Sida 1/13
MXC
Microflex
®
Complete
Update & Feature License
User guide for the Shure Microflex Complete Conference System
Version: -MXC FUU guide RevC.docx
Shure Incorporated
Table of
Table of
Table of
Table ofTable of
Contents
Contents
Contents
ContentsContents
1
Introduction
3
2 Buttons and windows in the FUU 3
3 4 Firmware update of MXC
3.1 Before you start 4
3.2 idelines General gu 4
3.3 Compatibility 4
3.4 Locked units 4
3.5 MXC Firmware Update Utility (FUU) 4
3.6 Firmware Connecting the FUU –
Update Utility 5
3.7 Checking the ‘Error Status’ window 6
3.8 System update 7
3.9 How to update or downgrade single
units 8
4 Changing of start image in MXC640 9
4.1 Upload a start image 9
4.2 11 Delete a start image
5 License key 11
6 - DCS LAN communication 12
6.1 Checking communication errors using
‘Error Status’ window 12
6.2 In case of errors in the communication
12
6.3 13 Advanced test
3
Shure Incorporated
1
Introduction
This manual describes the procedure for updating/downgrading the firmware in the various units in the DCS 6000 system.MXC/
The manual does also describe how to upload a Feature License into the MXC/DCS 6000 CCU Central Units.
For upload of language files and start up bitmap in DC 6990 Conference Units please refer to the manual ‘User Manual DC 6990 -
Languages’.
2 Buttons and windows in the FUU
CCU window
The windows shows ’Type’, ’Serial
number’ & ’Firmware version’ of the
CCU.
Status window
This window shows the status and
give messages to the user
Update System
Press this buttons to update the
firmware in all units in the system
‘ Command line’ button
Press this Icon to get a window
for sending commands to the
CCU
‘ ’ Present Units window
All units present in the system are
shown in this window
‘ Units’ Selected window
Unit, which are selected for
upgrading are shown in this window
Press this buttons to update the
status of the units connected
’Set Feature Id button’
Press this button change the
Feature setting for the selected
units
’ Update Units button’
Press this button to update the
units present in the ’Selected
Units window’
Select unit buttons
Select one or more units in the
’Present Units window and press ’
the ’Select Units(s) button’ to add
’Selected Units’ window or select by
type
’Remove buttons’
Press those buttons to either
remove a selected unit or to remove
all units from the ’Selected Units’
window
