Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: February 28, 2022 11:17 AM

Product ID

DKT31CH2CPD3

USB-C Multiport Adapter - HDMI 4K 60Hz HDR10 - 3 x USB (10Gbps) - 100W PD - Extended Cable

12 4

4USB-C Data/Charge Ports

• Connect and/or charge USB-C Peripherals

• USB-C Power Adapter required for charging

• USB 3.2 Gen 2 (10 Gbps)

• Supports 5V/3A (15 W) charging

5USB-C 100W Power

Delivery Port

• Connect a USB-C Power Adapter

• USB Power Delivery 3.0 (up to 100 W, with up

to 85 W available for charging)

6Gigabit Ethernet Port

• Connect a CAT 5e/CAT 6 cable to establish a

network connection

• 10/100/1000 Mbps

Component Function

1Built-in USB-C Host Cable

• Connect to a USB-C Port on a Host Computer

• USB 3.2 Gen 2 (10 Gbps)

• Power Delivery 3.0 Specication

2HDMI Output Port

• Connect an HDMI Display Device

• HDMI 2.0b HDR10

• Up to 4K (4096x2160) 60 Hz

• Via DisplayPort 1.4 DP Alt Mode

3USB-A Data/Charge Port

• Connect and/or charge a USB-A Peripheral

• USB-C Power Adapter required for charging

• USB 3.2 Gen 2 (10 Gbps)

• Supports BC 1.2 5 V/1.5 A (7.5 W) charging

(Side A)

(Side B)

(Side C)

Requirements

• Computer

• DP Alt Mode enabled USB-C Port

For the latest drivers, manuals, product information, technical specications, and

declarations of conformance, please visit: www.StarTech.com/DKT31CH2CPD3

Package Contents

• USB-C MultiPort Adapter x 1

• Quick-Start Guide x 1

Product Diagram

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-

party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which

this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the

property of their respective holders.

PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other countries.

Warranty Information

This product is backed by a 3-year warranty.

For further information on product warranty terms and conditions, please refer to .www.startech.com/warranty

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)

for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of

business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations

or exclusions contained in this statement may not apply to you.

FR: startech.com/fr

DE: startech.com/de

ES: startech.com/es

NL: startech.com/nl

IT: startech.com/it

JP: startech.com/jp

StarTech.com

Ltd.

45 Artisans Cres

London, Ontario

N5V 5E9

Canada

StarTech.com Ltd.

Unit B, Pinnacle 15

Gowerton Rd,

Brackmills

Northampton

NN4 7BW

United Kingdom

StarTech.com LLP

4490 South Hamilton

Road

Groveport, Ohio

43125

U.S.A.

StarTech.com Ltd.

Siriusdreef 17-27

2132 WT Hoofddorp

The Netherlands

Regulatory Compliance

FCC -- Part 15

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

• • Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• • Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:

(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause

undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est

autorisée aux deux conditions suivantes:

(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

IC Radiation Exposure Statement:

This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment. This equipment

should be installed and operated with minimum distance 20cm between the radiator and your body.

Installation

Side A Ports

1. Connect the , located on the Multiport Adapter, to a Built-in USB-C Host Cable

USB-C Port on your Host Computer. Your Host Computer will automatically detect

the device and install the required drivers.

2. Connect an HDMI Enabled Display to the HDMI Output Port, located on the

MultiPort Adapter, using an HDMI cable.

Notes:

• The computer’s USB-C port must support DP Alt Mode to output video.

• Video performance, such as resolution, and refresh rate depends upon the

connected Host Computer’s video controller. Please verify the specications of

the Host Computer.

3. Connect USB Peripheral Devices to the , located on the USB-A Data/Charge Port

Multiport Adapter.

Notes:

• Power and charge the connected Peripheral Devices with up to 5 V/1.5 A

(7.5 W).

• A USB-C Power Adapter must be connected to the USB-C 100 W Power

Delivery Port, located on the Multiport Adapter, to charge Peripheral

Devices.

• Without a power adapter connected, the USB port will output whatever bus

power is available, up to 4.5W.

4. Connect a USB Peripheral Device to the , located on the USB-C Data/Charge Port

Multiport Adapter.

Notes:

• Power and charge the connected Peripheral Device with up to 5 V/3 A (15 W).

• A USB-C Power Adapter must be connected to the USB-C 100 W Power

Delivery Port, located on the Multiport Adapter, to charge Peripheral

Devices.

• Without a Power Adapter connected, the will USB-C DATA/Charge Port

output whatever bus power is available, up to 4.5 W.

Side B Port

5. Connect a USB-C Power Adapter (up to 100W) from an AC outlet to the USB-C

DATA/100 W Power Delivery Port on the Multiport Adapter, to charge the Host

Computer that’s connected to the .Built-in USB-C Host Cable

Note: The Multiport Adapter reserves 15W of power, with up to 85W

available for charging your Host Computer.

Side C Port

6. Connect a CAT 5e/CAT 6 Cable from the Network Device (e.g. Router, Switch,

Modem, etc.) to the on the Multiport Adapter, to access Gigabit Ethernet Port

the network via a wired LAN connection.
