Sida 1/17
MULTI-CHANNEL POWER AMPLIFIER
16-50 | 8-50
I N S TA L L AT I O N A N D S U P P O R T M A N UA L
2
ZONE 1 ZONE 2 ZONE 4ZONE 3
ZONE 1 ZONE 2 ZONE 4ZONE 3
ZONE 5 ZONE 6 ZONE 8ZONE 7
MULTI-CHANNEL POWER AMPLIFIER
SONANCE 16-50 | 8-50 AMPLIFIER
TABLE OF CONTENTS
2 Box Contents
2 Introduction
2 Important Safety Information
3 Product Description
3 Placement
3 Quickstart Quide
4 Unpacking and Record Keeping
 
 
5 Recommended Tools, Cables, and Wires
5 Instruction Manual
5 Front and Rear Panel Features
6 AC Power Socket and Trigger Mode
6 Line Inputs/Loop Outputs
 
8 Speaker Connections
8 Bridging Channels
9 Protecting Circuitry, LEDs, and Speakers
 
10 Shelf and Rack Mounting
10 Installation
11 Troubleshooting
15 Uninstalling for Relocation or Service
 
16 Replacement Accessory Parts
17 Warranty Statement
8-50 FRONT

BOX CONTENTS
(1) Quickstart Guide

(1) AC Power Cord (North America Units Only)
(4) Amp Feet
(2) Rack Ears
(4 or 8) Speaker Block Connectors
(1) Voltage Trigger Block Connector
INTRODUCTION
Thank you for selecting the Sonance 16-50 or 8-50 multi-





Please take the time to carefully read through the

This extra time can lead to trouble free operation and

IMPORTANT SAFETY INSTRUCTIONS
You should always follow these basic safety precautions


READ THIS DOCUMENT IN ITS
ENTIRETY BEFORE ATTEMPTING USE.
 Read and retain instructions: Read all the safety and


 Heed warnings: Adhere to all warnings and precautions

 
 
 Carts and Stands: Use only with a cart or stand that is

6. CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE
THE POLARIZED PLUG WITH AN EXTENSION CORD,
RECEPTACLE, OR OTHER OUTLETS UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
 

 

 Grounding or Polarization: Precautions that should be

 Power-Cord Protection: Route power supply cords so they

 
16-50 FRONT

3
soft cloth. Do not use solvents, as they may damage the
amplier.
12. Non-Use Periods: Unplug the amplier’s power cord from
the outlet when the amplier will be left unused for a long
period of time.
13. Object Entry: Care should be taken so that objects do not
fall through the opening of the enclosure.
14. Moisture: Do not expose the amplier to dripping or
splashing. Do not place objects lled with liquids, such as
vases, on the amplier.
15. Damage Requiring Service: Have the amplier serviced by a
qualied service technician when the power cord or power
supply is damaged, the amplier has been dropped or
the enclosure is damaged, something has spilled into the
amplier, it has been exposed to rain, or the amplier is not
operating properly.
16. Servicing: Do not attempt to self service the amplier.
Contact Sonance Tech Support for servicing options.
17. Power Requirement: Do not connect the Sonance
amplier to the accessory outlet of any other component.
Connection to a grounded mains power outlet is required.
WARNING: THE POWER (MAINS) PLUG SERVES AS THE
AMPLIFIER’S DISCONNECT DEVICE. THE DISCONNECT DEVICE
SHALL REMAIN READILY OPERABLE DURING OPERATION.
TO ENSURE THAT THE DISCONNECT DEVICE IS EASILY
ACCESSIBLE, THE USER SHALL NOT PLACE THE AMPLIFIER IN
A CONFINED AREA DURING OPERATION.
18. Storms: To prevent damage to components, unplug all
electronic equipment during thunderstorms.
19. Unplug by grasping the plug, do not pull on the cord.
WARNING: ANY CHANGES OR MODIFICATIONS TO THIS UNIT
NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE
FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
NOTE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS B DIGITAL DEVICE,
PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE
DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE IN A RESIDENTIAL INSTALLATION.
THIS EQUIPMENT GENERATES, USES AND CAN RADIATE
RADIO FREQUENCY ENERGY AND, IF NOT INSTALLED
AND USED IN ACCORDANCE WITH THE INSTRUCTIONS,
MAY CAUSE HARMFUL INTERFERENCE TO RADIO
COMMUNICATIONS. HOWEVER, THERE IS NO GUARANTEE
THAT INTERFERENCE WILL NOT OCCUR IN A PARTICULAR
INSTALLATION. IF THIS EQUIPMENT DOES CAUSE HARMFUL
INTERFERENCE TO RADIO OR TELEVISION RECEPTION,
WHICH CAN BE DETERMINED BY TURNING THE EQUIPMENT
OFF AND ON, THE USER IS ENCOURAGED TO TRY TO CORRECT
THE INTERFERENCE BY ONE OR MORE OF THE FOLLOWING
MEASURES:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced technician for help.
PRODUCT DESCRIPTION
The Sonance 16-50 (16-channel power) and 8-50
(8-channel power) ampliers are rated at 50W per
channel into 8 Ohm loads, 100W per channel into 4
Ohm loads and 200W per bridged pair of channels into
8 Ohm loads. The internal stereo amplier modules
are audiophile grade, high-efciency Class D. The
amplier is easily congurable for stereo and/or bridged
operation and can pass paging and doorbell chimes
when these signals are connected to the Bus Inputs.
The amplier is compatible with 4 Ohm speakers in
stereo mode and 8 Ohm speakers in bridge mode.
Bridged operation is useful for higher power output
applications such as driving a passive subwoofer or an
outdoor 8 Ohm satellite and subwoofer system. Audio
source connections can be made into the ‘Local’ RCA
inputs for individual use or into one of the Bus Inputs
for distribution using the Zone Conguration Input
Assignment DIP switches. Busing allows for a single
source to be connected to one or more of the amplier
zones without the need for additional cabling. It is
possible to turn multiple Zone Conguration Input
Assignment DIP switches to ON to allow for multiple
inputs to play together such as with use of paging or
door bell chimes. The paging and door chimes will then
be heard along with the audio source(s). The 16-50 and
8-50 has a comprehensive protection circuit that guards
against shorted outputs, over-current, over-temperature,
low AC voltage (brownouts) and excessive AC voltage.
PLACEMENT
The 16-50 and 8-50 features fan assisted cooling utilizing
vents on both sides of the chassis. Ensure the sides of
the amplier have a least 3” (75mm) of clearance to
the sides of the rack or equipment cabinet to allow for
proper air ow.
The amplier should be placed in a dry, non-condensing
environment with ventilation. Locate the amplier so it
is completely isolated from temperature extremes, rain,
snow, direct sunlight and atmospheric contaminants. Do
not locate the amplier outdoors. Any moisture related
damage such as from condensation is not covered by
the factory warranty. Although the amplier includes
fan-assisted cooling, some heat is still produced. Locate
the amplier on a shelf or at the lowest place in a rack
that has good circulation of fresh air to dissipate heat.
Do not place the amplier in a closed cabinet or closet
with little ventilation as this can reduce its service life.
QUICKSTART GUIDE
The Quickstart Guide is intended for the installer who
is familiar with the 16-50 or 8-50 and has reviewed
the chapters on ‘Important Safety Instructions’ and
‘Placement’.
