O 4309/43H-11

OPERATING INSTRUCTIONS OIL RADIATOR

OIL RADIATOR

OIL RADIATOROIL RADIATOR

UPUTSTVO ZA UPOTREBU ULJANI RADIJATOR

ULJANI RADIJATOR

ULJANI RADIJATORULJANI RADIJATOR

GBR

SRB

O 4309/43H-11

OPERATING INSTRUCTIONS OIL RADIATOR

OIL RADIATOR

OIL RADIATOROIL RADIATOR

GBR

Warning: The radiator must not be located immediately below a socket-outlet.

-4- -1-

Usage:

1. There are two power switches, you can adjust them on your requirement.

2. Please make sure that the rated voltage is suitable and the rated electric

current is not lower than 10A.

3. When using, turn the temperature switch deasil to the max position and the

room temperature will rise higher and higher.

4. If the room temperature is too high during use and you want to lower it,

adjust the switch to “middle” or “low” position.

5. During use the radiator will keep the required temperature, when the room

temperature gets to the require temperature the radiator will stop

automatically. When the room temperature is lower than required, the

radiator will start working automatically.

6. Turn off the thermostat knob, the indicator light will be off.

Technical parameters:

Model

Rated voltage

Rated

frequency

Rated

power

Specication

Protection against

electricity category

CR403-7

230V

50Hz

1500W

7pieces

CR403-9

230V

50Hz

2000W

9pieces

CR403- 11

230V

50Hz

2500W

11pieces

Electric Drawing

Oil Radiator Instruction Manual

 Please read this manual carefully before using your oil radiator, so that

you can use it correctly.

 Please keep this manual handy for future reference.

Brief Introduction of the Product

The Oil Radiators adopt the electron thermal-tube as heating element to

heat the oil sealed in. This series of product has the features as high quality

and long using life. It is suitable for family and ofce.

Feature:

1. High quality and long using life.

2. High efciency heating oil sealed in, quickly heating, without peculiar

smell, without noise.

3. There is one knob switches and change into three different power.

4. There is temperature fuse to prevent overheating.

5. Convenient to use and easy to collect.

6. Truckled design, easy to move.

Notes:

1. The radiator should be placed on at ground. You must not place it

precipitately or tipsily.

2. Please do not use the radiator in place full of combustible or explosive a

gas, bathroom or a shower or a swimming pool.

3. For your safety, do not put your hand or stick into the hole or slot of the

radiator. (Especially for children).

4. When in use, the distance between the radiator and the wall and any other

objects should be above 20cm. Within 1m above its top there should not be

any other thing for the gas convection.
