Interchangeable Lens Digital Camera
Startup Guide
5-050-817- (1)11
E-mount
ZV-E1
Preparations
Checking the supplied items
The number in parentheses indicates the number of pieces.
• Camera (1)
• Rechargeable battery pack
NP-FZ100 (1)
• Wind screen (1) (attached to the
wind screen adaptor)
• Wind screen adaptor (1)
• Shoulder strap (1)
• Body cap (1) (attached to the
camera)
• Shoe cap (1) (attached to the
camera)
• Startup Guide (this manual) (1)
• Reference Guide (1)
Inserting the battery pack (supplied)/memory card
(sold separately) into the camera
Open the battery cover and the memory card cover, insert the battery/
memory card, and close the covers.
Insert the battery pack while pressing
the lock lever.
Ensure the notched corner
faces correctly.
This camera is compatible with SD memory cards.
When you use a memory card with this camera for the first time,
format the card using the camera in order to stabilize the performance
of the memory card.
About the “Help Guide”
For detailed instructions on using the camera, refer
to the “Help Guide” (web manual).
https://rd1.sony.net/help/ilc/2310/h_zz/
ZV-E1 Help Guide
Charging the battery pack
Charge lamp
To an external power
source
Turn the power off.
• If the camera is turned on, the battery pack
will not be charged.
Using a commercially available
USB Type-C cable, connect the USB Type-C
terminal on the camera to an external
power source, such as a commercially
available USB AC adapter or mobile
battery.
• The charge lamp will light up when charging
starts. When the charge lamp turns off,
charging is completed.
This camera is compatible with USB-PD (USB Power Delivery). When
a device compatible with USB-PD is connected to the camera, fast
charging is possible. We recommend using a USB-PD device that is
compatible with an output of 9V/3A or 9V/2A.
Attaching a lens
Mounting indexes
Mount the lens by aligning the two white
index marks (mounting indexes) on the
lens and camera.
While pushing the lens lightly toward
the camera, turn the lens slowly in the
direction of the arrow until it clicks into
the locked position.
Performing initial setup for the camera
By establishing a Bluetooth connection (pairing) between the camera
and a smartphone, you can perform initial camera setup such as
date and time settings from the smartphone. Install the dedicated
application on your smartphone in advance, and then follow steps
to under “Procedures for initial camera setup.”
Installing the dedicated smartphone application
Install the application from the following website. Also,
update to the latest version of the dedicated application.
The specifications of the dedicated application may
change without notice.
https://www.sony.net/ca/
Procedures for initial camera setup
ON/OFF (Power) switch
Control wheel/center
button
Set the ON/OFF (Power) switch to “ON” to
turn on the camera.
Select the desired language and then
press the center of the control wheel.
• The privacy notice screen will appear. Read
the privacy notice regarding biometrics by
opening the link using your smartphone, etc.
Press the center of the control wheel.
Follow the instructions on the camera
screen to connect the camera with your
smartphone and perform the initial
setup.
• You can also configure or change the initial
settings later from the MENU of the camera.
Connecting (pairing) the camera with your smartphone later
For details on the connection method, refer to the
following Help Guide URL:
https://rd1.sony.net/help/ilc/2310_pairing/h_zz/
Shooting movies
Still/Movie/S&Q switch
MOVIE (Movie)
button
MENU button
Set the Still/Movie/S&Q switch to
(Movie).
Press the MENU button and select
(Shooting) [Shooting Mode]
[Shoot Mode] the desired
shooting mode.
Press the MOVIE (Movie) button to start
recording.
Press the MOVIE (Movie) button again to
stop recording.
Using the wind screen (supplied)
Wind screen
Multi Interface Shoe
Use the wind screen to reduce wind noise
picked up by the internal microphone when
recording a movie.
Attach the wind screen to the Multi Interface
Shoe.
Notes on use
Refer to “Precautions” in the “Help Guide” as well.
Notes on handling the product
• Do not leave the lens exposed to a strong light source such as sunlight. Because of the
lens’s condensing function, doing so may cause smoke, fire, or a malfunction inside the
camera body or the lens. If you have to leave the camera exposed to a light source such
as sunlight, attach the lens cap to the lens.
• If sunlight or other strong light enters the camera through the lens, it may focus inside
the camera and cause smoke or fire. Attach the lens cap when storing the camera. When
shooting with backlighting, keep the sun sufficiently far away from the angle of view.
Even if it is slightly away from the angle of view, smoke or fire may still occur.
• Do not look at sunlight or a strong light source through the lens when it is detached. This
may result in unrecoverable damage to the eyes or cause a malfunction.
