USER MANUAL
OJAI - High Current DC Power Supply User Manual
®
pg 2
Ojai is the highest horsepower, most
technologically advanced effects pedal
power supply of its size. You get clean, rock-
steady power for your effects pedals in an
expandable package, giving you room to grow.
Ojai’s dual-stage topology, pre-regulated
outputs, optically isolated feedback, and
advanced multistage filtering allow your
pedals to achieve their highest possible
dynamic range.
Ojai’s all analog circuitry offers two stages of
isolation. Each of the five output channels is
individually isolated from the 24V DC, and the
24V DC is isolated from the AC input power,
eliminating ground loop and AC line noise
issues.
Your new Ojai power supply unit went through
the same rigorous audio tests that all
Strymon pedals go through. With Ojai, your
pedals will sound the way they were designed
to sound.
Playing gigs all around the world? No need
to purchase separate power supplies for your
international tour.
Ojai has automatic worldwide power
compatibility built-in (when connected with
the appropriate IEC cable). Whether you’re on
120V, 240V, 100V, or any variation in between,
Ojai delivers clean, reliable power to all of
your pedals.
Welcome to Ojai
Ultra-Low Noise
World Tour Ready
OJAI - High Current DC Power Supply User Manual
®
pg 3
Connect the other end of the
power adapter cable to Ojais
24V IN jack.
Connect up to five 9V
pedals here with the
included pedal cables.
Connect one end of the included IEC
cable to the 24V power adapter, and the
other end to an AC power outlet.
Connect one end of the
included power adapter cable
to the 24V power adapter.
1
3
4
2
PEDAL OUTPUTS: Connect up to
five 9V DC pedals with the included
5.5mm x 2.1mm pedal cables. Each
output is dual-isolated for noise-
free operation, provides 500mA of
available current at 9V DC, and has
center negative polarity.
Ojai will power most effects pedals
on the market, including all Strymon
pedals. However, there are some
pedals that have unique power
requirements. Check with each pedal
manufacturer for recommended
voltage, polarity, and required
current.
For pedals that have unique power
requirements (more than 500mA of
current, other voltages such as 18V),
you can find configuration details
here: strymon.net/support/ojai
LED INDICATOR: Each output
features an LED indicator. LED
illuminates green when a pedal
cable is plugged in. LED will turn off
if cable is unplugged, or the current
draw on the output exceeds the
maximum amount available.
Getting Started
Connect Your Pedals
