USER MANUAL

Riverside - Multistage Drive

pg 2

Front Panel

• GAIN

Toggles between the low or

high gain channel.

• DRIVE

Adjusts the amount of

gain applied to the signal.

Employs continuously

variable circuit tuning

to adjust many circuit

parameters as you turn the

knob.

• BASS

Active shelving/parametric

low frequency control.

• FAVORITE

Used to recall a single stored favorite setting, which consists of all knob,

switch, and noise gate settings.

RED LED indicates that the Favorite setting is selected. Press and hold

Favorite switch for 2 seconds to save a new favorite sound.

COMPARE MODE

With FAVORITE on, LED turns from from if current position is RED to GREEN

identical to saved favorite.

• PUSH

Toggles between flat

or enhanced midrange

frequencies.

• LEVEL

Controls the output volume

level when the effect is ON.

• TREBLE

Wide-ranging high frequency

active shelf control.

• MIDDLE

Parametric mid boost/

cut control with optimized

frequency center.

• ON

Bypasses analog and digital

gain stages. Defaults to

relay based true bypass, but

can also be set to buffered

bypass mode in which the

volume pedal and boost

functionality are preserved.

Riverside - Multistage Drive

pg 3

Rear Panel

• POWER

Use an adapter with the following rating:

9VDC center negative. 250mA minimum.

• PRESENCE SWITCH

Tailors the top end character of the output

to match your amp. Try minus (-) or center

in front of an amp. Try plus (+) when

plugging straight into a power amp.

• BOOST

Boost Switch Mode - Use an external Favorite

switch to toggle up to +6dB of post boost on/off

( ).See page 8 for setup

Favorite Output Mode – Connect to the EXP input

of another Strymon pedal set to work in Favorite

EXP mode to toggle the Favorite setting of that

pedal with the on-board FAVORITE switch (See

page 8 for setup).

• EXP

Can be used in one of two ways with a standard

TRS expression pedal:

Expression Pedal Mode – Allows continuous

control over any of the knobs (See page 11 for

more info).

Volume Mode – Allows control of the output

volume of the effect ( ).See page 11 for more info

• IN

Mono instrument input.

• OUT

Mono signal output.