• This camera (including accessories) has magnet(s) which may interfere with pacemakers,
programmable shunt valves for hydrocephalus treatment, or other medical devices.
Do not place this camera close to persons who use such medical devices. Consult your
doctor before using this camera if you use any such medical device.
• Increase the volume gradually. Sudden loud noises can damage your ears. Be especially
careful when listening to headphones.
• Do not leave the camera, the supplied accessories, or memory cards within the reach of
infants. They may be accidentally swallowed. If this occurs, consult a doctor immediately.
• If the monitor is damaged, stop using the camera immediately. The damaged parts may
harm your hands, face, etc.
• When shooting still images continuously, the monitor may flash between the shooting
screen and a black screen. If you keep watching the screen in this situation, you may
experience uncomfortable symptoms such as feeling of unwellness. If you experience
uncomfortable symptoms, stop using the camera, and consult your doctor as necessary.
• When recording or streaming for long periods of time or recording 4K movies, if the
same part of your skin touches the camera for a long period of time while using the
camera, even if the camera does not feel hot to you, it may cause symptoms of a low-
temperature burn such as redness or blistering. Pay special attention in the following
situations and use a tripod, etc.
- When using the camera in a high temperature environment
- When someone with poor circulation or impaired skin sensation uses the camera
- When using the camera with [Auto Power OFF Temp.] set to [High]
Sony lenses/accessories
Using this unit with products from other manufacturers may affect its performance,
leading to accidents or malfunction.
Note on the 5GHz band for wireless LAN
When using the wireless LAN function outdoors, set the band to 2.4GHz by following the
procedure below. (WW694956 only)
• MENU (Network) [Wi-Fi] [Wi-Fi Frequency Band]
How to turn off wireless network functions (Wi-Fi, etc.) temporarily
When you board an airplane, etc., you can turn off all wireless network functions
temporarily using [Airplane Mode].
For Customers in the U.S.A. and Canada
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines. This equipment
has very low levels of RF energy that is deemed to comply without testing of specific
absorption rate (SAR).
The available scientific evidence does not show that any health problems are associated
with using low power wireless devices. There is no proof, however, that these low power
wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio
frequency energy (RF) in the microwave range while being used. Whereas high levels of
RF can produce health effects (by heating tissue), exposure of low-level RF that does not
produce heating effects causes no known adverse health effects. Many studies of low-
level RF exposures have not found any biological effects. Some studies have suggested
that some biological effects might occur, but such findings have not been confirmed by
additional research.
This equipment has been tested and found to comply with ISED radiation exposure limits
set forth for an uncontrolled environment and meets RSS-102 of the ISED radio frequency
(RF) Exposure rules.
For Customers in the U.S.A.
For question regarding your product or for the Sony Service Center nearest you, call 1-800-
222-SONY (7669) .
Supplier’s Declaration of Conformity
Trade Name : SONY
Model : WW694956
Responsible Party : Sony Electronics Inc.
Address : 16535 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone Number : 858-942-2230
Important note on use of 5 GHz wireless LAN
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the
MAC, through the digital and analog baseband, and finally to the RF chip. Several special
packets are initiated by the MAC. These are the only ways the digital baseband portion will
turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the
transmitter will be on only while one of the aforementioned packets is being transmitted.
In other words, this device automatically discontinue transmission in case of either
absence of information to transmit or operational failure.
Frequency Tolerance: ±20 ppm
For Customers in Canada
5150-5350 MHz band is restricted to indoor operation only.
High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-
5350MHz and 5650-5850MHz and that these radars could cause interference and/or
damage to LE-LAN devices.
For Customers in Europe
IEEE802.11b/g/n 2 400 MHz < 60 mW e.i.r.p.
IEEE802.11a/n/ac 5 150 - 5 350 MHz
5 470 - 5 725 MHz
< 35 mW e.i.r.p.
IEEE802.11a/n/ac 5 725 - 5 850 MHz < 25 mW e.i.r.p.
Bluetooth 2 400 MHz < 10 mW e.i.r.p.
Hereby, Sony Corporation declares that this equipment is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet
address:
https://www.compliance.sony.eu
Hereby, Sony Corporation declares that this equipment is in compliance with the UK
relevant statutory requirements.
The full text of the declaration of conformity is available at the following internet address:
https://compliance.sony.co.uk
For this radio equipment the following restrictions on putting into service or of
requirements for authorization of use apply in AT/BE/BG/CY/CZ/DK/EE/FI/FR/DE/EL/HU/
IE/IT/LV/LT/LU/MT/NL/PL/PT/RO/SK/SI/ES/SE/UK/UK(NI)/HR/IS/LI/NO/CH/AL/BA/MK/
MD/RS/ME/XK/TR:
5150 - 5350MHz band is restricted to indoor operations only.
