Sida 1/8
-
O 6 09/6H-1 111
OPERATING INSTRUCTIONS OIL RADIATOR
OIL RADIATOR
OIL RADIATOR
OIL RADIATOROIL RADIATOR
UPUTSTVO ZA UPOTREBU ULJANI RADIJATOR
ULJANI RADIJATOR
ULJANI RADIJATOR
ULJANI RADIJATORULJANI RADIJATOR
GBR
SRB
-
O 6 09/6H-1 111
OPERATING INSTRUCTIONS OIL RADIATOR
OIL RADIATOR
OIL RADIATOR
OIL RADIATOROIL RADIATOR
GBR
Warning: The radiator must not be located immediately below a socket-outlet.
-4- -1-
Usage:
1. There is one power switch, you can adjust it to your requirements.
2. Please make sure that the rated voltage is suitable and the rated electric
current is not lower than 10A.
3. When in use, turn the temperature switch deasil to the max position and the
room
temperature will rise higher and higher.
4. If the room temperature is too high during use and you want to lower it,
adjust the switch to “middle” or “low” position.
5. While in use, the radiator will keep the required temperature, when the
room temperature gets to the required one, the radiator will stop
automatically. When the room temperature is lower than required, the
radiator will start working automatically.
6. Turn o the thermostat knob, the indicator light will be o.
Electric Drawing:
Oil Radiator Instruction Manual
Please read this manual carefully before using your oil radiator, to ensure
correct usage.
Please keep this manual handy for future reference.
Brief Introduction of the Product
The oil Radiators adopt the electron thermal-tube as heating element to
heat the oil sealed in. This product series has the features as high quality and
long-lift usage. It is suitable for household and oce use .
Feature:
1. High quality and long-lift usage.
2. High eciency heating oil sealed in, quick heating, without peculiar smell ,
without noise.
3. There are two switches and change into three dierent power.
4. There is temperature fuse to prevent overheating. a
5. Convenient to use and easy to assembly.
6. s designed for easy movement. Wheel
Notes:
1. The radiator should be placed on at ground. You must not place it
precipitately or unsteadily.
2. Please do not use the radiator anywhere combustible or explosive gas,
bathroom or a shower or a swimming pool.
3. For your safety, do not put your hand or stick into the hole or slot.
(Especially for children).
4. When in use, the distance between the radiator and the wall or any other
objects should be over 20cm and 1m above its top, for the gas convection.
Technical parameters:
Model
Rated
voltage
Rated
frequency
Rated
power
Protection against
electricity category
C61-7
230V
50Hz
1500W
I
C61-9
230V
50Hz
2000W
I
C61-11
230V
50Hz
2500W
I
