Sida 1/30
Product Manual
CE.00.0070.81-A
骑行前请务必下载并安装 Segway-Ninebot
APP，以激活您的滑板车。
如需了解更多信息，请登录 www.segway.com 。
赛格威有权对产品及其固件、说明书进行更新。
图片仅供参考，图片与实际产品可能不同，请以实际产品为准。
扫描二维码下载Segway-Ninebot
app
Diagram and Functions
Handlebar Functions
Handlebar
Stem
Rear Fender
Rear Disc Brake
Rear Hub Motor
Battery Pack
Kickstand
Rear Turn Signal
Rear Brake Lever
Left Turn Signal
Dashboard
Front Brake Lever
Headlight
Right Turn Signal
Quick Release Lever
Front Fork
Front Reflector
Front Shock
Absorber
Front Fender
Front Hub Motor
* For GT2 only
Front Wheel
Front Disc Brake
Folding Mechanism
Safety Button
Horn
Daytime Running Light (DRL)
Side Reflector
Footboard
Charging Port
Ambient Light
Left Control Switch
Rear Shock
Absorber
Right Control Switch
Power Button
Throttle
Horn Button
Turn Signal Button
Taillight &
Brake Light &
Rear Reflector
Power Button
Name Function Operation method
Press the Power Button to power on the scooter. Press and hold to power it off. Note: Only available when
the scooter is unlocked.
Press the Power Button to wake up the screen when the screen automatically dims.
When the scooter automatically enters PARK mode, press the Power Button to go back to the previous
speed mode.
While connecting to the scooter via the Segway-Ninebot app, press the Power Button to confirm Bluetooth
password.
Power on/off
Wake up the screen
Back to the previous
speed mode
Confirm Bluetooth
password
Press the left/right side of the Turn Signal Button, the left/right turn signal will turn off after three blinks.
press and hold the left/right side of the Turn Signal Button, the left/right turn signal will keep blinking until
it is released.
Throttle Twist the throttle to speed up.
Press the Horn Button, the scooter will beep once.
1) Press the Right Control Switch to activate the BOOST mode. 2) Press again or * In RACE mode only.
switch the speed mode to turn it off. * For GT2 only.
Left Control
Switch
Right Control
Switch
Turn Signal
Button
Turn on/off the headlight Rotate the Left Control Switch clockwise/counterclockwise to turn off/on the headlight.
Turn on/off the cruise
mode
Switch between 1WD
and 2WD
Press the Left Control Switch to turn on the cruise mode, and the scooter will cruise at a constant speed.
Press again to turn it off.
When the scooter is at a complete stop, press and hold the Left Control Switch to switch between 1WD and
2WD. * For GT2 only.
Rotate clockwise/counterclockwise to switch between speed modes.Mode switching
Activate the BOOST mode
Switch to WALK mode
For GT1: When the scooter is at a complete stop, press the Right Control Switch to switch to WALK mode.
At this point, press the Right Control Switch again to go back to the previous speed mode.
For GT2: When the scooter is at a complete stop, press and hold the Right Control Switch to switch to
WALK mode. At this point, press and hold the Right Control Switch again to go back to the previous speed
mode.
Speed up
Turn on the hornHorn Button
Turn on/off the left/right
signal
1
EN EN
01 02
1) With two-wheel drive, SDTC feature is auto-on in non-RACE modes.
Note: This feature helps prevent wheel slippage and maintain stability when
accelerating.
2) With one-wheel drive, SDTC feature is auto-off in RACE mode.
Dashboard
POWER Progress Bar
Cruise Mode
Bluetooth
Speedometer
BOOST Progress Bar
Warning
Warning
PARK Mode
ECO Mode
POWER Progress Bar
SPORT Mode
RACE Mode
PARK Mode
ECO Mode
SPORT Mode
RACE Mode
Bluetooth
WALK mode
Battery Level
Remaining Mileage
Charging Indicator
Cruise Mode
SDTC OFF
Battery Level
Speedometer
Headlight (on)
Lock
Headlight (o)
1WD/2WD
Headlight (on)
Headlight (o)
Turn Signal Indicator Turn Signal Indicator
Turn Signal Indicator
The symbol displays the motor output power of the scooter.
Symbol
The symbol displays the current speed of the scooter.
The symbol displays the remaining battery power in battery percentage and battery bar.
The symbol indicates that the scooter is connected to the Segway-Ninebot app.
The symbol displays the remaining mileage of the scooter.
The symbol indicates that the scooter is charging.
The symbol displays the remaining battery power in battery bar.
Meaning
WALK Mode
Lock
GT1
GT2
The icon 1WD indicates that the scooter is in the one-wheel drive mode. The icon 2WD indicates that the
scooter is in the two-wheel drive mode.
Name Description
POWER Progress Bar
Speedometer
Cruise Mode
Lock
1WD/2WD (GT2)
Battery Level (GT2)
Battery Level (GT1)
BOOST Progress
Bar
Bluetooth
Warning
Remaining Mileage
Charging Indicator
SDTC OFF (GT2)
1) In ECO, SPORT or RACE mode, press the Left Control Switch to turn on the cruise
mode when the speed 3.1 mph (5 km/h). Once turned on, the scooter will cruise at ≥
the current speed.
2) Turn off the cruise mode with the following methods:
Method 1: Twist the throttle or squeeze brake levers.
Method 2: Press the Left Control Switch.
Method 3: Switch the speed mode.
DO NOT turn on the cruise mode in complex environments, bad weather or
undesirable road conditions. Serious danger or injury may occur.
When the scooter is locked via the Segway-Ninebot app:
1) The screen will go dark in 3 seconds, at this point, press the Power Button to wake
up the screen.
2) The scooter will sound the alarm with flashing lights when it is moved for 3
seconds.
3) The scooter will keep beeping when it is moved for 10 seconds, and if the scooter
is moved again within 60 seconds, the beep will not stop.
When the scooter is unlocked, it will automatically power off if there is no operation
within 10 minutes.
Note: Enable/Disable this feature via the Segway-Ninebot app.
1) Press the Right Control Switch to activate the BOOST mode. * In RACE mode only.
2) Twist the throttle to accelerate faster.
3) Press the Right Control Switch again or switch the speed mode to turn it off.
When the BOOST mode is activated, the scooter will accelerate faster. DO NOT
apply this feature in complex environments, bad weather or undesirable road
conditions. Serious danger or injury may occur.
The symbol indicates
that the SDTC (Segway
Dynamic Traction
Control) feature is off.
The symbol indicates
that the Cruise mode
is activated.
When the icon lights
up, it means the
scooter is locked.
The symbol displays
the remaining
available acceleration
time of the BOOST
mode.
The symbol indicates that the scooter has detected an error. The error code will display on the dashboard.
See page 8 for possible causes and solutions.
EN EN
03 04
