200 New Highway, Amityville, NY 11701
800 645- -5516 / www.specotech.com
FEATURES
1000TVL Intensifier® Series Dome Camera with Junction Box
Wall/Ceiling Mount, Dual voltage
HTINT59K1 – 2.8~12mm varifocal lens, dark gray housing
SPECIFICATIONS
Image Sensor.................. 1/3” 1.3MP Sensor
Minimum Illumination....... 0.0001 lux (Sens-up X32)
Effective Pixels................ 1305 (H) x 1049 (V)
Total Pixels...................... 1312 (H) x 1069 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Video Output.................... 1.0 75 Vp-p / Ohms
Electronic Shutter............ Auto / Manual (1/ – 1/60 60,000 sec.)
WDR................................ On (Low / Middle / High) / Off
Day / Night....................... Auto / Color / BW
Test Monitor Output......... CVBS (Connector on Board)
Power............................. 12 24VDC / VAC
Power Consumption........ 600mA max. (DC), 450mA max. (AC)
Operating Temperature.... -4 –°F 140°F
Unit Dimensions.............. 3.97” (H ” (Dia.) ) x 5.23
Unit Weight...................... 1.4 lbs 0.7 lbs(camera), (junction box)
Certifications.................... FCC, RoHS
• 1/3” 1.3MP Sensor
• 1000 TV lines highest resolution in analog
• True WDR operation
• Superior low light performance -
• Amplify existing light with no distance limitation
• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor
• Built- -in heater and anti fog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Chameleon Cover™: snaps on and can be painted to
match any décor!*
• Full OSD operation through on board control-
• Signal distance up to 1600 feet*
• Vandal / tamper resistant
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
PRESET MODE
•OUTDOOR •INDOOR
•LOW LIGHT •LOBBY•HALLWAY •ELEVATOR
MAIN SETUP
EXPOSURE
•B/W
• • •LOW MIDDLE HIGH
• • •SHARPNESS GAMMA MIRROR •FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
•BRIGHTNESS •SHUTTER
BACKLIGHT
•HLC•BLC•WDR
•AUTO
• •AWB COLOR GAIN
• •ACE DEFOG
SYSTEM
•INTENSIFY •AGC
•COLOR
IRIS
MOTION
•PRIVACY
OSD Joystick
Video Test (CVBS)
Right
Up
Down
Left
DIMENSIONS
Bottom View
Side View Optional Accessories
Unit : inch
INTCM1
(Pole/Corner Mount)
INTWM1
(Wall Mount)
White Cover
(Included)
Black Cover
(Optional)
OSD CONTROL
•CAMERA TITLE
• •COMM IMAGE RANGE •COLOR SPACE
•OUTPUT
•LANGUAGE
•COLOR BAR •RESET
•D-ZOOM
•SHADING
Speco Technologies is constantly developing product improvements.
We reserve the right to modify product design and specifications without
notice and without incurring any obligation. Rev. 220415
200 New Highway, Amityville, NY 11701
800 645- -5516 / www.specotech.com
OSD MENU Details
DAY / NIGHT : Adjust Day / Night options.
COLOR : Always Color mode, Default value for these cameras
B/W : Always B/W mode.
- -ANTI SAT. : Adjusts the Anti Saturation level (0~ )20
AUTO : Day / Night is switching automatically by AGC level.
- -ANTI SAT. : Adjusts the Anti Saturation level (0~ )20
- 0~ )AGC THRES : Adjusts AGC THRES ( 20
- AGC MARGIN : Adjusts AGC margin (0~ )20
- DELAY : Adjusts the changing delay time (LOW/MIDDLE/HIGH)
COLOR : Adjusts white balancing options.
AWB : it goes to optimized color level automatically.
COLOR GAIN : Sets the desired Color Gain value (0~ )20
SPECO DNR : Uses to reduce the background noise in a low luminance
environment with 2D + 3D filtering system.
BACKLIGHT : Adjusts backlight options.
WDR : WDR illuminates darker areas of an image while retaining the
same light level for brighter areas to even out the overall brightness
of images with high contrast between bright and dark area
- Adjusts the WDR Weight (LOW/MIDDLE/HIGH)
BLC : Produces a clearer image of an object darkened by strong backlighting.
- H-POS : Adjusts the horizontal position(0~20)
- V-POS : Adjusts the Vertical position(0~20)
- H-SIZE : Adjusts the horizontal block size (0~20)
- V-SIZE : Adjusts the vertical block size (0~20)
HLC : Uses to contain extremely bright areas such as from car headlight,
the light can be masked out much of the on-screen details.
IMAGE : Adjusts various image options.
SHARPNESS : Adjusts sharpness level. Increasing this value, the picture
outline becomes stronger and clear. (0~10)
GAMMA : Sets the desired Gamma value. (0.45 ~ 0.75)
MIRROR : Change the video direction horizontally.
FLIP: Change the video direction perpendicularly.
D-ZOOM : Digital zoom up to x8 will be activated.
ACE (D-WDR) : Uses a digital wide dynamic range to balance dark and over
saturated areas within the image.
DEFOG : Activated this mode when the video or the weather is foggy.
SHADING : Sets the Lens Shading Compensation value. (ON/OFF)
PRIVACY : Used to hide regions of the image.
MOTION : Adjust motion detection settings.
DET WINDOW
DET TONE
MDRECT FILL
SENSITIVITY : Sets the desired of “Motion” (0~ )20
MOTION OSD
TEXT ALARM
SIGNAL OUT
SYSTEM : Adjusts various camera system options.
COM.
- -CAM ID : Sets the camera ID for the RS 485 (0~255)
- -BAUD RATE : Sets the baud rate for the RS 485 (2400~115200).
OUTPUT
VIEW ANGLE
WIDE 4 : 3 / WIDE 16 : 9
FREQ 60HZ
ANALOG MODE CVBS
CONFIRM YES
IMAGE RANGE
COLOR SPACE
COLOR BAR : Manufacturer’s option
LANGUAGE : Sets the desired OSD language
CAM TITLE
RESET: Press with long to reset all settings to factory defaults.
IRIS : ‘ALC’ as a default value
EXPOSURE : adjusts exposure settings.
BRIGHTNESS : Adjusts image brightness. (0 )~ 20
SHUTTER : Outdoor / Indoor / Deblur
INTENSIFY : Sets the desired multiple of the digital exposure length.
AGC(Auto Gain Control): Adjusts the AGC level. (0~ )10
1000TVL Intensifier® Series Dome Camera with Junction Box
Wall/Ceiling Mount, Dual voltage
HTINT59K1 – 2.8~12mm varifocal lens, dark gray housing
