Sida 1/5
Objective Lens
Ocular Lens
IPD
The eyecups on a Razor HD binocular twist up and down so any
viewer can see the full field and enjoy comfortable viewing—with
or without eyeglasses.
When not using eyeglasses or
sunglasses, keep the eyecups fully
extended. For the best viewing
when viewing through eyeglasses,
twist eyecups down.
Adjust the interpupillary distance
The interpupillary distance (IPD) is the distance between the centers
of the left and right eye pupils. Match the IPD of your eyes to that of
the binocular so that you see a single image that is free of shading.
BASIC OPERATION
Adjust the eyecups
Rotate the binocular barrels
inward or outward to line your
eyes up with ocular lenses.
Distance between the centers
of the ocular lenses.
Twist-up Eyecup
Strap
Attachment
Tripod Adapter
Socket
Center Focus
Locking
Diopter
3 2
Properly focus the binocular
For the best views, follow this two-step
process to properly adjust the center focus
and diopter. Choose an object that is about
20 yards away from you and stay in the same
spot until you have adjusted the binocular
for your eyes.
1. Adjust the center focus—start by closing your right eye
or covering the right objective lens
with your hand. Focus your left eye
on the object and adjust the center
focus wheel until the image is in focus.
Leave the center focus in this position
as you adjust the diopter.
2. Adjust the diopter—start by closing your left eye or covering
the left objective lens with your hand. Lift the diopter ring to
unlock and, looking through your
right eye, adjust the diopter so that the
object is in focus. Make note of this
diopter setting in case you need to set
it again. Push the diopter ring down to
lock—from this point on, you will only need to use the center
focus wheel.
The Razor HD comes with a rainguard for the ocular lenses and
tethered objective lens covers. Use these covers to protect the
lenses whenever you are not viewing.
Lens Covers
The protective case of the Razor HD provides safe storage between
viewing sessions. The carry strap is already attached to the case.
Carry Case
ACCESSORIES
Attach the padded neckstrap to the Razor HD in three simple
steps. Begin with the right barrel of the binocular and repeat the
process for the left barrel.
Neckstrap
1. Push a few inches
of the strap through
the strap attachment
on the binocular.
3. Adjust the overall
length, then pull tight
until strap secured
within the buckle.
2. Hold the buckle and
thread the end of the
strap through the buckle.
Note: If using another type of strap, never attach metal o-rings directly
onto the strap attachment.
Adjust Diopter Setting
54
Produktspecifikationer
| Varumärke: | Vortex |
| Kategori: | Kikare |
| Modell: | RAZOR HD |
