Technaxx BT-X51 Bruksanvisning

Technaxx Radio BT-X51

Läs nedan 📖 manual på svenska för Technaxx BT-X51 (7 sidor) i kategorin Radio. Denna guide var användbar för 2 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/7
MusicMan® * User Manual
DAB+ Socket Soundstation BT-X51
Portable Bluetooth Kitchen Radio with DAB+ Radio and BT , FM
with 27 1 m display x 5m
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,
to which this user manual belongs, complies with the essential requirements of the
standards referred to the Directive . The Declaration of Conformity you RED 2014/53/EU
find here: www.technaxx.de/ Before using (in bar at the bottom “Konformitätserklärung”).
the device the first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 C/min. from German fixed-line
& C/min. from mobile networks). 42
Free Email: support@technaxx.de
The support hotline is available Mon-Fri from 9 am to 1 pm & 2 pm to 5 pm
This device has a rechargeable battery. It must be fully charged before
first use. Turn OFF nearby Bluetooth devices to avoid signal
interference!
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product. Share your experience and opinion on one of the
well-known internet portals.
Security and Disposal Hints for Batteries: Hold children off batteries.
When a child swallowed a battery go to a doctors place or bring the child
into a hospital promptly! Look for the right polarity ( ) and ( ) of batteries! + --
Always change all batteries. Never use old and new batteries or batteries of
different types together. Never short, open, deform or load up batteries!
Risk of injury! Risk of explosionNever throw batteries into fire! !
Hints for Environment Protection: Packages materials are raw materials
and can be recycled. Do not disposal old devices or batteries into the
domestic waste. Protect the device from contamination and Cleaning:
pollution (use clean drapery). Avoid using rough, coarse-grained materials
or solvents/aggressive cleaner. Wipe the cleaned device accurately.
Important Notice: Should battery fluid leak from a battery, wipe the battery
case with a soft cloth dry. Technaxx Deutschland GmbH & Distributor:
Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
Features
Soundstation with DAB+/DAB & FM radio, Bluetooth V4.2 & AUX-IN
Pairing with Bluetooth-enabled audio devices, Smartphones, Tablets, etc.
Rechargeable everywhere via sockets Exchangeable 800mAh battery for
portable use MicroSD card slot & USB port up to 32GB AUX input for  
connection of other audio devices Illuminated LCD display (2,7x1,5cm)
  Clock & Alarm function Power options: replaceable battery, MicroUSB or
AC adapter* (*included) Ideal to use at home or for traveling (wide radio
variety, easiest installation, brilliant sound quality
Technical specifications
Bluetooth
Bluetooth V4.2 ~/ 10m distance transmitting band 2.4GHz / /
radiated transmission power max. 2.5mW
Functions
DAB/FM, Bluetooth, MicroSD carte, USB flash drive,
AUX–IN
Output
RMS 3W (mono, Ø 5.2cm) speaker, Impedance 4 , Ø 5.2cm Ω
/ THD = 10%
Frequency speaker
100Hz kHz –20
DAB+ frequency band
170Hz 2 –40MHz
FM frequency band
87.5 108.0M Hz–Hz
AUX-IN
3.5mm stereo plug (analog audio input)
Music format
MP3 / WAV
SNR / DAB+ sensitivity
≥ 80dB / –101dB
Replaceable rechargeable Lithium 800mAh battery
3.7V
~2–3 hours (USB charging cable or socket power
plug*, *included)
~3 hours 4 hours (max. VOL, BT/SD card / ~ or USB)
~10 hours with 50% volume
~ hours (BT connection without playing music) 20
~6 month (in Power OFF mode)
DC 5V/1A or AC 220 50Hz –240V
External FM antenna (for DAB+ Radio), Length: 8.5& FM –33.5cm
PC & ABS
2 g / (L) 9.5 x (W) 10.5 x (H 460 ) .5cm
Package
contents
MusicMan® DAB Socket Soundstation BT-X51 -5C 800mAh , BL
Battery, Micro USB charging cable, AUX IN cable Socket –,
adapter, User Manual
Charging
Before first use open the battery cover, put battery into the compartment and
close . There are two ways of charging the it BT-X : Either connect the AC 51
adapter to the BT-X51 and plug it into an AC 220-240V 50Hz socket, or use
the MicroUSB port (12) by connecting a MicroUSB cable to the BT-X . 51
Connect the charging cable to a DC 5V/1A USB adaptor* (*not included) or
computer USB port.
The RED on the top shines bright while charging in the OFF status. When LED
the BT-X is fully charged, the RED LED turns off and battery signal on the 51
display will be full. (We suggest to turn off the BT-X51 while charging. It takes
a longer time to get fully charged if it is in usage when being charged.)
Product overview: Front / Back / Top / Side
