Sida 1/24
WITH
For Bluetooth®connection to mixer showers use the Instant
Match Premium with Whale Sense SDA074T (see Whale Sense
Quick Connect Guide included with this kit for more information)
www.whalepumps.com
Technical Helpline: 0345 9090 912
Installation guidelines for Models
SDP303T Whale INSTANT MATCH®PREMIUM Kit
400,000
WHALE KITS INSTALLED IN THE UK
www.youtube.com/WhaleHealthcare
Please leave this booklet with the end user
after installation and demonstration
lumbing of the Waste Pipe
lumbing of the Waste Pipe
User Warnings
• This appliance may be used by children from 8 years and above, by persons with reduced physical, sensory
or mental capabilities and by persons who lack experience of the system, if they have been given instructions
concerning the use of the application in a safe way and they understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be carried out by children without supervision.
• If any components or cords are damaged, it must be replaced by a qualified person to avoid a hazard.
End User Help
1. My pump is turning on but not taking the water away
Please contact a plumber to check for blockages, air leaks, and also the condition of the internal rubber
components. For video assistance on how to inspect and change the rubber components, please visit
www.whalepumps.com For further assistance or to request a new tricuspid valve please contact our
Technical Helpline on 0345 9090 912.
2. My pump is not working
Please turn on your shower and listen to or feel for vibration of the pump as it starts. If you hear or feel your
pump turn on, please contact a plumber to check for blockages or air leaks in the pipework, and the condition of
the internal rubber components. For video assistance on how to check the pipework for issues and for a video
instructing you how to inspect and change the pump components, please visit www.whalepumps.com
If your pump doesn’t turn on, first check the power is on at the fused spur. If on, please contact an electrician
to inspect the power to the pump, or contact our Technical Helpline on for further assistance.0345 9090 912
3. My Pump is running slow/labouring/cutting out
Contact a plumber to check for blockages. If there are no blockages then contact our Technical Helpline
on for further assistance.0345 9090 912
4. My pump is constantly running
Please contact our Technical Helpline on for further assistance before contacting an electrician to0345 9090 912
carry out tests on the equipment.
5. My pump isn’t turning on
If your pump doesn’t turn on check that the power is turned on at the fused spur. If on, please contact an
electrician to inspect the power to the pump. For further assistance please contact our Technical Helpline on
0345 9090 912.
6 My pump turns on randomly
Please contact a plumber to fit non-return valves to your hot and cold pipework before the flow switches to
prevent this from happening.
7 How do I register my warranty?
Please complete and return the warranty registration form supplied with your pump,
or complete the online form at: www.whalepumps.com
0345 9090 912
info@whalepumps.com
www.whalepumps.com
Whale, 2 Enterprise Road,
Bangor, Co. Down,
BT19 7TA, N.Ireland
WARNING
2
Thank you for purchasing this Instant Match Premium product.
Whale®is the market leader in pumped shower drainage kits.
These kits have the reputation of working reliably for many years
without requiring maintenance.
The front cover shows the product installation in an apartment with the components in a concealed access.
Assess your installation prior to fitting to ensure that the unit will be situated in an accessible location.
Typical installations would have these components in an adjacent cupboard i.e. airing cupboard or in a false
wall with an access panel. Do not fit the pump cover in these locations.
Incorrect installation may invalidate the warranty.
This kit has been designed for the pumping of shower waste water. The Instant Match Premium control unit uses flow
sensors to measure the flow rate of water into the shower. The control unit uses the signals sent from the flow sensors
to adjust the pump speed to match the flow of water from the shower. This minimises suction noise at the gulley. When
the shower is turned off, the flow sensors send a signal to the control unit and after a pre-set time delay the pump turns
off. After a further 15 minutes the pump will automatically switch on for a short period of time at a reduced pumping
speed, removing any run off water pooled in the shower area. The pump has the ability to run dry without causing
damage. Non-return valves in the pump head prevent smells from entering the bathroom area from the waste pipe.
Installation Warnings
Before installation please read the instructions. All electrical and mechanical components (Transformer, Pump and Sika ®
flow sensors) must be accessible after installation.
• The Instant Match Premium is designed to work on shower bases with a minimum of a 1:40 fall to the gulley.
Where the fall is insufficient, the water will not refill the gulley rapidly enough and so suction noise will be increased.
We recommend the use of a shower former as this eliminates the risks of pooling caused by insufficient fall to the gulley.
• Forming a shower base by hand is a highly skilled task and must be carried out by a trained installer. Do not
attempt this if you are unsure and seek professional advice.
• The maximum flow rate of the shower that the pump is designed to work with is 12 ltrs/min.
• Avoid plumbing the pump outlet into the waste piping that other appliances drain into as there is a risk of
induced syphoning. Use an anti-syphon trap in these situations. (See page 7)
• In installations where the floor is being formed in the screed, we recommend the following minimum falls:
40mm in 1m, 20mm in 500cm,10mm in 250cm.
• Plumbing must comply to latest WRAS standards.
• The electrical wiring must conform to wiring regulations BS7671 2018 Part 7 (18th Edition).
• Pipework must be secured to prevent vibration and noise.
• Ensure that the water fall from the shower head is as close to the gulley as possible.
WARNING
3
Plumbing of the Waste Pipe
Principles of Operation
