User Guide
SW640 / SW642
Wireless Half Mile Hailer PA System
Thank you for choosing the from SW640 / SW642 Wireless Half Mile Hailer PA System AmpliVox Porta-
ble Sound Systems.
We are excited in introducing this truly unique system. Our system combines flexibility with functionality.
Please refer to this user guide as you enjoy the unique capabilities of another quality product from Am-
pliVox Portable Sound Systems.
We encourage you to visit our website to register your product for its warranty coverage, www.ampli.com
sign up to receive our newsletter, download our catalog, and learn more about the complete line of Am-
pliVox audio visual products, including portable PA systems, and lecterns.
AmpliVox 650 Anthony Trail Suite D, Northbrook, IL 60062 Phone: (800)267-• • 5486 • Fax: (800)267-5489 www.ampli.com
2
IMPORTANT SAFETY INSTRUCTIONS
Before using this product, read the instruction manual for important safety information. Please retain this manual for
future reference and warranty information.
Troubleshooting & Servicing
Do not attempt to service or repair the device yourself. Refer all servicing to qualified service personnel. Do not at-
tempt to modify the device in anyway. Doing so could invalidate your warranty.
Cleaning
When cleaning the device, please use a soft, dry cloth. Never use benzene, paint thinner, or other chemicals on the -
device.
Location
Place the device in stable location, so it will not fall causing damage to the device or bodily harm.
Intended use
The product may only be used with the original parts intended for it. The intended use includes adherence to the speci-
fied installation instructions. The manufacturer accepts no liability for damage arising due to improper use.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance instructions in this owner’s guide.
IMPORTANT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, includ-
ing interference that may cause undesired operation.
The unit’s circuitry may cause interference to nearby radios. To prevent interference, either switch the unit off or move
away from the affected radio.
NOTE: This equipment complies within the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or tele-
vision reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
NOTE: Shielded cables may be required to be used with this unit to en sure compliance with the Class B FCC limits.-
3
Battery Power
1. The amp uses 10 " D " size Alkaline batteries
(not included); or the optional rechargeable Am-
pliVox NiCad Battery Pack (S 1465) and (S1460) -
AC adapter purchase separately (Fig 3).-
2. The removable battery door on the back of the
amp is designed to stay closed until you need to
change the batteries. Slip a finger nail under it and
slide it out. (Fig 1)
3. Lift the battery holder out. The plastic dividers
between the batteries help prevent battery corro-
sion. (Fig 2)
4. Install 10 fresh Alkaline " D" size batteries. Be
sure to observe the polarity when putting batteries
in the battery compartment. The negative (flat)
ends go against the springs. (Fig 2) Carefully re-
place battery holder. Batteries should look like they
are standing up.
DO NOT MIX BATTERY TYPES OR
ATTEMPT TO RECHARGE ALKA-
LINE BATTERIES. EQUIPMENT
DAMAGE, SAFETY HAZARD OR
FIRE COULD RESULT.
Note: The battery holder cable comes from the
factory already plugged into the connector. If it
comes loose, push it in securely. (Turn the plug
over if it doesn’t fit; it only fits one way.)
5. Slide door back into place.
6. If using the S 1465 NiCad Battery pack (Fig 3), -
Plug AC Adapter/ Recharger power supply (S1460)
into the jack on front panel of the amp. “DC IN”
Plug into a working electrical outlet. Charge 24
hours for full charge before using.
Wireless Transmitter
The wireless headphone transmitter bodypack is
operated by 1 "AA" alkaline battery. Before use, -
install battery as shown (Fig. 4). Make certain the
battery is fully seated in its compartment so the
cover slides in place easily. Battery life with alkaline
batteries is approximately 8 hours of operating
time. When LED on top panel turns to the bat-RED
tery should be replaced immediately.
Fig 4
Fig 3
Fig 2
Fig 1
S 1465 S 1460- -
INSTALL BATTERIES
