ENTRY LEVEL USB 2.0
EXTENDER OVER CAT5E
EXTEND THE TRANSMISSION
DISTANCE BETWEEN A USB
DEVICE AND ITS HOST
COMPUTER UP TO 150 FT
Quick Start Guide
LOCAL UNIT
Upstream Port USB Type A Male
Downstream Port RJ45 Jack
Power Bus-Powered
REMOTE UNIT
Upstream Port USB Type A Female
Downstream Port RJ45 Jack
Power 5VDC - 2A
OTHER
Built-In Cable Length 1 ft
Interconnect Cable Standard CAT5/5e/6 Cable
Max Cable Length 150 ft
Weight 0-185 °F (0-85 °C)
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
TECHNICAL SPECIFICATION
USB2NANO
WHAT’S IN THE BOX
PART NO. DESCRIPTIONQ-TY
USB2NANO 1 USB 2.0/1.1 Extender Link
Quick Start Guide 1
OVERVIEW
SmartAVI’s USB2Nano extends standard USB (Universal
Serial Bus) 2.0 signals up to 150 feet using a single CAT5
cable. The USB2Nano supports all USB 2.0 high-speed
devices, from keyboards to printers, and will operate on
Windows®, Mac and Linux® operating systems. Additional
USB hubs can be added, increasing the amount of devices
that can be plugged into the USB2Nano.
FEATURES
• Supports all USB 2.0 and1.1 Devices Transparently
(Flash Drives, Printers, etc.)
• Supports USB 1.1 keyboard and mouse
• Works on Windows, Mac and Linux Operang
Systems
• Bus-Powered Local Unit
• Power Adapter for Remote Unit
• Extends USB device connecvity up to 150 feet
• Supports suspend/resume detecon
• Supports Hot Plug funconality
• Low cost compared to hub-based extension or other
USB extenders
• No soware driver required
• Plug-and-Play Ready
1. Connect the USB2Nano Transmitter to the computer using the USB Type A (Male) connector of the device.
2. Power up the USB2Nano Receiver using the power supply provided.
3. Connect the USB2Nano Transmitter to the USB2Nano receiver using a CAT5e UTP cable (up to 150ft).
4. Connect a USB 2.0 peripheral device to the USB Type A (female) connector of the USB2Nano Receiver.
HARDWARE INSTALLATION
USB
CAT5/6
USB2NANO-TX
USB2NANO-RX
