Sida 1/138

Οδηγίες Χρήσης

User’s Manual

Manuale d’installazione ed uso

Manual del usuario

ΚΛΙΜΑΤΙΣΤΙΚΟ ΤΟΙΧΟΥ ΤΥΠΟΥ INVERTER

WALL MOUNTED AIR CONDITIONER INVERTER TYPE

CONDIZIONATORE SPLIT

AIRE ACONDICIONADO DE PARED TIPO INVERTER

ΜΟΝΤΕΛΑ / MODELS / MODELLI / MODELOS

NTN/NTG-928R32

NTN/NTG-935R32

NTN/NTG-956R32

NTN/NTG-971R32

Ευχαριστούμε για την επιλογής σας στο κλιματιστικό TOYOTOMI.

Για τη σωστή του χρήση παρακαλούμε διαβάστε το εγχειρίδιο χρήσης προσεκτικά, πριν θέσετε τη μονάδα σε

λειτουργία και κρατήστε το σε καλή κατάσταση για μελλοντική αναφορά.

Thank you for purchasing our product.

• Before using this product, be sure to read this Instruction Manual to ensure proper usage. Please keep this

manual for later reference.

• Improper use of this product may result in a malfunction, failure, unexpected accident, or create a potential

hazard.

Grazie per aver scelto un prodotto TOYOTOMI.

Per un corretto funzionamento, leggere attentamente questo manuale prima di usare il condizionatore e

conservarlo per una futura consultazione.

Gracias por adquirir nuestro producto.

• Antes de usar este producto, lea este manual de instrucciones para asegurar el uso apropiado del mismo.

Por favor, guarde el manual para futura referencia.

• El uso inapropiado de este producto puede resultar en averías, fallos, accidentes inesperados o crear

peligro potencial.

 The appliance shall be stored in a room without continuously operating ignition sources. (for

example: open flames, an operating gas appliance or an operating electric heater.) Do not

pierce or burn the air conditioner.

 Appliance shall be installed, operated and stored in a room with a floor area larger than 5m.

 Air conditioner refrigerant can not charge more than 1.7kg.

 The storage of the air conditioner should be able to prevent mechanical damage caused by

accident.

 Air conditioner must be installed with stop valve cover.

 Appliance filled with flammable gas R32. For repairs, strictly follow manufacturer’s instructions

only. Be aware that refrigerants do not contain odor and may be tasteless.

 Read carefully the instruction manual before first use.

PRECAUTIONS

WARNING

Operation and Maintenance



This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved.



Children shall not play with the appliance.



Cleaning and user maintenance shall not be made by children without

supervision.



Do not connect air conditioner to multi-purpose socket. Otherwise, it may

cause fire hazard.



Always disconnect power supply when cleaning air conditioner. Otherwise,

it may cause electric shock.



If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons to avoid a hazard.



Do not use the air conditioner in lightning storm weather. Lightning might

cause damage.



Do not wash the air conditioner with water to avoid electric shock.



Do not use liquid or corrosive cleaning agent wipe the air conditioner. Doing

this may cause electric shock or damage to the unit.



Do not spray water on indoor unit. It may cause electric shock or

malfunction.



After removing the filter, do not touch fins to avoid injury.



Do not use fire or hair dryer to dry the filter to avoid deformation or fire

hazard.



Cleaning or maintenance MUST NOT be made by children. Supervision

must always be provided by an adult responsible for their safety.



Maintenance must be performed by qualified professionals. Otherwise, it

may cause personal injury or damage. In such case warranty will be invalid.

DANGER: This symbol indicates a dangerous situation that if not avoided could lead to death

or serious injury.

WARNING: This symbol indicates a dangerous situation that if not avoided could lead to death

or serious injury.

ATTENTION: This symbol indicates a dangerous situation that if not avoided could lead to

minor or moderate damage.

NOTICE: Indicates important information indicate the risk of material damage.

Appliance filled with flammable gas R32. If the refrigerant is leaked and exposed to an

external ignition source, there is a risk of fire.

Before use the appliance, read the owner’s manual first.

Before install the appliance, read the installation manual first.

Before repair the appliance, read the service manual first.

Refrigerant R32: GWP 675

The Refrigerant

 To realize the function of the air conditioner unit, a special refrigerant circulates in the system.

The used refrigerant is the fluoride R32, which is specially cleaned. The refrigerant is flammable

and inodorous. Furthermore, it can leads to explosion under certain conditions. But the

flammability of the refrigerant is very low. It can be ignited only by fire.

