VR1 VR2

U s e r M a n u a l

User Manual - EN

Thank you

We would like to thank you cordially for choosing this sE microphone! This manual contains some

important instructions for setting up and operating your new equipment. Please take a few minutes

to read the instructions below carefully. We hope you will enjoy working with it as much as we

enjoyed designing and building it for you.

Most Sincerely,

Your sE Team

Brief Description

The VR1 and VR2 ribbon microphones mark a new era in ribbon technology. Whereas most ribbon

microphones have a dark, muted high-frequency response, the VR1 and VR2 utilize a clever

mechanical device to achieve nearly full-range frequency response that extends well beyond that of

most other ribbon microphones, approaching nearly 20kHz. This provides an extended level of top-

end detail, so the result includes not only the distinctly natural low end and midrange that most -

ribbons provide, but also minimal loss in high frequency content. Guitar and brass tones retain their

“edge”, cymbals still sound rich and full, and a supremely natural sound is achieved from top to

bottom.

Additionally, the VR1 and VR2 can handle very high sound pressure levels and thus can be utilized

for applications not normally considered for most ribbon microphones, including loud brass, drums,

and electric guitar cabinets both in the studio and on stage.,

The VR1 is a passive ribbon, so it does not require phantom power – -though it is “phantom

protected”, so it will not be damaged by accidental application of phantom power. Given its lower

output, it is ideally suited for loud sources such as electric guitars, drum overheads, and brass.

The VR2 is an active ribbon and requires +48V phantom power for operation. higher sensitivity With

than the VR1, it is ideally suited for applications including acoustic instruments, piano, and vocals,

as well as the same sources as the VR1 (guitars, drums, brass).

What’s in the box

Your packaging should contain the follow items. If anything is missing, please contact your sE

Electronics dealer and let them know.

• VR1 / VR2 microphone

• m icrophone stand clip

• t t hread adap er

• wooden case

• shock mount

Powering - VR2 ONLY

To ensure proper operation, the VR2 microphone requires a phantom power source providing 48

Volts according to IEC 61938.

Risk of damage

Do not connect the VR2 microphone to any power supply other than a

phantom power source (input with phantom power or external IEC

standard phantom power supply) with a floating connector, using a

balanced cable with studio grade connectors to IEC 268-12 only. This is

the only way to ensure safe and reliable operation.

Note: The VR1 is a passive ribbon microphone and does not require phantom power for

operation.

Safety and maintenance

Risk of damage

Please make sure that the piece of equipment to which your microphone

will be connected fulfils the safety regulations enforced in your country

and is fitted with a ground lead.

Cleaning icrophone the m

After every use, clean the microphone with a dry, soft cloth tissue and store it in a solid case or a

zipper pouch.

Technical Specifications

VR1

VR2

Electronics

Passive

Active

Transducer

Hand-tensioned 2.5µm aluminum ribbon

Magnet

Neodymium

Polar Pattern

Figure-8

Frequency Range

20 18,000 Hz–

Sensitivity

1.78 mV/Pa ( 55 dB)-

14.1 mV/Pa ( 37- dB)

Electrical Impedance

300 Ohms

200 Ohms

Recommended Load

Impedance

>1k Ohms

Max SPL

135 dB (0.5% THD @ 1kHz)

Equivalent Noise Level

18 dB(A)

Dynamic Range

117 dB

Signal to Noise Ratio

76 dB
