Area 5.1

The Area 5.1 is a 5.1 surround

microphone preamplifier featu-

ring five matched high precision

gain stage preamplifiers with

motorized master/slave mic gain

controls, a Sub/LFE stage to deter-

mine the composition of the sub

signal and stereo downmix stages

for each channel. A monitor stage

allows on-location monitorin g

with stereo headphones.

The complete Area 5.1 system

contains the Area 5.1 unit and the

both optionally available SPL MA 5

mic array and multicore lead.

Though the Area 5.1 preamplifier

could be used with any micropho -

ne setup, the combination with

the MA 5 is recommended . This

setup has proven in various live

and studio situations to be per-

fect in capturing the 5.1 sound

image of a preferred ”listener’s

position“, while its versatility is

exceeded only by its ease of use.

Generally any digital or analog

recording system can be connec-

ted to the analog 1/4" unbalanced

jack or balanced XLR outputs of

the Area 5.1.

If for example, an eight-track

DTRS is employed, the first five

tracks can be used for the L, C, R,

SL and SR channels, the sub bass

signal should be routed to the

6th track while track 7 and 8 can

be used to record the stereo mix-

down.

Features

• Matched audiophile preampli-

fiers (pad, phase reverse, 48 V

power supply, Lundahl input

transformers)

• High precision motorized ma-

ster/slave mic gain controls

• Stereo downmix stages for 5.1

and stereo recordings in parallel

• Suited for any microphone type

(matched mics recommended)

• First discrete 5.1 system for

motion recordings with optio-

nal SPL MA 5 mic array.

Specifications

Frequency Response:.............. 10 Hz-50kHz

Common Mode Rejection:...... 10 kHz:>- 60dB

THD & N

Amplification: A weighted:

20 dB -97.1 dBu

40 dB -91.1 dBu

65dB -71.0 dBu

Dynamic Response:................ 119 dB

Max.Output Level XLR / Jack: +20 dBu

Output Impedance: ............... <75 Ohm

Housing: ............................... Standard EIA 19"/3U

482 x 132 x 237 mm

Weight: ................................. 7.3 kg

Area 5.1 Model 2047

Sound Performance Lab · Sohlweg 55 · D-41372 Niederkrüchten · Tel.+49 (0) 21 63 9834-0,Fax -20 · E-Mail:info@soundperformancelab.com · Internet: www.soundperformancelab.com