 Compared to common refrigerants, R32 is a nonpolluting refrigerant with no harm to the

ozonosphere. The influence upon the greenhouse effect is also lower. R32 has got very good

thermodynamic features which lead to high energy efficiency. The units therefore need a less

filling.

WARNING

 Do not use means to accelerate the defrosting process or to clean, other than those

recommended by the manufacture.

 If repair or maintenance is necessary, contact your nearest authorized Service Centre. Any

repairs carried out by unqualified personnel may be dangerous.

3GB

 The appliance shall be stored in a room without continuously operating ignition sources. (for

example: open flames, an operating gas appliance or an operating electric heater.) Do not

pierce or burn the air conditioner.

 Appliance shall be installed, operated and stored in a room with a floor area larger than 5m.

 Air conditioner refrigerant can not charge more than 1.7kg.

 The storage of the air conditioner should be able to prevent mechanical damage caused by

accident.

 Air conditioner must be installed with stop valve cover.

 Appliance filled with flammable gas R32. For repairs, strictly follow manufacturer’s instructions

only. Be aware that refrigerants do not contain odor and may be tasteless.

 Read carefully the instruction manual before first use.

PRECAUTIONS

WARNING

Operation and Maintenance



This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved.



Children shall not play with the appliance.



Cleaning and user maintenance shall not be made by children without

supervision.



Do not connect air conditioner to multi-purpose socket. Otherwise, it may

cause fire hazard.



Always disconnect power supply when cleaning air conditioner. Otherwise,

it may cause electric shock.



If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons to avoid a hazard.



Do not use the air conditioner in lightning storm weather. Lightning might

cause damage.



Do not wash the air conditioner with water to avoid electric shock.



Do not use liquid or corrosive cleaning agent wipe the air conditioner. Doing

this may cause electric shock or damage to the unit.



Do not spray water on indoor unit. It may cause electric shock or

malfunction.



After removing the filter, do not touch fins to avoid injury.



Do not use fire or hair dryer to dry the filter to avoid deformation or fire

hazard.



Cleaning or maintenance MUST NOT be made by children. Supervision

must always be provided by an adult responsible for their safety.



Maintenance must be performed by qualified professionals. Otherwise, it

may cause personal injury or damage. In such case warranty will be invalid.

DANGER: This symbol indicates a dangerous situation that if not avoided could lead to death

or serious injury.

WARNING: This symbol indicates a dangerous situation that if not avoided could lead to death

or serious injury.

ATTENTION: This symbol indicates a dangerous situation that if not avoided could lead to

minor or moderate damage.

NOTICE: Indicates important information indicate the risk of material damage.

Appliance filled with flammable gas R32. If the refrigerant is leaked and exposed to an

external ignition source, there is a risk of fire.

Before use the appliance, read the owner’s manual first.

Before install the appliance, read the installation manual first.

Before repair the appliance, read the service manual first.

Refrigerant R32: GWP 675

The Refrigerant

 To realize the function of the air conditioner unit, a special refrigerant circulates in the system.

The used refrigerant is the fluoride R32, which is specially cleaned. The refrigerant is flammable

and inodorous. Furthermore, it can leads to explosion under certain conditions. But the

flammability of the refrigerant is very low. It can be ignited only by fire.

 Compared to common refrigerants, R32 is a nonpolluting refrigerant with no harm to the

ozonosphere. The influence upon the greenhouse effect is also lower. R32 has got very good

thermodynamic features which lead to high energy efficiency. The units therefore need a less

filling.

WARNING

 Do not use means to accelerate the defrosting process or to clean, other than those

recommended by the manufacture.

 If repair or maintenance is necessary, contact your nearest authorized Service Centre. Any

repairs carried out by unqualified personnel may be dangerous.

5GB



If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons to avoid a hazard.



The temperature of refrigerant circuit will be high, please keep the

interconnection cable away from the copper tube.



The appliance shall be installed in accordance with national wiring

regulations.



Installation must be performed in accordance with applicable local

regulations by authorized licensed personnel only.



The air conditioner is the first-class electric appliance. It must be properly

grounding with specialized grounding device by a professional. Please

make sure it is always grounded effectively, otherwise it may cause electric

shock.



The yellow-green wire in air conditioner is grounding wire, which can't be

used for other purposes.



The grounding resistance should comply with national electric safety

regulations.



The appliance must be positioned so that the plug is accessible.



All wires of indoor unit and outdoor unit should be connected by a

professional.



If the length of power connection wire is insufficient, please contact the

supplier for a new one. Avoid extending the wire by yourself.



For the air conditioner with plug ，the plug should be reachable after

finishing installation.



For the air conditioner without plug, a circuit break must be installed in the

line.



