item #2273
User’s Manual
Mini Stepper Master™
Mini Stepper Master
™
by Wagan Tech
1www.wagan.com
User’s Manual—
Dear Valued Customer,
Thank you for purchasing Wagan Tech Mini Stepper fitness equipment!
We know you will be more than satisfied with our products. This user
manual contains instructions on how to properly operate and care for your
new Mini Stepper. If you have any questions with regards to the assembly
or operation of this product, please call us at 1-800-231-5806 extension
101 or email us at customerservice@wagan.com.
Please take note that any specifications, diagrams and/or functions
described in this instruction manual may have changed since its printing,
and we will not be able to provide separate notice of any changes and/or
improvements made to the product.
Note: It is important to adhere strictly to the instructions that are outlined in
this manual for correct operation and maintenance of the equipment. We
will not be held liable for any bodily injury or property damage resulting
from misuse of the equipment.
Assembly
1. Run the Power Cable (1) through the Stand Tube (2).
2. Connect the Stand Tube (2) to the main frame (3) with supplied short
bolts and washers (4).
3. Run the Power Cable (1) through the Connecting Tube (5).
4. Connect the Connecting Tube (5) to the Stand Tube (2) with supplied
short bolts and washers (4).
5. Connect the Power Cable (1) to the underside of the LCD Meter (6)
and then proceed to install the LCD meter (6) onto the very top of the
Connecting Tube (5).
6. Connect the two Handle Bars (7) to either side of the Connecting
Tube (5) with supplied long bolts and washers (8).
Mini Stepper Master
™
by Wagan Tech
3www.wagan.com
User’s Manual—
Tension Adjustment
1. Locate the tension key, which looks like a
screw with a triangular cap (Figure 1).
2. Locate the threaded hole on the opposite side
on the stepper (Figure 2).
3. Twist the tension key slowly into the threaded
hole on the backside of the main frame (2).
4. One side of the stepper will be automatically
lifted up as the tension key is screwed into the
main frame (2). As the tension key is fastened
into the main frame, the amount of force
required to screw the key in increases (Figure
3). Hint: Lift up one of the stepper pedals
manually before inserting the tension key.
5. Once the tension key has been properly
adjusted, please test out the stepper by
stepping on each pedal in an alternating
fashion.
6. If the tension key has been properly installed,
one pedal will be up while the other will be
down as you put pressure on either of the
pedals.
7. Adjust the tension key according to how firm
you would prefer the steps to be.
8. If the tension key is all the way in, the pedals
have been adjusted to provide the most
intense workout available.
9. If the tension key is loosened so that it is
barely screwed in, the pedals have been
adjusted to provide the least demanding
workout available.
Figure 1
Figure 2
Figure 3
