Because of the mounting design, the mouthpiece is
always facing the diver in perfect alignment for instant use.
2
Air2_2009_pagine.qxd:Air2_2005_pagine.qxd 2-12-2009 8:55 Pagina 2
APPLICATION DEPENDABILITY
The problems associated with the accumulation of sand,
gravel, and foreign matter inside the backup regulator have
been solved in the design of the AIR 2 in two ways. First,
because the AIR 2 is attached to the shorter buoyancy
control hose is less likely to drag on the bottom. Second,
constant flushing action partially eliminates the problem of
debris accumulation.
THE QUICK DISCONNECT COUPLING
The quick disconnect coupling can be connected with or
without pressure in the hose because of an automatic check
valve in the hose end of the coupling which prevents
leakage of air when disconnected.
OPERATION
Normal Operating Mode - Push button or oral inflation/
deflation. When properly installed to the left hand shoulder of
the buoyancy device, the AIR 2 can be fully operated with the
left hand by depressing the buttons for inflation or deflation.
These two buttons are offset and are different sizes for easy
identification. The smaller button is depressed for automatic
inflation. The larger button is depressed for deflation. For oral
inflation, only the large deflation button is used. To inflate, the
diver seals his lips on the mouthpiece, depresses the deflation
button fully, then exhales into the mouthpiece and releases the
button to capture the exhaled air.
CAUTIONS
In buoyancy devices equipped with CO2(carbon dioxide)
detonators, the possibility exists under a certain set of
circumstances that CO2could be inhaled from the device. If
CO2has been detonated, do not depress the deflation button
with the unit in the mouth or attempt to further inflate the device
orally. Doing so would release CO2into the mouth, and it could
possibly be inhaled. Flush the buoyancy device thoroughly
with air or fresh water before reuse; the presence of CO2from
a detonated cartridge should be readily noticeable because it
is distastefully flavored and odored.
3
AIR 2 - ALTERNATIVE INFLATOR REGULATOR
Air2_2009_pagine.qxd:Air2_2005_pagine.qxd 2-12-2009 8:55 Pagina 3
