Sida 1/2
AG Preamp Pedal
Revered for its tight, fast response and wide tonal flexibility, the AG preamp takes the beloved AG sound
and places it in a compact pedal. The AG preamp features a 4-band EQ and foot-switchable broadband
“deep” and “bright “controls for added depth and presence. Its 18-volt operation provides plenty of
headroom ensuring your sound stays clean and transparent. It also features a built-in headphone out and
aux in, for silent practicing, as well as a DI with pre/post and ground lift controls. The AG preamp is a
must-have for any bassist looking for a clean and transparent preamp with all the controls needed for
sculpting their sound.
Features:
• Analog preamp circuit inspired from the AG 700 amplifier
• 4-band EQ with treble, bass, low midrange, and high midrange controls
• Foot-switchable, broadband “Bright” and “Deep” EQ controls
• DI out with pre/post and ground lift controls
• 1/8” aux-in and 1/8” headphone out for silent practice
• Three-year limited warranty
Owner’s Manual
Manual Version 1.1
Functions
A. Top Panel:
Gain - Controls input sensitivity level
Treble - +/- 14 dB @ 4 kHz
Bass - +/- 17 dB @ 40 Hz
High Mid - +/- 14dB @ 800 Hz
Low Mid - +/- 15 dB @ 300 Hz
Volume - Controls output level
Engage - Toggles between on/bypass (blue LED indicates on)
Bright/Deep - Toggles through broadband “Deep”, “Bright”, or “Deep + Bright” (blue LED indicates on) The
frequencies for the boosts are:
Deep: +6 dB <250 Hz, shelving Bright: +6 dB >3 kHz, shelving
Headphone Mix - Controls mix of bass signal and aux-in in headphones
Aguilar Musical Instruments
316 South Service Road
Melville, NY 11747
B. Top Side Panel:
In: 1/4” input
Aux In: 1/8” aux input for music device
Out: 1/4” output
Headphones Out: 1/8” headphones output
DC IN: 18v. This is a standard 2.1mm DC jack. The center terminal polarity is negative.
C. Left Side Panel:
DI Out: XLR balanced DI out
Pre/Post Control:
Pre: Your signal goes to the D.I. XLR output before your Gain and EQ settings
Post: Gain, EQ, and Master settings will be sent to the D.I. XLR output jack.
Ground Lift Control: If there is a hum when using the D.I, there may be a ground loop. In many cases,
pushing in the Ground/Lift button can fix this problem.
D. Specifications:
Current consumption:............................. 36 mA
Input impedance: ..........................................1mega Ohm
Output impedance: .........................................1k
External DC Power: ………………………18v DC
E. Headphone out:
The AG Preamp features a headphone out for silent practice. Use the Aux-In 1/8” for connecting your
laptop, phone, or audio source and the Headphone Out 1/8” out for your headphones. To adjust the
overall headphone volume, use the main Volume control. To adjust the balance of your aux-in to
headphone mix, use the Headphone Mix control just above the Volume control.
USA
Aguilar Amplification’s products are covered under warranty to the original owner against defects in
materials and workmanship. Aguilar products are under warranty for a period of 3 years. Tubes are
covered by the warranty for a period of 90 days and speakers are covered for a period of 1 year.
The warranty period starts from the date of purchase from an authorized Aguilar dealer. Your sales slip or
purchase invoice is necessary for warranty service.
If you are needing your unit to be repaired or serviced within the USA, please contact Korg USA
Customer Service at customerservice@korgusa.com with a description of your unit’s issue. For general
product support, please contact support@korgusa.com.
Aguilar Amplification is not responsible for shipping damage, either to or from our service centers. Claims
must be filed with the carrier.
Outside USA
Please contact your local Dealer or Distributor for your countries specific warranty period and repair
procedure.
Aguilar Musical Instruments
316 South Service Road
Melville, NY 11747
