Sida 1/9
Ninebot KickScooter
F25 / F30 / F30S / F40
Product Manual
Manuel de Produit
Manual del producto
EN
FR
ES
www.segway.com
CE.00.0050.91-B
The manufacturer reserves the right to make changes to the product, release firmware updates, and update this manual at any
time. Visit www.segway.com or check the Segway-Ninebot app to download the latest user materials. You must install the app,
activate your KickScooter, and obtain the latest updates and safety instructions.
Le fabricant se réserve le droit d'apporter des modifications au produit, de publier des mises à jour du microprogramme et de
réviser ce manuel à tout moment. Visitez www.segway.com ou consultez l'application Segway-Ninebot pour télécharger les
derniers contenus utilisateur. Vous devez installer l'application, activer votre KickScooter et obtenir les dernières mises à jour et
consignes de sécurité.
El fabricante se reserva el derecho a realizar cambios en el producto, actualizaciones del firmware y modificaciones de este
manual en cualquier momento. Visita www.segway.com o revisa la app para descargar los materiales de usuario más recientes.
Debes instalar la aplicación Segway-Ninebot, activar tu KickScooter y obtener las actualizaciones e instrucciones de seguridad
más recientes.
EN
F R
E S
EN The pictures shown are for illustration purposes only. The actual product may vary.
FR La photo est pour référence seulement. Veuillez vous référer au produit réel pour plus de détails.
ES La imagen es solo de referencia. Remítase al producto en sí para ver más detalles.
Diagram
1
EN
Bell
Handlebar Electric Throttle
Snap Hook
Dashboard & Power Button
Safety Hook
Brake Lever
Headlight
Stem
Folding Mechanism
Quick-release lever
Front Fork
Front Fender
Hub Motor
Charge Port
Footboard
Buckle
Rear Fender
Rear Light
Disc Brake
Kickstand
Battery Compartment
01
Dashboard & Power Button
Power Button: Press the button to turn on; press and hold the button for 3 seconds to turn off. When the KickScooter is on, press the button
to turn on/off the headlight and the rear light, and press twice to switch between the speed modes.
Speedometer: It displays the current speed of the scooter, as well as error codes.
Please switch between metric and imperial units via the Segway-Ninebot app. How to switch: Tap the slide menu > Settings.
Speed Mode: There are three modes available. The top speed is as follows:
Error Notification: It indicates that the scooter has detected an error.
Temperature Warning: If the temperature warning is on, it indicates that the battery temperature has reached 131°F (55°C) or is below
32°F (0°C).
* At this point, the vehicle cannot accelerate normally and may not be charged. Do not use until the temperature has reverted to the
normal range.
Bluetooth: It indicates that the scooter has been successfully connected to the mobile device.
Battery Level: When the battery is at its full capacity, it will show 5 bars.
* The battery power is very low when the first battery bar is red. Please charge your KickScooter immediately.
Speedometer
Bluetooth
Headlight
Temperature Warning
Speed Mode
Error Notification
Battery Level
Power Button
Model
Mode F25 F30 F40F30S
9.3 mph (15 km/h)
15.5 mph (25 km/h)
15.5 mph (25 km/h)
9.3 mph (15 km/h)
15.5 mph (25 km/h)
15.5 mph (25 km/h)
9.3 mph (15 km/h)
18.6 mph (30 km/h)
18.6 mph (30 km/h)
ECO (Energy-saving mode)
D (Standard mode)
S (Sport mode)
Approx. 45 18.9 45.7 in (1143 480 1160 mm)× × × ×
Approx. 45 18.9 19.5 in (1143 480 495 mm)× × × ×
Approx. 32.4 lbs (14.7 kg)
Specifications
2
Product
Rider
Machine
Battery
Motor
Charger
Ninebot KickScooter
F25
Item Parameter
Name
Model
Length Width Height× ×
Folded: Length Width Height× ×
Net Weight
Payload
Recommended Age
Required Height
Max. Speed
Typical Range[1]
Max. Slope
Traversable Terrain
Operating Temperature
Storage Temperature
IP Rating
Duration of Charging
Nominal Voltage
Max. Charging Voltage
Charging Temperature
Nominal Capacity
Nominal Energy
Battery Management System
Output Power
Input Voltage
Max. Output Voltage
Rated Output
Brake Light
Riding Modes
Tire Pressure
Tires
40–45 psi
10-inch pneumatic tires.
LED Rear Light
Energy-saving mode, Standard mode and Sport mode
0.07 kW, 70 W
100–240 V~
42 V
41 V , 1.7 A
Nominal Power 0.3 kW, 300 W
36 V
42 V
32–104°F (0–40°C)
5100 mAh
183 Wh
Over-heating, short circuit, over-current, over-discharge and
over-charge protection
Approx. 15.5 mph (25 km/h)
Approx. 12.4 miles (20 km)
Approx. 12%
Asphalt/flat pavement; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
14–104°F (-10–40°C)
14–122°F (-10–50°C)
IPX5
Approx. 3.5 h
66–220 lbs (30–100 kg)
14+ years
3’11”–6’6” (120–200 cm)
[1] Typical Range: tested while riding under full power, 165 lbs (75 kg) load, 77°F (25°C), 60% of max. speed on average on pavement.
* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
Features
Tire
02 03
