Sida 1/36

Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

Thank you for choosing this WyreStorm product.

Please read these instructions carefully before installing to avoid complications later.

WyreStorm Pro Plus PoH HDBaseT Solutions

MX-0808-PP-POH MX-0808-PP-POH-Custom

Fixed Pro Plus chassis featuring PoH

HDBaseT out, mirrored HDMI out, HDMI in, IR

input transmission card.

Modular Pro Plus chassis with selection

of customisable analogue and digital PoH

transmission cards.

Instruction Manual

2Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

Contents

1. Introduction

CONTENTS AND INTRODUCTION

The WyreStorm MX-PP-POH matrix range oers the

ultimate in exible and aordable Class B HDBaseT™

integration; for projects that demand the benets

of HDBaseT transmission, such as signal stability,

distribution of full 1080p HD video, HD audio, Power-over-

HDBaseT (PoH) and control via IR and routable serial

control over a single Cat5e/6 cable up to 70m/230ft, yet

may not require the transmission distance or feature set

of full Class A HDBaseT.

Models in the MX-PP-POH range offer an HDBaseT Pro Plus

matrix solution with PoH support for power passed along a

single Cat5e/6/7 cable along with transmissions and control

commands to enable receivers to operate without the need for

local mains power at display zones.

This not only offers more exibility and convenience during

installation but also greater energy efciency and an easier

installation than a permanent mains connection as less power

supplies are required for devices.

MX-PP-POH matrices also feature routable serial commands

via RS232 for individual screen control in display zones using

a WyreStorm Enado or third party control system – all of which

adds up to a powerful package for applications of any size or

budget.

MX-PP-POH matrices are available either in factory standard

conguration, featuring HDMI input to HDBaseT and mirrored

HDMI Output, or a modular customisable conguration featuring

a matrix chassis and selection from a range of multi-format

digital and analogue transmission cards that enable distribution

and control to be tailored to the specics of the project like

never before.

Using our Virtual Rack system-planner available at

www.wyrestom.com, combinations of matrices and

transmission cards can be selected and customised to personal

specication, with orders submitted online, custom-built and

shipped directly within 10 days from initial spec to nal delivery.*

MX-PP-POH matrix solutions from WyreStorm offer incredible

exibility and versatility of custom transmission selection

combined with the power and features of HDBaseT for solutions

where stable HD transmission and control over distance is

required, whether in a residential or commercial setting.

For further information on this product and other WyreStorm

ranges, visit our website or download our latest product guide.

www.wyrestom.com

*Subject to stock availability

Introduction

Features

Safety Precautions

Package Contents

Front Panel Description

i. Rear Panel Description - MX-0808-PP-POH

ii. Rear Panel Description -MX-0808-PP-POH-CUSTOM

Card Options

i. Typical Application - TX-POH-010 Transmission Card

ii. Typical Application - All Cards

Connection

Basic Operation

Basic Remote Control

Advanced Remote Control

Advanced Operation

RS232 Application Scenarios - Understanding

RS232 Connection & Signals

Routable RS232 with MX-PP-POH

Routing Serial Commands from the MX-PP-POH

QuickSync Setting

EDID Management - About EDID

Before EDID Adjustments

EDID Presets

COM CTL

Troubleshooting

FAQ

Maintenance

Provided Service

Mail In Service

i. Warranty

ii. Warranty Limits and Exclusions

i. Installation Reference Log - Input Reference Log

ii. Installation Reference Log - Output Reference Log

Specication

Technical Support: support@wyrestorm.com US: +1 866 677 0053 EU: +44 (0) 1793 230 343

2. Features

3. Safety Precautions

FEATURES AND SAFETY PRECAUTIONS

• Class B HDBaseT technology for one-cable

transmissions of full HD 1080p video @60Hz, HD

multichannel audio, routed control and power up

to 70m/230ft, under perfect conditions

• HDBaseT more resistant to electrostatic interference

than conventional distribution

• (MX-0808-PP-POH) - factory congured with 8 standard

transmission cards: HDBaseT PoH out, mirrored HDMI

out and HDMI In

(MX-0808-PP-POH-CUSTOM) - selection of digital

and analogue card options for customisable modular

HDBaseT PoH congurations

• Full 3D Support frame packing (Blu-Ray) / stereoscopic

(satellite/cable)

• Bi-directional, wide range IR control of inputs/outputs

from source and display locations via discrete IR control

(30 KHz to 56 KHz frequency)

• Fully routable RS232 serial control allows central control

of all display devices connected to the matrix via

WyreStorm Enado and third party control systems

• PoH – power passed directly along Cat5e/6 cable up to

70m/230ft from the MX-PP-POH to all connected PoH-

enabled display receivers - no additional power required

at display location for PoH receivers

• Each output can be cascaded up to 7 times for even

larger distributions spanning 56 displays covering a

transmission distance of up to 1.2Km/ 0.74miles

• Matrix also cascadable up to 7 times (using a TX-

POH-020 HDMI pass-thru card) for the quick and easy

creation of very large arrays of up to 392 displays

• Conforms to IEEE-568B standards

• HDCP compliant with constant feed to prevent screen

drop-outs

• Reads, copies and manages EDID from connected

devices

• Fully compatible with market leading third party control

systems - full integration protocols available for AMX,

Control4, Crestron, Red Eye, Nevo, RTI, Control FX,

Savant, Bit Wise, Elan, g!, URC, WyreStorm Enado

• Choose from 5 switching methods – front panel

buttons, local IR, IR call-back, RS232 and LAN

• Remote control can also be learned into a universal

remote handset to allow the control of multiple devices

from one handset

• Compact 2U size

• Additional infrared extension port for longer IR

connections

• Including mounting brackets, IR receivers, IR

transmitters and remote control handset

NOTE: *Perfect transmission conditions denote cable run

is within specied distance range of product, no electrical

interference, the use of straight cable runs with no bends

or kinks and no patch panels or wall outlets used. Please

be advised that the presence of any of these factors in

your installation may compromise bandwidth and signal

strength.

1. Do not expose this apparatus to rain, moisture,

sprays, drips or splashes and ensure that no

objects containing liquids are placed on the

apparatus, including cups, glasses and vases.

2. Do not place this unit in a conned space such as

enclosed shelving, cabinets or bookshelves.

Ensure the unit is adequately ventilated.

3. To prevent the risk of electric shock or re hazard

due to overheating, do not cover the unit or

obstruct ventilation openings with material,

newspaper, cardboard or anything that may restrict

airow into the unit.

4. Do not install near external heat sources such as

radiators, heat registers, boilers or any device that

produces heat such as ampliers or computers and

do not place near sources of naked ame.

5. Unplug apparatus from power supply during

lightening storms or when unused for long periods

of time.

6. Protect the power cable from being walked on,

pinched or restricted in any way, especially at plug

connections.

7. Only use attachments/accessories specied by the

manufacturer.

8. Units contain non-servicable parts - Refer all

servicing to qualied service personnel.

9. Attention Do Not Hotswap HDMI plugs or HDBaseT

connectors - Please insert and extract cables carefully

with the power SWITCHED OFF. Power is passed along

transmissions so connecting and disconnecting cables

while powered can result in damage to circuitry or

possible injury.

WARNING

To reduce the risk of re, electric shock

or product damage:

• Simplied ports - Input: HDMI – Output: integrated RJ45

connectors for a single Cat5e/6/7 UTP cable to each display

USB to 5V Cable
