Box contents

Install Instr tiouc ns For:

IPD-SM52-EZ and IPD-SM82-EZ

Do not spec or install speaker near support beam, ventilation duct or

other structure that may interfere with speaker function or dispersion.

Warning

SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for

optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.

U- b et rack

Back plate

IPD-SM-EZ

Series

1.435.647.9555

800.647.TUBE

www.soundtube.com

Safety cable

U-bracket screw

Screw cap

Warning

1 Speaker

1 U-bracket

2 U-bracket screws

2 Screw caps

1 Allen wrench

1 Back plate

1 Port plug

1 Safety cable

1 Strain relief water tight gland

Strain relief water tight gland

Pour réduire les risques d’incendie ou de choc électrique n’exposez

pas cet appareil à la pluie ou à l’humidité.

Avis

To reduce the risk of re or electric shock, do not expose this

apparatus to rain or moisture.

Warning

Install Instr tiouc ns For:

IPD-SM52-EZ and IPD-SM82-EZ

IPD-SM-EZ Series

Important Safety Instructions



1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

ampliers) that produce heat.

9) Only use the attachments/accessories specied by the manufacturer.

10) Unplug this apparatus during lightning storms or when unused for long periods of time.

11) Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in

any way, such as power-supply cord or plug is damaged, the apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

Consignes de sécurité importantes



1) Lisez ces instructions.

2) Conservez ces instructions.

3) Respectez tous les avertissements.

4) Suivez toutes les instructions.

6) Nettoyer seulement avec un chiffon sec.

7) Ne pas bloquer les ouvertures de ventilation. Installer conformément aux instructions du fabricant.

8) Ne pas installer près de sources de chaleur telles que des radiateurs, registres de chaleur, poêles ou autres

appareils (incluant les amplicateurs) qui produisent de la chaleur.

9) Utiliser uniquement les xations / accessoires spéciés par le fabricant.

10) Débranchez cet appareil pendant les orages ou si inutilisé pendant de longues périodes de temps.

11) Conez toute réparation à un personnel qualié. Une réparation est nécessaire lorsque l'appareil a été

endommagé de quelque façon que ce cordon d'alimentation ou la che est endommagé, l'appareil a été exposé à la

pluie ou à l'humidité, s'il ne fonctionne pas normalement ou s'il est tombé.

Port prot tionec for SM-EZ

1. Unpack speaker and

mounting hardware.

2. Choose a secure mounting

surface with sufcient strength

to reliably hold the speaker.

The speaker may be mounted

in either the vertical or the

horizontal position with the

same U-bracket.

9. Aim speaker and tighten

u-bracket screws. Once

tightened down, place the

screw caps on the screws.

Done!

To enhance protection of

internal components from

humidity and other potentially

corrosive elements, use

provided port plug to seal

enclosure. Use RTV silicone

around edge of the port plug

for increased protection.

8. Tilt speaker 45º (grille up)

and slide on to bracket.

Install Instr tiouc ns For:

IPD-SM52-EZ and IPD-SM82-EZ

IPD-SM-EZ Series

5. RJ-45 must be terminated

after CAT cable is run through

the water tight gland. Run

signal wire through the strain

relief gland and terminate RJ-45

connector. Once the connection

is secure, connect the signal wire

to the back of the speaker and

tighten the top of the wire gland

such that the rubber grommet is

tight around the cable. This may

require a wrench.

6. Install back plate and

secure with included fasteners.

7. Select desired location for

safety cable and remove the

U-bracket screw from that

side. Attach safety cable to the

clamping screw and reinstall

loosely.

3. Mount u-bracket with

clamping slots pointing

upward. Securely fasten

mounting bracket and safety

cable to surface (user must

supply fasteners).

Note: The safety cable will

attach to the U-bracket

clamping screw on one side of

the cabinet.

4. Place strain relief gland in

one of the knockouts on the

back plate and securly fasten

the gland nut on the other

side.
