Sida 1/8
Crescendo
120V Eight Channel Microphone Preamplier
EN
DE
Manual
Find more information: spl.audio
Crescendo – Manual
4
Frequency range
20-70kHz -3dB
Mic pre amp gain
70 dB (adjustable with potentiometer)
Input impedance
10 kOhm
Output impedance
75 Ohm
Noise (A-weighted)
(150 Ohm, 60dB Gain) -69.7 dBu
(150 Ohm, 30dB Gain) -87.5 dBu
CMRR
80dBu/1kHz
THD/N
(10 Hz - 22 kHz, 30dB Gain) 0.008%
E.I.N
(60dB Gain) 150 Ohm -129.7 dBu
Power consumption
230 60V: W
115 80V: W
The phantom power required for condenser microphones can be activated with
the 48V switch.
If phantom power is on, the 48V LED lights up blue.
IMPORTANT:
Use phantom power only for condenser microphones. For all other microphone types – especially
ribbon micorphones – switch o the phantom power!
Use the Mic Gain control to adjust the preamplication gain.
The polarity of a microphone signal can be inversed (180°) with the Polarity
Inversal switch.
If the input signal is too hot, switch on PAD. This reduces the level by 20dB.
You can make the VU Meters less sensitive by activating the VU-10dB switch.
Power down
Switch omains on the back of the Crescendo (O = O).
The VU Meter no longer light up.
Specications
8
9
10
11
12
13
Crescendo – Manual
Security Advices
Before starting up the device:
• Read thoroughly and follow the security advices.
• Read thoroughly and follow the Quickstart.
• Observe all warning instructions on the device.
• Please keep the user manual as well as the security
advices in a safe place for future reference.
Warning
Always follow the security advices listed below to avoid
serious injuries or even deadly accidents due to electric
shocks, short circuit, re or other dangers. The following
are examples of such risks and do not represent an
exhaustive list:
Power supply/Power cord
Do not place the power cord near heat sources such
as heaters or radiators and do not excessively bend or
otherwise damage the cord, do not place heavy objects
on it, or place it in a position where anyone could walk
on, trip over, or roll anything over it.
Only use the voltage indicated on the device.
Only use the supplied power cord/plug.
If you intend to use the device in an area other than in
the one you purchased it, the included power cord may
not be compatible. In this case please contact your
dealer.
Be sure to connect the device to an appropriate mains
socket outlet with a protective grounding connection.
Improper grounding can cause electrical shock.
Do not open
This device contains no user-serviceable parts. Do not
open the device or attempt to disassemble the internal
parts or modify them in any way. If it should appear to be
malfunctioning, turn o the power immediately, unplug
the power cord from the mains socket outlet and have it
inspected by a qualied professional.
Water warning
Do not expose the device to rain, or use it near water
or in damp or wet conditions, or place anything on it
(such as vases, bottles or glasses) containing liquids
which might spill into any openings. If any liquid such as
water seeps into the device, turn o the power immedi-
ately and unplug the power cord from the mains socket
outlet. Then have the device inspected by a qualied
professional.
Never insert or remove an electric plug with wet hands.
Fire warning
Do not put burning items, such as candles, on the unit.
A burning item may fall over and cause a re.
Lightning
Before thunderstorms or other severe weather, discon-
nect the device from the mains socket outlet; do not
do this during a storm in order to avoid life threatening
lightning strikes. Similarly, disconnect all the power
connections of other devices, antenna and phone/
network cables which may be interconnected so that no
damage results from such secondary connections.
If you notice any abnormality
When one of the following problems occur, immediately
turn o the power switch and disconnect the electric
plug from the mains socket outlet. Then have the device
inspected by a qualied professional.
• The power cord or plug gets frayed or damaged.
• The device emits unusual smells or smoke.
• An object has fallen into the unit.
• There is a sudden loss of sound during the use of the
the device.
Caution
Always follow the basic precautions listed below to
avoid the possibility of physical injury to you or others,
or damage to the device or other property. These
precautions include, but are not limited to, the following:
Power supply/Power cord
When removing the electric plug from the device or an
mains socket outlet, always pull on the plug itself and
not the cord. Pulling the cord may damage it.
Unplug the device from the mains socket outlet when
the device is not used for a while.
XLR output connector
Touching the open pins of the XLR output connector may
result in an uncomfortable feeling.
Location
Do not place the device in an unstable position where it
might accidentally fall over.
Do not block the vents. This device has ventilation holes
to prevent the internal temperature from rising too high.
In particular, do not place the device on its side or upside
down. Inadequate ventilation can result in overheating,
possibly causing damage to the device or even re.
Do not place the device in a location where it may come
into contact with corrosive gases or salty air. This may
result in malfunction.
Before moving the device, remove all connected cables.
When setting up the device, make sure that the mains
socket outlet you are using is easily accessible. If some
trouble or malfunction occurs, immediately turn o the
power switch and disconnect the plug from the mains
socket outlet. Even when the power switch is turned o,
electricity is still flowing to the product at a minimum
rate. When you are not using the device for a long time,
make sure to unplug the power cord from the wall mains
socket outlet.