For customers who purchased their camera from a store in
Japan that caters to tourists
Note
Some certification marks for standards supported by the camera can be confirmed on the
screen of the camera.
Select MENU (Setup) [Setup Option] [Certification Logo].
Specifications
Camera
[System]
Camera Type:
Interchangeable Lens Digital Camera
Lens: Sony E-mount lens
[Image sensor]
Image format: 35mm full frame,
CMOS image sensor
Effective pixel number of camera:
Approx. 12 100 000 pixels
Total pixel number of camera:
Approx. 12 900 000 pixels
[General]
Rated input: 7.2V , 3.5W
Operating temperature:
0 to 40 °C (32 to 104 °F)
Storage temperature:
–20 to 55 °C (–4 to 131 °F)
Dimensions (W/H/D) (Approx.):
121.0 × 71.9 × 54.3 mm
(4 7/8 × 2 7/8 × 2 1/4 in.)
Mass (Approx.):
483g (1lb 1.1oz) (including battery
pack, SD Card)
[Wireless LAN]
WW694956 (see name plate on the
bottom of camera)
Supported format:
IEEE802.11a/b/g/n/ac
Frequency band: 2.4GHz/5GHz
WW942672 (see name plate on the
bottom of camera)
Supported format: IEEE 802.11 b/g/n
Frequency band: 2.4 GHz
Rechargeable battery pack
NP-FZ100
Rated voltage: 7.2V
Design and specifications are subject to
change without notice.
Compatible iPhone/iPad models
iPhone SE (3rd generation), iPhone 13 Pro Max, iPhone 13 Pro, iPhone 13, iPhone 13 mini,
iPhone 12 Pro Max, iPhone 12 Pro, iPhone 12, iPhone 12 mini, iPhone SE (2nd generation),
iPhone 11 Pro Max, iPhone 11 Pro, iPhone 11, iPhone XS Max, iPhone XS, iPhone XR,
iPhone X, iPhone 8 Plus, iPhone 8, iPhone 7 Plus, iPhone 7, iPhone SE, iPhone 6s Plus,
iPhone 6s, iPad Air (3rd, 4th, and 5th generation), iPad (5th through 9th generation),
iPad mini (6th generation), iPad Pro 12.9-inch (1st through 5th generation), iPad Pro 11-inch
(3rd generation), iPad Pro 11-inch (2nd generation), iPad Pro 11-inch, iPad Pro 10.5-inch,
iPad Pro 9.7-inch, iPad Air 2, iPad mini (5th generation), iPad mini 4
(As of September 2022)
Trademarks/Licenses
• is a trademark of Sony Group Corporation.
• Apple, iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other
countries.
• USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum.
• Wi-Fi, the Wi-Fi logo and Wi-Fi Protected Setup are registered trademarks or trademarks
of the Wi-Fi Alliance.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Sony Group Corporation and its
subsidiaries is under license.
• QR Code is a trademark of Denso Wave Inc.
• In addition, system and product names used in this manual are, in general, trademarks or
registered trademarks of their respective developers or manufacturers. However, the ™
or marks may not be used in all cases in this manual.
IMPORTANT – Read the End User Software License Agreement before using your Sony
product.
Using your product indicates your acceptance of the End User Software License
Agreement. The software license agreement between you and Sony is available at the
following URL:
(https://rd1.sony.net/help/di/el23/h_zz/)
• Use of the Made for Apple badge means that an accessory has been designed to
connect specifically to the Apple product(s) identified in the badge, and has been
certified by the developer to meet Apple performance standards. Apple is not
responsible for the operation of this device or its compliance with safety and regulatory
standards.
Additional information on this product and answers to frequently asked
questions can be found at our Customer Support Website.
©2023 Sony Corporation Printed in Thailand
Produktspecifikationer
| Varumärke: | Sony |
| Kategori: | Kamera |
| Modell: | ZV-E1 |
Behöver du hjälp?
