Sida 1/1

Mod.

EVV-2DIN

Mod.

EVV-4DIN

Mod.

EVV-R

EVV-2DIN (A)

EVV-4DIN (A)

EVV-R (A)

EVV-2DIN (B)

EVV-4DIN (B)

EVV-R (B)

66 45

1 2 3 4

5 6 7 8

EVV-2DIN

10 11 12 13 14 15 16 17 18

1 2 3 4 5 6 7 89

EVV-4DIN

EVV-R

25 4 3 16

23 4 6

1411 12 13 1510

8 9

17 18

2 3 41

6 7 85

SAFETY WARNINGS

1) Do not supply power to the instrument if any part of

it is damage d

2) Follow the connection diagrams carefully to install

the instrument

3) sConnect the measurement terminals to inaccessible part

or outside accessible parts with at least one main

insulation (EN 61010-1 )

4) Make sure that the electrical panel in which the appliance

is to be installed will prevent access to the terminals

after these have been installe d

5) The electrical system in the building in which the

instrument is to be installed should have an ove -curren r t

switch and protection devic e

6) The instrument is designed to be installed in location s

with ove voltage catego III and pollution level r ry

2 )(EN 61010-1

EVV-2DIN

Cod Mode Rang Resol. Overl. Imp.e l e

Imped.

VM244100 EVV-2DI 100N V AC V Vn k0,1 1,2 500 Ω

VM245800 EVV-2DIN 1 V DC 1 mV Vn k1,2 10 Ω

VM246600 EVV-2DI 10N V DC mV Vn k10 1,2 50 Ω

VM247400 EVV-2DI 100N V DC V Vn k0,1 1,2 500 Ω

VM248200 EVV-2DI 600N V DC 1 V Vn 2 M1,0 Ω

EVV-4DIN

Cod Mode Rang Resol. Overl. Imp.e l e

Imped.

VM262300 EVV-4DIN 1 V DC 1 mV Vn k1,2 10 Ω

VM263100 EVV-4DI 10N V DC mV Vn k10 1,2 50 Ω

VM265600 EVV-4DI 600N V DC 1 V Vn 2 M1,0 Ω

EVV-R

Cod Mode Rang Resol. Overl. Imp.e l e

Imped.

VM295300 EVV-R 1 V DC 1 mV Vn k1,2 10 Ω

VM296100 EVV-R V DC mV Vn k10 10 1,2 50 Ω

VM297900 EVV-R V DC V Vn k100 0,1 1,2 500 Ω

VM298700 EVV-R V DC 1 V Vn 2 M600 1,0 Ω

TECHNICAL SPECIFIC ATIONS

•Po :wer supply 115/230 V AC (-15%/+10%) 50/60 Hz

•Reading: 3 , 7 display digits segments

•Absorption: 5 VA

•Precision ±(0,5% end of scale dgt: + 1 )

•Minimum values measured 4% of the end scal : e

•Termin tion ona : 6 mm

2block

•Oper ting temper ture -10 °C +50a a : ÷ °C

•S a a : ÷ °Ctor ge temper ture -40 °C +90

•Rel tive humidity 20%÷90 RH non condensina : % g

•Insul tion wer supply and measurement circuit galvanicallya : po

insul ted main insul tion level (EN 61010-1a at a )

•Container:

— NEVV-2DI : 2 y, cmodule DIN colour RAL-7035 gre in lass V-0

ma mterial in accordance with the UL 94 nor

— NEVV-4DI : 4 y, cmodule DIN colour RAL-7035 gre in lass V-0

ma mterial in accordance with the UL 94 nor

User Manua l

DIGITAL VOLTMETER

Read all the instructions carefull y

Legend:

— E RVV- : estandardised dimensions 72x72 mm in accordanc

with the DIN 43700 norm s

A) Dimensions

B) Connection di gram a s

OPERATION

1) ”If the display sh ws o “HHH during oper tion this means a ,

th the dimension under examin tion is gre ter than theat a a

maximum value admissible .

2) If the value in question is less than 4% of the scale the displa , y

will sh ow “000”

REFERENCE STANDARDS

Conformity to the European Union directives :

2006/95/EC (Low Voltage - LVD)

2004/108/EC (Electromagnetic compatibility- EMC)

is de lared with reference to the foll wing harmonised c o

standards:

EN 61010- 1

EN 61000-6-2 / EN 61000-6-4

Vemer S.p.A.

I - 32032 Feltre (BL) • Via Camp Lonc, 16

Tel +39 0439 80638 • Fax +39 0439 80619

e-mail: info@vemer.it - web site: www.vemer.it

V3IS00260-011-112008
