COM230
Active Paging Station
953.230UK
User Manual
Version 1.0
Caution: Please read this manual carefully before operating
Damage caused by misuse is not covered by the warranty
953.230UK User Manual
Introduction
Thank you for choosing Adastra COM230 active paging station for r compact audio installation. an you
This unit is designed to power wall or ceiling mounted speakers and offer microphone paging to 2
separate zones. Please read this manual to gain the best results from your product and avoid damage
through misuse.
SAFETY SYMBOL AND MESSAGE CONVENTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC ELECTRIQUE NE PAS
OUVRIR
This symbol indicates that dangerous voltage constituting a risk of electric shock is
present within this unit
This symbol indicates that there are important operating and maintenance instructions in
the literature accompanying this unit.
Warning
To prevent the risk of fire or electric shock, do not expose any components to rain or moisture. If
liquids are spilled on the casing, stop using immediately, allow unit to dry out and have checked by
qualified personnel before further use. Avoid impact, extreme pressure or heavy vibration to the case.
No user serviceable parts inside Do not open the case refer all servicing to qualified service – –
personnel.
Safety
• Only use the power adaptor supplied with the COM230. Other adaptors may damage the circuitry.
• Check for correct supply voltage before connecting the power adaptor to the mains.
Placement and Assembly
• Position the COM230 on a stable surface, such as a worktop, counter-top or desk . top
• Ensure adequate access to rear panel connections and controls.
• Allow enough slack lead length to avoid straining cable or connectors at the rear panel.
Cleaning
• Use a soft cloth with a neutral detergent to clean the housing as required.
• Use a vacuum cleaner to clear apertures and controls of any dust or debris bu - . ild up
953.230UK User Manual
Connections and Controls
1. XLR microphone connector
2. A and Mic signal indicators ux
3. Zone 1 pag select button ing
4. Zone 2 pag select button ing
5. Microphone paging button
6. 3.5mm A put jack ux in
7. Aux output level
8. Mic output level
9. Zone 1 speaker output terminals
10. Zone 2 speaker output terminals
11. DC power adaptor input
Speaker connections
Connect speakers to the Zone 1 and Zone 2 speaker terminals (9 using 2-core speaker cable. , 10)
The green Euroblock screw terminals may be unplugged from the rear panel for easier connection.
Connect + terminal to the + connection of the speaker. the “ ” “ ”
Connect - terminal to the - connection of the speaker. the “ ” “ ”
Each speaker zone output can deliver al at 4 . 30W tot Ω
This means that a single 8 speaker may be Ω
connected to either zone ceiving up to . , re 15W
Alternatively, 2 x 8 speaker may be connected Ωs in
parallel to either zone, each receiving up to 15W.
Both of these scenarios are shown in the diagram
opposite.
Another option would be to connect a singl 4 e Ω
speaker to either speaker zone output, which would
receive up to . 30W
Ensure that the combined impedance connected to each speaker output is not lower than 4 and that Ω
the speakers connected can handle the output power at that combined load impedance.
