NEOM USB

U s e r M a n u a l

User Manual - EN

Thank you

Thank you for choosing an sE microphone! In addition to some basic safety precautions, this manual includes

details and specifications to help you get the most out of your NEOM USB. Please take a few minutes to read

through it.

Capturing excellent audio is our passion. We sincerely hope you’ll enjoy the sound of this mic as much as

we’ve enjoyed designing and building it for you.

Happy Tracking,

The sE Team

Brief Description

The NEOM USB USB is a condenser microphone, similar to our celebrated X1 A studio mic. Condenser mic

capsules capture sound in a very detailed and vivid way, making them perfect for recording voices as well as

instruments. The NEOM USB has a “cardioid” polar pattern, which means that it picks up sound mainly from

the front, and less from the sides and rear. The capsule is built into an internal shock mount system, helping

to keep the sound free from rumble.

USB microphones have built-in audio interfaces, which is what separates them from analog microphones. The

NEOM USB’s -audio system allows you to record at resolutions up to 192 kHz at 24 bits. However, that

maximum resolution creates very large audio files, which can be a drain on hard drive space. We recommend

using 48 kHz at bits for most applications. -24

All sE products are designed to be professional grade, and the NEOM USB is no exception! The desktop mic

stand is made of metal, rather than plastic, and is equipped with rubber feet to minimize any vibration. The

mic clip can also be twisted off (counter- - clockwise) for use on a full size mic stand. Additionally, the NEOM

USB can be used with sE’s Isolation Pack, which includes a studio shock mount and a metal pop filter.

What’s in the B ? ox

• NEOM USB microphone

• Desktop microphone stand

• Microphone clip

• thread adapter

• USB- - C to USB A cable

Using the Microphone

The NEOM USB -is straightforward and user friendly. Once you’ve plugged it into your mobile device or

computer’s USB input, there’s not much more to do!

Mic Gain

The Mic Gain knob adjusts how loudly the microphone captures sound. As you

turn this knob up, the halo LED around it will light up green to show that it’s

hearing you. If the halo LED turns red, that means you’ve turned it up a bit too

loud in the audio, and you may hear distortion . Back it off by 10 - 15% or until it

doesn’t flash red anymore.

Mute Button

The sE logo is also a Mute Button. You can use this as needed when you don’t

want the mic to send audio to your computer. The button flashes in red when

the sound is muted. If you’re having trouble recording audio with your NEOM

USB, make sure the Mute Button is off.

Headphone Output

The 1/8” Headphone Output -is in the back right corner, at the bottom of the mic.

Much of the time, if your headphones are plugged into the computer, you will hear

a distracting delay called “latency.” By plugging your headphones directly into the

microphone, you can avoid that.

Mic Level and Playback Level Knobs

The NEOM USB’s Mic Level and Playback Level knobs allow you set up a custom

headphone mix, balancing the playback from your computer with the sound being

captured by the microphone. We set out to make this process effortless, so rather

than having to tweak software drivers, everything is easily accessible on the front

of the mic! Adjust the Playback Level knob to a comfortable volume, then bring the

Mic Level knob up until you can comfortably hear yourself.

Best Practices

The NEOM USB -is a side address microphone, meaning that the sound is captured by the surface just above

its controls, rather than the top of the mic. Ideally, when singing or speaking, place yourself about 6 inches -

from the microphone. We recommend using a pop filter when recording vocals, for the cleanest possible

audio. For each new source, even if it’s two different singers, make sure to readjust the Mic Gain knob. This

will ensure that you are recording at adequate levels, and more importantly, not experiencing distortion.

Compatibility and Software

The NEOM USB can be used with Windows and Mac systems, as well as both portable Apple and Android

devices. It comes complete with a USB- -C to USB A cable which can be used for devices equipped with an

USB- - - -A port. For connecting to a device with an USB C port you can use a USB C to USB C cable. For other

ports please use a suitable cable or adapter, - , i.e. micro USB or Lightning .

Although no driver is required, we recommend that Windows users install our custom ASIO driver in order to

get the best out of the ; , NEOM USB including advanced control options, a virtual mixer and virtual channels.

This . driver available on our website, www.seelectronics.com

Produktspecifikationer

Varumärke:	SE Electronics
Kategori:	mikrofon
Modell:	NEOM USB
Färg på produkten:	Roestvrijstaal
Höjd:	229 mm
Snäll:	Microfoon voor instrumenten
Anslutningsteknik:	Bedraad
Diameter:	22 mm
Förbindelse:	XLR-3
Stroomverbruik:	10 mA
Mikrofonriktningstyp:	Omnidirectioneel
Mikrofonkänslighet:	-29 dB
Mikrofonfrekvens:	3 - 50000 Hz
Mikrofoningångsimpedans:	65 Ohm
XLR ut:	1
Antal-produkter-ingår:	2 stuk(s)
Maximal ljudtrycksnivå (1 kHz):	140 dB
Mikrofonens vikt:	225 g
Känslighet (1 kHz):	34 mV/Pa
Skrämmande kraft:	24 - 48 V
Motsvarande ljudnivå:	20 dB
Inkluderar klämma:	Ja
