Installation guidelines for
Models:
BP1558B Shower Tray Kit
BP1578 Wet Floor Kit
This booklet should be given to the customer after installation and demonstration
For illustration purposes only
Typical flow switch electric shower installation with tray gulley.
Including
CONNECT
Flow switch
Transformer
Pump
15 mm pipe
Unswitched
5A fused spur
22 mm pipe
WITH
Electric shower
Installation & maintenance videos available at:
www.youtube.com/WhaleHealthcare
The front cover illustrates the product in typical healthcare
installations.
Assess your installation prior to tting to ensure that the
pump, transformer and ow switch will be situated in an
accessible position.
Typical installations would have these components in an
adjacent cupboard i.e. airing cupboard or in a false wall with
an access panel. The cover does not have to be used in
such areas.
Incorrect installation may invalidate the warranty.
This kit has been designed for the pumping of shower
waste water.
• When the shower is turned on the ow switch(es)
provide a signal to the transformer to supply dc voltage
to the pump*. The pump activates with a brief clearing
cycle before the pump runs at its normal (often lower)
pumping speed.
* For a direct connection to compatible showers
with an internal on/off switch, please see Page 11.
• When the shower is turned off, the ow switch sends a
signal to the transformer and after a pre-set time delay
stops the supply of dc voltage to the pump.
• After a further 15 minutes, the pump will switch on
automatically for a short time at a reduced pumping
speed removing any water pooled in the shower area.
• The pump has the ability to run dry without causing
damage to the pump.
• Before installation read the instructions.
• Plumbing installation must comply with the plumbing
regulation as specied in the latest WRAS leaet for
plumbing systems.
• The electrical wiring must conform to BS7671: 2018
(18th Edition)
Contact the Technical Helpline
if you need further assistance 0345 9090 912
Principles of Operation
Index
Principles of Operation 2
List of Parts Included in the Kit 4
Accessories and Spares 4
Plumbing Specication 6
Plumbing Gulley 7
Plumbing of Waste Pipe 8
Fitting of Flow Switch/Filter 8
Transformer Installation 9
Electrical Connections 9
Active Link Diagnostics 9
Transformer Settings 10
Direct Connect 11
Thermostatic Electric Shower Connections 11
Safety Warning 12
Installation Testing & Repair 12
EU Declaration of Conformity 13
Statement of Limited Liability 13
Specication 14
Fault Diagnosis 15
Illustrations
1.0 90 mm Gulley 4
1.1 Pump Mounting Instructions 5
1.2 Plumbing Layout 6
1.3 Pump Orientation 6
1.4 Rotation of Pump Head 6
1.5 Mixer Valve Installation Illustration 7
1.6 Tray Gulley Installation 7
1.7 Wet Floor Gulley Installation 7
1.8 Plumbing ‘Waste Fittings’ 8
1.9 Macerator Connections 8
2.0 Flow Switch Orientation 8
2.1 Transformer Mounting 9
2.2 Pump Mounting (Electrics) 9
2.3 Wiring Diagram 9
2.4 Transformer Settings 10
2.5 Shower Cable Connections to Mira 11
2.6 Shower Cable Connections to Redring 11
2.7 Shower Cable Connections to Triton 11
2.8 External Pipework Test 12
2.9 Air Leak Test 12
www.whalepumps.com/psd
Reliability
Designed and built to
provide years of
maintenance - free life
Innovation
Continuous product
improvement
Service
Nationwide service
network and dedicated
technical helpline
A manufacturer with people,
innovation and service at our heart.
Video Support:
For Installation and maintenance tutorials visit:
www.whalepumps.com/psd
and click on the installation/support section, or:
www.youtube.com/whalehealthcare
