USB 3.1 Gen 2 (10Gbps) dual-bay dock for 2.5"/3.5" SATA SSD/HDDs
StarTech ID: SDOCK2U313
Get unprecedented performance and storage capacity with this USB 3.1 Gen 2 (10 Gbps) dual-drive docking
station. It supports both 2.5” and 3.5” form factor solid-state and hard drives, with a high capacity storage
capability of 12TB (6TB per drive).
Harness the speed of USB 3.1 Gen 2
USB 3.1 Gen 2 gives you greater bandwidth and speed with file transfer rates of up to 10 Gbps – twice the
speed of USB 3.0 (USB 3.1 Gen 1) technology. It lets you leverage the high performance of the latest SSDs and
hard drives, while alleviating bottlenecks in your data transfers.
Top-loading design for easy drive access
It’s never been easier to dock and swap drives from your desktop computer or laptop. Simply insert your drives
into the top loading slot, with no tools or trays required. The HDD ejection button allows fast and simple drive
www.startech.com
1 800 265 1844
removal.
Convenient compatibility
The dual-drive docking station comes with a USB Type-A to B cable, providing backward compatibility with your
existing USB 3.0, 2.0 and 1.x devices. It also supports UASP for enhanced performance.
Extend the value of this hard drive docking station further with the addition of our SATA to IDE Hard Drive
Adapter (SAT2IDEADP), allowing easy insertion of any 2.5” or 3.5” IDE hard drive into a SATA hard drive dock.
The SDOCK2U313 is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Applications
Perfect for system builders and IT professionals who need quick access to drives for imaging
Back up data quickly to an external drive for archiving
Transfer data from one hard drive to another
Convenient for technicians who test or benchmark multiple hard drives
Easily take backup data to an offsite location for safekeeping
Features
Access data from two 2.5/3.5” SATA SDD/HDDs over ultra-fast USB 3.1 Gen 2
Support for SATA I, II and III (up to 6 Gbps)
USB Type A interface for backward compatibility with USB 3.0, 2.0 and 1.x
Dual bay, top-loading design with built-in ejection button for easy drive access
UASP support for enhanced performance
Supports large drive capacity of 12TB (6TB per bay)
Independent power buttons for each drive
www.startech.com
1 800 265 1844
Technical Specifications
Warranty 2 Years
Bus Type USB 3.1 Gen 2
Chipset ID ASMedia - ASM1352R
Compatible Drive Types (Type and Rate) SATA
Drive Installation Removable
Drive Size 2.5in & 3.5in
Fan(s) No
Interface USB 3.1 Gen 2
Number of 2.5 inch bays 2
Number of Drives 2
Number of internal 3.5 inch bays 2
Max Drive Capacity Currently tested with hard drives up to 6TB at 7200 RPM
Maximum Data Transfer Rate 10 Gbps
Type and Rate USB 3.1 Gen 2 - 10 Gbit/s
Type and Rate SATA III (6 Gbps)
UASP Support Yes
Drive Connectors 2 - SATA Data & Power Combo (7+15 pin) Receptacle
Host Connectors 1 - USB 3.1 USB type Micro-B (10 pin; Gen 2; 10 Gbps) Female
Color Black
Enclosure Type Plastic
Product Height 2.8 in [70 mm]
Product Length 5.2 in [132 mm]
Product Weight 18.7 oz [530 g]
Product Width 5.8 in [148 mm]
LED Indicators 1 - Power
LED Indicators 2 - HDD Activity
Center Tip Polarity Positive
Input Current 1.3A
Input Voltage 110 ~ 240 AC
Output Current 3000 mA
Output Voltage 12 AC
Plug Type M
Power Source AC Adapter Included
www.startech.com
1 800 265 1844
