- EN - - EN - - EN - - EN - - EN - - EN - - EN - - EN - - EN -

Shenzhen Temie Technology Co. Ltd.

Web:www.tacklife.net

E-mail:support@tacklife.net

ADD:No.31, Qing Linxi Road, Longgang

District,Shenzhen, Guangdong, China 518172 CN

Mini Cross Line Laser

Model: SC-L01

User Manual

Contents

Congratulations!

You have chosen one of our laser tools that’s guaranteed reliable and

tough for professional tool users at various job sites.

• Safety

• Product Overview

• Operation Modes

• Applications

• User Guide, Maintenance and Care

• Specifications

• Warranty

Product Overview

1. Laser Windows

2. Power/Lock

3. Battery Compartment

4. 1/4-20 Mounting Thread

Safety

WARNING:

Read the Safety Instructions and User Manual thoroughly before using this

product. All users must fully understand and adhere to these instructions.

CAUTION:

While the product is in operation, be careful not to expose your eyes to the

emitting laser beam (red or green light source). Exposure to a laser beam

for an extended time may be hazardous to your eyes.

CAUTION:

Glasses may be supplied in some of the laser tool kits. These are NOT

certified safety glasses. These glasses are ONLY used to enhance visibility of

beam in brighter environments or at greater distances from laser source.

WARNING:

The following label/print samples are placed on the product to inform of

the laser class for your convenience and safety.

• Do not stare directly into the beam or view directly with optical instruments

or set up the laser at eye level.

• Do not disassemble the laser tool. There are no user serviceable parts inside.

• Do not modify the laser in any way. Modifying the tool may result in

hazardous Laser Radiation Exposure.

• Do not operate the laser around children or allow children to operate

the laser. Serious eye injury may result.

• An exposure to the beam of a Class 2 laser is considered safe for a

maximum of 0.25 seconds. Eyelid reflexes will normally provide adequate

protection.

Applications

User Guide, Maintenance and Care

• The laser tool is sealed and calibrated at the plant to the accuracies

specified.

• It’s recommended to carry out an accuracy check before its first use

and periodic checks during future use especially for precise layouts.

• When not in use please power OFF the tool and place the pendulum

lock in its locked position.

• In Manual Mode, self leveling is OFF. The accuracy of the beam is not

ensured to be level.

• Do not short any battery terminals or charge alkaline batteries or dispose

of batteries in fire.

• Do not mix old and new batteries. Replace all of them at the same time

with new batteries of the same brand and type.

• Keep batteries out of reach of children.

• Remove batteries if the tool will not be used for several months.

• Do not store the laser tool in direct sunlight or expose it to high temperatures.

The housing and some internal parts are made of plastics and may

become deformed at high temperatures.

• Exterior plastic parts may be cleaned with a damp cloth. Although

these parts are solvent resistant, NEVER use solvents. Use a soft, dry cloth

to remove moisture from the tool before storage.

• Store the tool in its case when not in use. If storing for extended time,

remove batteries before storage to prevent possible damage.

Warranty

We are confident of the quality of our products and offer outstanding

guarantee for professional users of the products. This statement is in addition

to and in no way prejudices your contractual rights as a professional user

Laser Class

Laser Wavelength

Leveling Accuracy

Horizontal/Vertical Accuracy

Leveling/Compensation Range

Working Distance (Line)

Working Distance

(Line with Detector)

Power Source

IP Rating

Operation Temperature Range

Storage Temperature Range

Class 2 (IEC/EN60825-1/2007)

635±5nm

±4.5mm/15m

4°±1°

15m

approximately 12Hours

( )10 mw diode used to split beams

2×˝AA˝ (LR6)

IP54

-10 – 50℃ ＋ ℃

-20 – 70℃ ＋ ℃

or your statutory rights as a private non-professional user. We warrant our

laser level(s) against faults in materials and/or workmanship for one year

from date of purchase provided that:

• Proof of purchase is produced.

• Service/repairs have not been attempted by unauthorized persons;

• The product has been subject to fair wear and tear;

• The product has not been misused;

Defective products will be repaired or replaced, free of charge or at our

discretion, if sent together with proof of purchase to our authorized

distributor(s).

This Warranty does not cover faults caused by accidental damage, unfair

wear and tear, and use other than in accordance with the manufacturers’

instructions or repair or alteration of this product not authorized by us.

Repair or replacement under this Warranty does not affect the expiry date

of the Warranty.

To the extent permitted by law, we shall not be liable under this Warranty

for indirect or consequential loss resulting from faults in this product. This

Warranty may not be varied without our authorization. Calibration and

care are not covered by warranty.

NOTE:

The customer is responsible for the correct use and care of the tool. Moreover,

the customer is completely responsible for periodically checking the

accuracy of the laser, and therefore for the calibration of the tool

35m

Operating Time

Operation Modes

• Do not dispose of this product with household waste.

• Always dispose of batteries per local code.

• Please recycle in line with local provisions for the collection and disposal

of electrical and electronic waste under the WEEE Directive.

Specifications – Red Beams

1. Unlock the laser tool by switching to the Unlocked Position to turn the

laser tool ON and project the cross line.

2. Lock the laser tool by switching to the Locked Position to turn the laser

tool OFF and shut off the cross line.

3. Short press the key on the keypad while the laser tool is powered On in

the Unlocked Position to deactivate or activate out-of-self-leveling alert.

4. Laser beams will flash once every 5 seconds when out of self-leveling

range alert in the Unlocked Position is deactivated.

5. Laser beams will flash twice a second when the laser tool is out of its

self leveling range in the Unlocked Position with its self-leveling range

alert activated.