If you need to relocate the air conditioner to another place, only the

qualified person can perform the work. Otherwise, it may cause personal

injury or damage.



Select a location which is out of reach for children and far away from

animals or plants. If it is unavoidable, please add the fence for safety

purpose.



The indoor unit should be installed close to the wall.



Instructions for installation and use of this product are provided by the

manufacturer.



The air conditioner is not allowed to use in a room that has running fire

(such as fire source, working coal gas ware, operating heater).



It is not allowed to drill hole or burn the connection pipe. These tasks shall

only be done by a licensed technician to ensure your safety.



Leak test is a must after installation.



Don’t install the air conditioner in a place where there is flammable gas or

liquid. It may cause fire even explosion.

This product contains fluorinated greenhouse gases



Do not repair air conditioner by yourself. It may cause electric shock or

damage. Please contact dealer when you need to repair air conditioner.



Do not extend fingers or objects into air inlet or air outlet. It may cause

personal injury or damage.



Do not block air outlet or air inlet. It may cause malfunction.



Do not spill water on the remote controller, otherwise the remote controller

may be broken.



When below phenomenon occurs, please turn off air conditioner and

disconnect power immediately and then contact the dealer or qualified

professionals for service.

 Power cord is overheating or damaged.

 There’s abnormal sound during operation.

 Circuit break trips off frequently.

 Air conditioner gives off burning smell.

 Indoor unit is leaking.



If the air conditioner operates under abnormal conditions, it may cause

malfunction, electric shock or fire hazard.



When turning on or turning off the unit by emergency operation switch,

please press this switch with an insulating object other than metal.



Do not step on top panel of outdoor unit or put heavy objects. It may cause

damage or personal injury.



Installation must be performed by qualified professionals. Otherwise, it may

cause personal injury or damage.



Must follow the electric safety regulations when installing the unit.



According to the local safety regulations, use qualified power supply circuit

and circuit break.



Install the circuit break. If not, it may cause malfunction.



An all-pole disconnection switch having a contact separation of at least

3mm in all poles should be connected in fixed wiring.



Including a circuit break with suitable capacity, please note the following

table. Air switch should be included magnet buckle and heating buckle

function, it can protect the circuit-short and overload.



Air Conditioner should be properly grounded. Incorrect grounding may

cause electric shock.



Don't use unqualified power cord.



Make sure the power supply matches with the requirement of air

conditioner. Unstable power supply or incorrect wiring or malfunction.

Please install proper power supply cables before using the air conditioner.



Properly connect the live wire, neutral wire and grounding wire of power

socket.



Be sure to cut off the power supply before proceeding any work related to

electricity and safety.



Do not put through the power before finishing installation.

 When it is cold and wet outside, the outdoor unit will develop frost over the heat exchanger which will decrease the

heating capacity. Then the air conditioner will start defrost function.

 During defrost, the air conditioner will stop heating for about 5-12 minutes.

 Vapor may come out from the outdoor unit during defrost. This is not a malfunction, but a result of fast defrost.

 Heating will resume after defrost is complete.

NOTES FOR TURNING OFF THE AIR CONDITIONER

 When the air conditioner is turned off, the main controller will automatically decide whether to stop immediately or

after running for several seconds with lower frequency and lower air speed.

EMERGENCY OPERATION

 If the remote controller is broken or lost, use emergency switch button to operate

the air conditioner.

 If this button is pushed when unit is OFF, the air conditioner will operate in AUTO

mode.

 If this button is pushed when unit is ON, the air conditioner will stop running.

ADJUSTMENT OF AIR FLOW DIRECTION

 Use U/D SWING up-down swing and L/R SWING left-right swing buttons on the

remote controller to adjust the air flow direction.

 For the models without L/R SWING left-right swing function, the fins has to be

moved manually.

Note: Move the fins while the air conditioner is not in operation, or your fingers might be

insured, and unit can also be damaged.

Never place your hands into the air inlet or outlet when the air conditioner is in operation.

PAY ATTENTION

 Open front panel of indoor unit.

 The connector must not touch the terminal board, and is positioned as shown in Fig.

CLEAN AND MAINTENANCE

CLEANING THE INDOOR UNIT

1. Turn off the unit and cut off the power supply. Wait after that at least 5 minutes before you start cleaning of the unit

otherwise there might be the risk of electric shock.

2. Clean the indoor unit (only the outside plastic parts) with dry or damp soft cloth in cold water. Do not spray or spill the

unit in order to clean it.

3. Clean air filters regularly, in order to avoid accumulation of dust that might affect the good performance of the air

conditioner. After removing the air filters, do not touch the metallic parts. It might cause injury.

