Thank you for choosing this WyreStorm Express product.
Please read these instructions carefully before installing to avoid complications later.
Instruction Manual
exp-SP-0104-4K
WyreStorm Express™ 1x4 HDMI 4K Splitter
RoHS
2
Contents
Introduction
Features
Introduction
Features
Safety Precautions
Specication
Panel Description
i. Front
ii. Rear
Connection & Operation
Troubleshooting
FAQ
Maintenance
Product Service
Mail In Service
Warranty
Warranty Limits and Exclusions
Installation Notes
Ultra Slim, Ultra High Denition. The WyreStorm Express
EXP-SP-0104-4K 1x4 4K Splitter enables lossless
duplication and distribution of a single HDMI UltraHD
or HD source to up to 4 connected outputs for simple,
exible and reliable content replication to multiple display
devices supporting resolutions up to 4Kx2K.
Featuring HDMI 1.4a specication supporting data rates
up to 10.2Gb/s, for lossless audio/video formats, full
3D and Lip Sync, the EXP-SP-0104-4K also includes
24bit True Color with chroma subsampling rate of 4:2:2
for 4K color palette and 36bit Deep Color for 1080p
transmissions.
Automatic HDCP and EDID management continuously
negotiates and authenticates communication between
connected devices, ensuring simultaneous distribution
of source content to all outputs, while also maintaining
signal integrity via internal equalization and amplication
to output devices.
Systems can be further expanded by cascading multiple
EXP-SP-0104-4K units to create larger distributions; with
4K transmissions cascaded twice and 1080p signals up
to 12 times to the same model units for exible, scalable
solutions for residential and commercial applications.
Furthermore, with the addition of an in-line WyreStorm
EXP-SCL-DAC-4K scaler/Dolby downmixer between
splitter and display device, combined 4K, HD and
multichannel or stereo audio distributions can be created
without risking resolution or audio disparity between
devices.
As such, the EXP-SP-0104-4K represents an ideal
solution wherever simple-yet-reliable distribution of single
HDMI source to multiple outputs is required, with the
versatility and cost-eciency to ensure systems are just
as easily expanded or adjusted to meet the needs of any
application.
• 1 HDMI Input to 4 simultaneous HDMI Outputs
• Fully 4K compatible - 3840 (UHD) and 4096 (DCI) 2160
@ 30Hz with 4K color palette 4:2:2
• Plug and Play connectivity - automatic EDID and HDCP
device communication
• Low prole 18mm/0.7 for greater installation
convenience
• Create combined 4K/HD distributions with additional
WyreStorm inline scaler (sold separately)
• Supports 4K resolutions up to 4096x2160@30Hz and
HD resolutions up to 1080p@60Hz
• 4K color @ 24bit with 4K chroma subsampling color
palette 4:2:2, 1080p @ 36bit
• Supports HD resolutions up to 1080p@60Hz
• Transmission distances up to 10m/33ft (4K/1080p
input, 4K output), 15m/49ft (1080p output) using
standard HDMI cables
• Multichannel audio supported (mirrors source)
• Full 3D compatibility up to 1080p - frame packing/
sequential (Blu-ray) and interlaced stereoscopic
(satellite/cable broadcasts)
• Threaded power port for locking or standard 5v DC
connection
• Front panel LED indication for I/O and Power
connectivity
• Slimline chassis for space-saving local installation
• Supports HDMI 1.4a with automatic HDCP and EDID
management between devices
• Automatically adjusts signal feedback, equalization and
amplication for easy, reliable installation
• Units cascadable to create larger systems: 1080p up
to 12 times, UHD 4K up to two times
• Easily create cost eective, scalable combined 4K/HD
distributions by connecting WyreStorm EXP-SCL-DAC-
4K scaler with Dolby downmixer (sold separately)
3
Specication
Safety Precautions
WARNING
To reduce the risk of re, electric shock
or product damage:
Package Contents
Input 1 x HDMI INPUT (Type A female connector)
Output 4 x HDMI OUTPUT (Type A female connector)
Input/Output Signal Type HDMI 1.4a, 3D, DVI 1.0
Input/Output Resolution Support 480i, 480p, 576i, 576p, 720p, 1080i, 1920x1080p @ 60Hz,
3840 (UHD), 4096 (DCI) 2160 @ 30Hz
Color 4K color @ 24bit with 4K chroma subsampling color palette
4:2:2, 1080p @ 36bit
Maximum Data Rate 10.2 Gbps
Maximum Pixel Clock 340 MHz
Input Video Signal 0.5~1.2 V p-p
Input DDC Signal 5V
Video Impedance 100Ω
Power Supply 5V DC 1A
Power Consumption 1080p: 1.2 W (Max.), 4K: 1.7 W (Max.)
Operating Temperature 32°F ~ 95°F (0°C ~ 35°C), 10% ~ 90%, non-condensing
Storage Temperature -4°F ~ 140°F (-20°C ~ 70°C), 10% ~ 90%, non-condensing
BTU Rating (British Thermal Unit) 25.59
ESD Protection ±4 kV (Contact discharge) , ±8 kV (Air discharge)
Product Dimension (WxHxD) 140mm/5.5” x 18mm/0.7” x 65mm/2.6”
Product Weight 0.26 kg
Certication CE, FCC, RoHS
1. Do not expose this apparatus to rain, moisture,
sprays, drips or splashes and ensure that no objects
containing liquids are placed on the apparatus,
including cups, glasses and vases.
2. Do not place this unit in a conned space such as
enclosed shelving, cabinets or bookshelves. Ensure
the unit is adequately ventilated.
3. To prevent the risk of electric shock or re hazard
due to overheating, do not cover the unit or obstruct
ventilation openings with material, newspaper,
cardboard or anything that may restrict airow into
the unit.
4. Do not install near external heat sources such as
radiators, heat registers, boilers or any device that
produces heat such as ampliers or computers and
• 1 x EXP-SP-0104-4K WyreStorm Express™ 1x4 HDMI
4K Splitter
• 1 x Quickstart guide (Quickstart and full manual
downloadable from wyrestorm.com)
• 1 x 5v DC 1A power adapter
• 2 x Mounting brackets
do not place near sources of naked ame.
5. Unplug apparatus from power supply during
lightening storms or when unused for long periods of
time.
6. Protect the power cable from being walked on,
pinched or restricted in any way, especially at plug
connections.
7. Only use attachments/accessories specied by the
manufacturer.
8. Units contain non-servicable parts - Refer all servicing
to qualied service personnel.
