Technaxx® * User Manual
Internet Stereo-Radio TX-153
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares
that this device, to which this user manual belongs, complies with the
essential requirements of the standards referred to the Directive RED
2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/
(in bar at the bottom “Konformitätserklärung”). Before using the device the
first time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks). Free
Email: support@technaxx.de
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product. *Share your experience and opinion on one of the
well-known internet portals.
Hints for Environment Protection: Packages materials are raw
materials and can be recycled. Do not disposal old devices or
batteries into the domestic waste. Protect the device from Cleaning:
contamination and pollution. Avoid using rough, coarse-grained
materials or solvents/aggressive cleaner. Wipe the cleaned device
accurately. Distributor: Technaxx Deutschland GmbH & Co.KG,
Kruppstr. 105, 60388 Frankfurt a.M., Germany
Features
Radio reception via Internet
Listen to uncountable radio stations worldwide
250 favourite stations memory
2x 2W Stereo loudspeaker
USB port for media playback
Headphone output
2.4” TFT screen
Product details
1
Standby / Menu
6
TFT display
2
Left button
7
Favourite button
3
Line out / Headphone
8
Right button
4
Volume / Navigation / OK
9
Bass reex opening
5
USB-port
10
DC in
Power on/o
Use the supplied mains adaptor to connect the device to a household
mains socket.
When it is the rst time running the device, the system will ask you to
set Language and Network Congurations. You may setup the
network connection immediately, or set it later. Use Navigate to
select the desired option. Press Navigate/OK to conrm.
Press and hold Standby button when unit is power on, unit will go to
standby mode. Press again will make it again. on
Network conguration
WEP or WPA network conguration
Select “Yes” for the normal Wireless Network Conguration: Select
the required AP (SSID, name of your router) by turning Navigate” (4)
and confirm it by pressing “Navigate/OK” (4).
Enter WEP or WPA code ( -Fi Key) to connect the Wi-Fi network Wi
by select the correct character turning the “Navigate/OK” button.
Press (8) button to select the next character. In this condition,
press (2) button you can turn left and delete the left characters at
the same time: When the password is complete please press
“Navigate/OK” button to confirm.
Note: Below characters are available for the radio:
Numbers (from 0- 9)
Letters (from A to Z and from a to z)
Spezial characters ) (@,!,,#,$,%,&,*,’,+ and (,)
WPS PBC network conguration
Select “Yes WPS” when you would like set up with Wireless Network
(WPS PBC) feature:
If you are using a router with WPS button, you may set up the network
connection simple via WPS function. Enter it and go to press the
WPS button on your router within 120 seconds.
The connection between the router and the Radio will then be
congured automatically.
Select “No” when you do not want to install the network at the
moment.
Internet radio functions
Switch on “Standby” and rotate Navigate to scroll through the main
menu. Press OK (to enter sub menus or confirm settings). Press
to return to the previous menu. After the connection of any station is
succeeded, station information’s will be shown:
information content can be changed with ◄or ► button.
My Favorites
List of my favourite pre-set stations. It supports up to favourite 250
entries including stations and folder. During the station playing
screen, press and hold F AV(7) on the device to save the station as
favourite. You may replace the previous saved station to the new
one.
If the selected station has been saved, you cannot save it again. The
saved stations are showed under this menu. You may also press
