Sida 1/16
ASM-5
USER’S GUIDE
Table of Contents:
Introduction ................... 2
Overview ........................ 3
Precautions ....................4
Setting Up ..................5-9
Specifications ........ 10-11
Troubleshooting ....12-13
Warranty ....................... 14
2
Thank you for choosing Senal.
The The Senal ASM-5 Two-Way Active Speaker is designed for
near-field monitoring in professional audio applications. The
ASM-5 features active filter technology and a dual-channel
power amplifier, driven by a 5 woofer and 0.8 metal dome ″ ″
tweeter that deliver a wide and flat frequency response with
pristine audio reproduction and accurate sound imaging. The
cabinet’s curved port tube provides natural low-frequency
output and minimizes distortion, while the ellipsoidal
design and rigid, high-intensity aluminum alloy construction
prevent diffraction and cabinet resonance. This meticulous
engineering allows the ASM-5 to handle high sound pressure
levels in a compact cabinet size.
Fine-tune settings allow the user to adjust the high, mid, and
low frequencies to compensate for the listening environment,
speaker placement, and audio source. There is also a three-
position high-pass filter for low-frequency cutoff that makes
it easy to match the speaker with a subwoofer. The ASM-5
comes with a rubber base that isolates the speaker from its
resting surface to prevent resonant coupling, and makes it
easy to adjust the vertical angle of the speaker to down fire or
up fire. The speaker can also be mounted on a wall or a stand
via the mounting threads on the cabinet.
Introduction
3
Overview
Fine-tune settings
HF.High.frequency
MF.Mid.frequency
LF.Low.frequency
HP.High-pass.filter
Overview
Power.LED
Also Included:
XLR.to.XLR.cable
XLR.to.RCA.cable
AC.power.cable
User.manual
Frequency.adjust.terminal
Power.input
XLR.input
Mounting.thread
55
65
75
SETTIN G
HF MFLF HP
Tweeter
Woofer
Power.switch
Volume.control
Vent
Mounting.threads
Rubber.base
