Atmos 5.1 Surround Miking System
2
Version 1.0 E – 12/2003
R&D: Wolfgang Neumann
This user's guide contains a description of the product. It in no way represents
a guarantee of particular characteristics or results of use. The information in this
document has been carefully compiled and verifi ed and, unless otherwise stated or
agreed upon, correctly describes the product at the time of packaging with this docu-
ment.
Sound Performance Lab (SPL) continuously strives to improve its products and
reserves the right to modify the product described in this manual at any time without
prior notice. This document is the property of SPL and may not be copied or repro-
duced in any manner, in part or fully, without prior authorization by SPL.
Special thanks to:
Gerd Jüngling from ADT, who kindly provided the circuitry for the surround panning
matrix. Dirk Brauner Röhrengerätemanufaktur for the good collaboration.
Contact
Sound Performance Lab
Sohlweg 55, 41372 Niederkruechten, Germany
Fon +49 (0) 21 63-98 340
Fax +49 (0) 21 63-98 3420
Mail: info@soundperformancelab.com
Internet: www.soundperformancelab.com
Atmos 5.1 Surround Miking System, Model 9843 User’s Guide
© 2003 SPL electronics GmbH. All rights reserved. Technical specifi cations and appearance subject to change without notice.
3
Contents
Atmos 5.1 – the complete miking system for surround recordings ................... 4
Installation ........................................................................................................ 5
Control Elements ............................................................................................... 6
Standard Recording Setup ................................................................................ 11
Integration of additional microphones/stereo submix ...................................... 12
Integration of additional microphones/stereo submix ...................................... 13
A typical recording setup .................................................................................. 14
Specifi cations ................................................................................................... 15
Block diagram ................................................................................................... 16
Introduction
Dear customer,
thanks for using the Atmos 5.1 system. We wish you have as much fun working with
it as we had during the development of this extraordinary recording equipment.
The complete Atmos 5.1 system includes Atmos 5.1 controller, the Adjustable
Surround Microphone 5 (ASM 5), a separate power supply unit and a multicore cable
(length ca. 25 meters/27.5 yards).
The Atmos 5.1 system allows to record the original event and all of its authentic
spatial content with highest precision. It demonstrates the signifi cant difference
between discrete surround recordings and artifi cial surround mixes with breath-
taking results. To reliably achieve these amazing results, the Atmos 5.1 provides
everything you need to record virtually any audio event.
Due to its analog structure, the audio signals are compatible with any common
surround format—DVD-A, DVD-V, SACD, AC3, DTS, MLP... you name it, Atmos 5.1 can
deliver it.
With its ingenious ASM 5 „star frame“ array based on Brauner VM1 mic elements
and custom-designed, hand-built Atmos 5.1 controller, this unique system offers an
unparalleled combination of uncompromising audio quality and ultimate fl exibility.
Most importantly, the Atmos 5.1 system is a breeze to use and can be set up in
minutes, arming you for the most convincing 5.1 recordings you‘ve ever experi-
enced.