Om du behöver hjälp med Sony ZV-E1 ställ en fråga nedan och andra användare kommer att svara dig
Kamera Sony Manualer
19 September 2024
18 September 2024
15 September 2024
15 September 2024
15 September 2024
11 September 2024
11 September 2024
10 September 2024
6 September 2024
6 September 2024
Kamera Manualer
- Kamera Samsung
- Kamera Casio
- Kamera Philips
- Kamera Panasonic
- Kamera Epson
- Kamera Medion
- Kamera Nikon
- Kamera Olympus
- Kamera VTech
- Kamera Canon
- Kamera Acer
- Kamera Agfaphoto
- Kamera Agfa
- Kamera Alpine
- Kamera Anker
- Kamera Argus
- Kamera Hikvision
- Kamera GE
- Kamera BenQ
- Kamera Lexibook
- Kamera Leica
- Kamera Silvercrest
- Kamera Hitachi
- Kamera Gembird
- Kamera Lenco
- Kamera GoPro
- Kamera Pyle
- Kamera SereneLife
- Kamera Kodak
- Kamera Bushnell
- Kamera Blaupunkt
- Kamera TP Link
- Kamera Logitech
- Kamera Ezviz
- Kamera Polaroid
- Kamera Trust
- Kamera Avaya
- Kamera Easypix
- Kamera Denver
- Kamera Optoma
- Kamera Sanyo
- Kamera Imou
- Kamera Fujifilm
- Kamera Maginon
- Kamera Konica Minolta
- Kamera Emerson
- Kamera AVerMedia
- Kamera Celestron
- Kamera Eufy
- Kamera Lumens
- Kamera Yashica
- Kamera Flir
- Kamera Dahua Technology
- Kamera Daitsu
- Kamera Rollei
- Kamera Arlo
- Kamera Netgear
- Kamera Nest
- Kamera Sigma
- Kamera Ricoh
- Kamera Cobra
- Kamera Bresser
- Kamera Reolink
- Kamera Ansco
- Kamera Sygonix
- Kamera UniView
- Kamera Powerfix
- Kamera Intel
- Kamera Mamiya
- Kamera Pentax
- Kamera Konig
- Kamera Trevi
- Kamera Foscam
- Kamera Zenit
- Kamera Fuji
- Kamera Technaxx
- Kamera D-Link
- Kamera Swann
- Kamera Fluke
- Kamera Azden
- Kamera Kyocera
- Kamera Minox
- Kamera Minolta
- Kamera Lorex
- Kamera Marshall Electronics
- Kamera Ring
- Kamera Vivitar
- Kamera SJCAM
- Kamera Zorki
- Kamera Laserliner
- Kamera EverFocus
- Kamera RunCam
- Kamera Scosche
- Kamera SeaLife
- Kamera Burris
- Kamera FIMI
- Kamera SPC
- Kamera Meade
- Kamera Contax
- Kamera ARRI
- Kamera Traveler
- Kamera Levenhuk
- Kamera Exakta
- Kamera Digital Watchdog
- Kamera Elmo
- Kamera Oregon Scientific
- Kamera Silvergear
- Kamera Dorr
- Kamera Spypoint
- Kamera HOLGA
- Kamera Praktica
- Kamera Hasselblad
- Kamera Moto Mods (Motorola)
- Kamera Fantasea Line
- Kamera Vimar
- Kamera Kogan
- Kamera Getac
- Kamera Speco Technologies
- Kamera Brinno
- Kamera Z CAM
- Kamera General
- Kamera Ergoguys
- Kamera Strex
- Kamera General Electric
- Kamera Berger & Schröter
- Kamera Prixton
- Kamera AViPAS
- Kamera Leitz Focomat IIc
- Kamera Cosina
- Kamera Hanwha
- Kamera Videology
- Kamera InfiRay
- Kamera Pelco
- Kamera Joy-it
- Kamera Videotec
- Kamera Cambo
- Kamera Kobian
- Kamera Kyocera Yashica
- Kamera Red Digital Cinema
- Kamera Alfatron
- Kamera Bauhn
- Kamera Konica
- Kamera Akaso
- Kamera BZBGear
- Kamera Seek Thermal
- Kamera Aida
- Kamera Ikegami
- Kamera MuxLab
- Kamera Ikelite
- Kamera Adeunis
- Kamera Hoppstar
- Kamera IOptron
- Kamera Moultrie
- Kamera PatrolEyes
- Kamera Camouflage
- Kamera HuddleCamHD
- Kamera AquaTech
- Kamera PTZ Optics
- Kamera Aplic
- Kamera Linhof
- Kamera GoXtreme
- Kamera KanDao
- Kamera Aquapix
Nyaste Kamera Manualer
14 Januari 2025
8 Januari 2025
8 Januari 2025
7 Januari 2025
7 Januari 2025
7 Januari 2025
6 Januari 2025
5 Januari 2025
31 December 2025
31 December 2025
