Sida 1/14

2 Pcs. Portable Mono Solar Panel Starter Kit

SLSPSKT200

100W with 3 ft. 11AWG Cable Set

and 30A PWM Controller with LCD Screen

www.SereneLifeHome.com1

Please read the manual carefully before installing or operating the Portable

Mono Solar Panel Starter Kit to prevent personal injury or damage to the

components. Contact Technical support for any questions concerning the

installation.

INTRODUCTION

This manual provides the installation and operation instructions for users:

• Please carefully read this manual before installation, operation and maintenance

of our solar system. This manual includes all the important information and data,

and in order to guarantee the good performance of this system, please strictly

follow the instructions in this manual.

• We are not responsible for any consequences caused by wrong installation or

operation which does not correspond to this manual.

• Please keep this manual for future reference. In case of any questions or need

further assistance, please contact us or our agencies as well.

STORAGE & OPERATING CONDITIONS

Storage

To avoid potential dangers, the following notes must be followed:

• Storage environment should be ventilated and dustless.

• Relative humidity is less than 90%, and no water droplets.

• Keep away from re or any corrosive substances.

Operating Conditions

Operating Temperature

• Controller and inverter: -20°C - 50°C (-4°F - 122°F)

• Solar panel: -40°C - 85°C (-40°F - 185°F)

SAFETY PRECAUTIONS

• Installation stas should use insulating equipment (e.g. insulating shoes, insulating

gloves) to avoid electric shock.

• Solar panel is heavy and should always be handled by two people, and it contains

glass, which can be easily broken if mistreated, such as place heavy loads or drop

objects on its surface. .

• When working at height, appropriate protective safety equipment as recommended

by local safety codes (e.g. hard hat, scaolding, safety rope) should be used.

• Do not install the module if the back sheet or glass is damaged because there is

an electrical and re risk.

• Do not attempt any installation in adverse weather conditions (e.g. high winds,

rain or when ice or snow is present).

www.SereneLifeHome.com 2

PACKING LIST

INSTALLATION WITH ROOF RACK



100W Solar Panel A *1

100W Solar Panel B *1

Mounting brackets

*2set

Wire xer

*10pcs

Controller

30A*1pc

Extension lead

11AWG * 20ft

Fuse

15A*1pc

Battery lead

11AWG * 8ft

1 2 3

4 5 6

7 8

ONE SET of mounting

bracket included

Z-shape bracket

*4pcs

Double nut

aluminum plate

*4pcs

Ø8 Bolt (M8*16)

*4pcs

Ø8 Nylon lock nut

*4pcs

Ø8 Bolt at mat

*12pcs

Ø8 Bolt (M8*25)

*8pcs

Ø8 Bolt spring washer

*8pcs

Ø8 Big Bolt at mat

*4pcs
