ap-en.segway.com
CE.00.0042.28-A
EN The manufacturer reserves the right to make changes to the product, release firmware updates, and update this
manual at any time. Visit www.segway.com or check the Segway-Ninebot app to download the latest user materials.
You must install the app, activate your KickScooter, and obtain the latest updates and safety instructions.
Ninebot KickScooter
F20A / F30 / F30A / F40 / F40A
Product Manual
EN
EN The pictures shown are for illustration purposes only. The actual product may vary.
Diagram
1
EN
Dashboard & Power Button
Bell
Handlebar
Electronic Throttle
Snap Hook
Dashboard & Power Button
Safety Hook
Brake Lever
Headlight
Stem
Folding Mechanism
Quick Release Lever
Front Fork
Front Fender
Hub Motor
Charging Port
Footboard
Buckle
Rear Fender
Rear Light
Disc Brake
Reflector*
* For F20A, F30A, and F40A.
Reflector*
* For F20A, F30A, and F40A.
Kickstand
Battery Compartment
Power Button: Press the button to turn the KickScooter on and press, and hold the button for 3 seconds to turn the scooter off. When the
KickScooter is on, press the button to turn on/off the headlight and the rear light, and press twice to switch between the
speed modes.
Speedometer: Display the current speed of the scooter, as well as to display error codes.
Speed Mode: Three modes available.
Error: The wrench icon indicates that the scooter has detected an error.
Temperature Indicator: The thermometer icon always on indicates that the battery temperature has reached 122°F (50°C) or is below
32°F (0°C).
* At this point, the vehicle cannot accelerate normally and may not be charged. Do not use it until the temperature is
lowered to normal range.
Bluetooth: The icon indicates that the scooter has been successfully connected to the mobile device.
Battery Level: The total battery level equals to 5 bars.
* The battery power is very low when the first battery bar is red. Please charge your KickScooter immediately.
Speedometer
Bluetooth
Headlight
Temperature Indicator
Speed Mode
Error Display
Battery Level
Power Button
Model
Mode F20A
15 km/h (9.3 mph)
25 km/h (15.5 mph)
25 km/h (15.5 mph)
F30
15 km/h (9.3 mph)
25 km/h (15.5 mph)
25 km/h (15.5 mph)
F30A
15 km/h (9.3 mph)
25 km/h (15.5 mph)
25 km/h (15.5 mph)
F40
15 km/h (9.3 mph)
30 km/h (18.6 mph)
30 km/h (18.6 mph)
F40A
15 km/h (9.3 mph)
25 km/h (15.5 mph)
25 km/h (15.5 mph)
ECO (Energy saving mode)
D (Standard mode)
S (Sport mode)
01 02
Approx. 30 km/h (18.6 mph)
Approx. 30 km (18.6 miles)
Approx. 20%
Asphalt/flat pavement; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
-10–40°C (14–104°F)
-10–50°C (14–122°F)
IPX5
Approx. 6.5 h
Approx. 1143 × 480 × 1160 mm (45 × 18.9 × 45.7 inch)
Approx. 1143 × 480 × 495 mm (45 × 18.9 × 19.5 inch)
Approx. XX kg (XX lbs)
Specifications
2
Product
Rider
Machine
Battery
Motors
Charger
Ninebot KickScooter
F20A
Item Parameter
Name
Model
Length × Width × Height
Folded: Length × Width × Height
Net Weight
Payload
Recommended Age
Required Height
Max. Speed
Typical Range[1]
Max. Slope
Traversable Terrain
Operating Temperature
Storage Temperature
IP Rating
Duration of Charging
Nominal Voltage
Max. Charging Voltage
Charging Temperature
Nominal Capacity
Nominal Energy
Battery Management System
Output Power
Input Voltage
Max. Output Voltage
Rated Output
Brake Light
Riding Modes
Tire Pressure
Tires
45 psi
Hollow tires. Material: NR + SBR + SILICA. Size: 8 * 2.0. Without nozzle
LED Rear Light
Energy saving mode, Standard mode and Sport mode
0.07 kW, 70 W
100–240 V~
Nominal Power 0.25 kW, 250 W
36 V
0–40°C (32–104°F)
5100 mAh
183 Wh
Over-heating, short circuit, over-current, over-discharge and
over-charge protection
Approx. 25 km/h (15.5 mph)
Approx. 20 km (12.4 miles)
Approx. 10%
Asphalt/flat pavement; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm)
-10–40°C (14–104°F)
-10–50°C (14–122°F)
IPX5
Approx. 3.5 h
30–100 kg (66–220 lbs)
14–60 years
120–200 cm (3’11”–6’6”)
[1] Typical Range: tested while riding under full power, 75 kg (165 lbs) load, 25°C (77°F), 60% of max. speed on average on pavement.
* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
Approx. 1143 × 480 × 1160 mm (45 × 18.9 × 45.7 inch)
Approx. 1143 × 480 × 495 mm (45 × 18.9 × 19.5 inch)
Approx. XX kg (XX lbs)
Product
Rider
Machine
Battery
Motors
Charger
Features
Tire
Features
Tire
Ninebot KickScooter
F40
Approx. XX kg (XX lbs)
Approx. 25 km/h (15.5 mph)
Item Parameter
Name
Model
Length × Width × Height
Folded: Length × Width × Height
Net Weight
Payload
Recommended Age
Required Height
Max. Speed
Typical Range[1]
Max. Slope
Traversable Terrain
Operating Temperature
Storage Temperature
IP Rating
Duration of Charging
Nominal Voltage
Max. Charging Voltage
Charging Temperature
Nominal Capacity
Nominal Energy
Battery Management System
Output Power
Input Voltage
Max. Output Voltage
Rated Output
Brake Light
Riding Modes
Tire Pressure
Tires
45 psi
Hollow tires. Material: NR + SBR + SILICA. Size: 8 * 2.0. Without nozzle
LED Rear Light
Energy saving mode, Standard mode and Sport mode
0.07 kW, 70 W
100–240 V~
Nominal Power 0.35 kW, 350 W
36 V
0–40°C (32–104°F)
10.2 Ah
367 Wh
Over-heating, short circuit, over-current, over-discharge and
over-charge protection
30–120 kg (66–265 lbs)
14–60 years
120–200 cm (3’11”–6’6”)
F30A
Approx. XX kg (XX lbs)
Approx. 15%
Approx. 5 h
0.3 kW, 300 W
7650 mAh
275 Wh
F40A
[1] Typical Range: tested while riding under full power, 75 kg (165 lbs) load, 25°C (77°F), 60% of max. speed on average on pavement.
* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.
F30
03 04
