DURACASE - USER GUIDE

FOR 800 SERIES BARCODE SCANNERS

socketmobile.com

Follow these instructions for connecting the Socket Mobile 800 Series barcode scanner and the mobile device into the DuraCase.

Caution: *DO NOT BEND the mobile device or barcode scanner forward. DO NOT BEND the connectors.

*On Samsung mobile devices, be sure to disable Fast Charge.

Watch our video https://youtu.be/AJJyV3uYtGY

Step 1: Insert scanner into DuraCase

Step 4: Slide mobile device in place

Step 2: Bend DuraCase to align connector

Step 5: Bend DuraCase to align connector

Step 3: Snap down scanner

Step 6: Snap down mobile device

GDS®, IntelliSkin™, GDS Tech™, GDS Technology™, GDS Green™ and GDS Compatible™ are

trademarks or registered trademarks of National Products Inc.

The distinctive D Shape™ of the GDS® connector is a trademark of National Products Inc.

Patented and Trademarks

www.rammmount.com/ip 6430-00368F

Warranty: 1 Year Limited Warranty

socketmobile.com sales@socketmobile.com

UK/Ireland/South Africa: +44 7787 112109 Toll-Free: +1 800 552 3300 (USA/Canada) EMEA & Russia: +41 62 834 0780

France: +33 970 462 241 Switzerland: +41 62 834 07 80 Asia Pacic: +1 510 933 3122

Japan: +8190 9808 0518 Germany: +49 9401 5299 052 +1 510 933 3153Latin America:

Technical Support: Send us a support ticket at support.socketmobile.com or call us at 1 800 279 1390 between the hours of 7:00 AM- 7:00 PM PST.

© 2017 Socket Mobile, Inc. All rights reserved. Socket®, the Socket Mobile logo, SocketScan™, DuraScan™, Battery Friendly® are registered trademarks or trademarks of Socket Mobile, Inc. Microsoft® is a registered trademark of Microsoft Corporation in

the United States and other countries. Apple®, iPad®, iPad Mini®, iPhone®, iPod Touch®, and Mac iOS® are registered trademarks of Apple, Inc., registered in the U.S. and other countries. The Bluetooth® Technology word mark and logos are registered

trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Socket Mobile, Inc. is under license. Other trademarks and trade names are those of their respective owners.

Step 2: Align pins Step 3: Snap togetherStep 1: Squeeze the side clips

Charging Options

How to Use Single Charging Dock & 6 Multi-Bay Charger

How to Use Charging Adapter

Step 1: Insert charging cable Step 2: Insert DuraCase Step 3: Device charging

DuraCase Charging Dock DuraCase 6 Multi-Bay ChargerDuraCase Charging Adapter
