SurgeX
Installation Instructions
SA82 F
Fl
la
at
tP
Pa
ak
k
120 Volt Connections
The SurgeX SA82 is designed to operate from a 120V AC service. Power up the unit by
connecting the power cord supplied with the unit and then plug into a 120V ac receptacle.
The SA82 is rated for a maximum load of 8 amps. Plug up to two equipment power cords into
the yellow receptacles as needed to provide safe, filtered power to the equipment.
Under no circumstances should the product be used with a “ground lifter” or any other device
which disconnects ground from the SurgeX. Doing so will create a safety hazard and could
constitute danger to life.
Indicator Lights
The green Self-Test light indicates that power is applied to the unit and the internal surge
protection circuitry is fully functional. If this light is not on when the unit is plugged into the AC
check that AC is present at the receptacle where the unit is plugged in.
If at any point the Self-Test light should go out, first make sure that AC is present at the
receptacle where the unit is plugged in. If the light is still off once this has been checked then it
will be necessary to return the unit to SurgeX for repair.
The red Power light indicates that AC power is available at the two yellow receptacles. This light
will go out if the AC voltage rises above 145 Volts and power will be interrupted in order to
protect connected equipment. When the AC voltage returns below 135 Volts power will be
automatically restored to the yellow receptacles and the red Power light will once again be lit.