4. Do not use water which temperature that exceeds 40oC to clean the front panel. Otherwise it may cause deformation

or discoloration.

5. Do not use liquids, hard detergents, thinner, gasoline or any other chemical product for cleaning. Otherwise plastic

parts of the air conditioner might be damaged or even cause electric shock.

CLEANING THE AIR FILTERS

 Remove pre-filters and heathy filters

 Use both hands to open the front panel for an angle from both ends of the panel in accordance with the direction of

the arrow, until it clamps in a certain position. Lift gently the pre-filters until they unclench, release them from the slot

and remove them.

Refrigerant leakage contributes to climate change. Refrigerant with lower

global warming potential (GWP) would contribute less to global warming than

a refrigerant with higher GWP if leaked to the atmosphere. This appliance

contains a refrigerant fluid with a GWP equal to [675]. This means that if 1 kg

of this refrigerant fluid would be leaked to the atmosphere the impact on global

warming would be [675] times higher than 1 kg of CO2 over a period of 100

years. Never try to interfere with the refrigerant circuit yourself or disassemble

the product yourself. These tasks should be carried only by licensed

authorized technician.

Ensure no following objects are under the indoor unit:



Microwaves, ovens and other hot objects.



Computers and other high electrostatic appliances.



Sockets that plug frequently.

The joints between indoor and outdoor unit shall not be reused, unless after re-flaring the

pipe.

The specifications of the fuse are printed on the circuit board, such as: 3.15A/250V AC, etc.

If your air conditioner is not fitted with a supply cord and a plug, an anti-explosion all-pole

switch must be installed in the fixed wiring and the distance between contacts should be no

less than 2.5 mm.

If your air conditioner is permanently connected to the fixed wiring, an anti-explosion

residual current device (RCD) having rated residual operating current not exceeding 30 mA

should be installed in the fixed wiring.

Power supply circuit should have leakage protector and air switch of which the capacity

should be more than 1.5 times of the maximum current.

USEFUL TIPS

Conditions where the Air Conditioner might not run normally

Cooling

Outdoor

>43oC (Apply to T1)

>52oC (Apply to T3)

Indoor

<18oC

Heating

Outdoor

>24oC

<-7oC

Indoor

>27oC

 When temperature is too high, the air conditioner may activate the automatic protection device, so that the air

conditioner could be shut down.

 When temperature is too low, heat exchanger of the air conditioner may freeze, leading to water dripping or another

malfunction.

 In long-term cooling or dehumidification with a relative humidity of above 80% (doors and windows open), there might

be water condenses or dripping near the air outlet.

 T1 and T3 refer to ISO 5151.

NOTES FOR HEATING

 The fan of indoor unit will not start running immediately after the heating is started to avoid blowing out cold air.

Produktspecifikationer

Varumärke:	Toyotomi
Kategori:	Luftkonditionering - Luftkylare
Modell:	Noboru NTN-NTG-928R32

Behöver du hjälp?

Om du behöver hjälp med Toyotomi Noboru NTN-NTG-928R32 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Luftkonditionering - Luftkylare Toyotomi Manualer

Toyotomi Satori STN-STG-918R32 Bruksanvisning

13 September 2024

Toyotomi Satori STN-STG-924R32 Bruksanvisning

7 September 2024

Toyotomi Satori STN-STG-909R32 Bruksanvisning

2 September 2024

Toyotomi Noboru NTN-NTG-928R32 Bruksanvisning

30 Augusti 2024

Toyotomi Kuro TKN-TKG-656R32 Bruksanvisning

29 Augusti 2024

Toyotomi Kuro TKN-TKG-635R32 Bruksanvisning

29 Augusti 2024

Toyotomi Noboru NTN-NTG-956R32 Bruksanvisning

25 Augusti 2024

Luftkonditionering - Luftkylare Manualer

Nyaste Luftkonditionering - Luftkylare Manualer

Sencor SAC MT9021C Bruksanvisning

7 Januari 2025

Daikin FTXM35M2V1B Bruksanvisning

7 Januari 2025

Daikin CTXA15A2V1BW Bruksanvisning

23 Oktober 2024

Daikin FTXM42M2V1B Bruksanvisning

23 Oktober 2024

Daikin FTXM20M2V1B Bruksanvisning

23 Oktober 2024

Bomann CL 6045 QC CB Bruksanvisning

19 September 2024

Bomann CL 6046 QC CB Bruksanvisning

19 September 2024

General Electric AS-24 Bruksanvisning

15 September 2024

General Electric AS-22 Bruksanvisning

15 September 2024

General Electric AS-16 Bruksanvisning

15 September 2024
